Summary of Contents for CEL POWERmow
- Page 1 POWERmow 24V Cordless Cylinder Mower User Manual Innovation from C Enterprise Ltd...
- Page 2 THANK YOU Thank you for investing in a CEL product. The 24V Cordless Cylinder Mower has been engineered and made to demanding high quality standards; ease of operations and safety have taken a major role in development. Proper care of your product will give you years of trouble-free use.
-
Page 3: Table Of Contents
Contents Important Safety Notes Unpacking Assembly GETTING STARTED Safety Key Battery Charging Cutting Height Battery Level Warning Blade Adjustment MOWING Mowing Tips Emptying Grass Collector 10.0 Starting & Stopping 10.1 Over Work Protection 11.0 Care and Maintenance 11.1 Storage CARE 11.2 Environment 12.0... -
Page 4: Important Safety Notes
Important Safety Notes READ ALL INSTRUCTIONS BEFORE USE. RETAIN INSTRUCTIONS FOR FUTURE REFERENCE. THIS MACHINE CAN CAUSE SERIOUS INJURIES. WARNING: When using an electrical appliance, basic safety precautions should be observed, including the following, to reduce the risk of fire, electrical shock or injury: 1. - Page 5 Important Safety Notes 20. Stop the blade if the appliance has to be tilted for transportation when crossing surfaces other than grass, and when transporting the appliance to and from the area to be mowed. 21. Never operate the appliance with defective guards, or without safety devices, for example deflectors and/or grass catchers in place.
-
Page 6: Unpacking
Unpacking figure1 1. Main Unit 7. Cable Clips x3 2. Battery Pack 8. Charging Adaptor 3. Lower Frame 9. Keys x2 4. Middle Frame x2 10. Grass Collector 5. Upper Frame 11. Tool 6. Nut & Bolts x6... -
Page 7: Assembly
Assembly Unpacking 1. Unpack and remove the whole unit from its packaging, and ensure all the parts are present. (See figure1) Caution: Remove the Safety Key and Battery from the mower to safely work on the product. 2. Fit the Lower Frame onto the two large lugs on the Main Unit. - Page 8 Assembly 5. Use 4 nuts and 4 bolts to hold the upper and middle sections in place on the Lower Frame. Insert the bolts from the outside and fit the nuts on the inside of the frame. 6. Once the frame is assembled, connect the plug on the handle cable to the socket on the main unit.
-
Page 9: Safety Key
Safety Key IMPORTANT : There is a safety key fitted to this device, the product will not work without it. The key needs to be fitted and turned to the on position for the product to operate. Always remove the key and battery before carrying out any adjustments or maintenance on the mower, or if the mower is left unattended. -
Page 10: Battery
Battery If the battery is damaged in any way do not attempt to charge it and replace immediately. Remove the battery from the product by rotating and lifting with the handle Keep clear of any moisture, direct sunlight or temperature extremes. Fully unwind the charger cable, plug into a suitable mains outlet, the light on the charger will turn green. -
Page 11: Charging
16 hours, but it is advisable not to leave it on for more than 48 hours, as this might shorten the battery life. POWERmow can be used as a push mower if the battery needs charging. Warning: Only use the charger supplied with this product. -
Page 12: Cutting Height
Cutting Height Caution: For safety ensure that the Safety Key and Battery are removed from the Mower before adjusting the height. To ensure that the roller is aligned correctly, it is recommended that the height is adjusted on a level surface. -
Page 13: Blade Adjustment
Blade Adjustment SHARP BLADES-BE VERY CAREFUL. Caution: for safety ensure that the Safety Key and Battery are removed Bolt Bolt from the Mower before adjusting the blade. To adjust the blade turn the 2 bolts on the blade shield. The cylinder should almost touch the Cutting Cylinder blade, but do not over tighten it. -
Page 14: Mowing Tips
Push the mower more slowly when cutting thick grass. If the grass is particularly thick you can release the safety handle and use the POWERmow as a push mower. Emptying the Grass Collector Before removing the grass box for emptying, release the operation lever and wait for the blades to stop turning. -
Page 15: Starting & Stopping
Starting & Stopping 10.0 The handle is designed with a safety button to prevent accidental starting. 1. Press and hold the safety button ‘A’ located on the left of the upper handle, then squeeze the operation lever ‘B’ towards the upper handle. 2. -
Page 16: Care And Maintenance
Care and Maintenance 11.0 CAUTION : Remove the key and Battery before carrying out any maintenance. Do not accidentally turn the unit on while cleaning it. Check for any faults such as loose or damaged blades, loose fittings and worn or damaged components. -
Page 17: Environment
Storage (continued) 11.1 For storage in confined spaces the handles can be removed from the mower. Disconnect the power cord and flex the lower handles to remove from the frame locating lugs. Never Store the Mower With a Flat Battery. The battery should ideally be stored between 10ºC and 24ºC (50ºF and 75ºF). -
Page 18: Faq
Ensure the key is fitted and in the ON position. (see Section 3.0) POWERmow can be used as a push mower if the The overload electronics is preventing damage, allow a battery needs charging or if the grass is very thick. -
Page 19: 13.0 Technical Specifications
- 18.2 Weight Kg (including battery) *Dependant on grass length & thickness If you experience any problems with the product please contact C Enterprise Limited Tel: 08453 88 97 69 email: sales@cel-global.com www.cel-garden.com BEWARE OF SHARP BEWARE OF FLYING GENERAL HAZARD... - Page 20 C Enterprise Ltd C Enterprise Limited www.cel-global.com info@cel-global.com • • • China • Europe • Australia • Japan...
