SPECIFICATIONS

Frequency response, 1 meter on-axis,
swept-sine in anechoic environment:
90 Hz to 20 kHz (±3 dB, with
processing)
Usable low frequency limit
(-10 dB point):
85 Hz (with processing)
Power handling:
Low frequency section:
1,000 watts continuous
2,000 watts program
4,000 watts peak
Mid frequency section:
200 watts continuous
400 watts program
800 watts peak
High frequency section:
200 watts continuous
400 watts program
800 watts peak
Sound pressure level, 1 watt,
1 meter in anechoic environment:
Low frequency section (Both 12"
woofers in parallel):
99 dB SPL (2.00 V input)
Mid frequency section:
101 dB SPL (2.83 V input)
High frequency section:
102 dB SPL (2.83 V input)
Maximum sound pressure level
(1 meter)
:
*
Low frequency section:
129 dB SPL continuous
135 dB SPL peak
Mid frequency section:
124 dB SPL continuous
130 dB SPL peak
Versarray
212
High frequency section:
125 dB SPL continuous
131 dB SPL peak
*Note: This spec is for one module at 1
meter, a line array of 8 units has much
higher output at distance due to line source
effect where SPL falls of at 3 dB per distance
doubling rather than 6 dB. All peak levels
confirmed by measurement.
Normal radiation angle measured at
-6 dB point of polar response:
70° horizontal by 15° vertical
(One module only; straight line array
of more than 1 module narrows
vertical dispersion accordingly)
Radiation angle measured at
-6 dB point of polar response:
500 Hz to 1.6 kHz:
Horizontal 158° +/- 55°
Vertical 90° +/- 45°
1.6kHz to 5 kHz:
Horizontal 84° +/- 15°
Vertical 30° +/- 10°
5 kHz to 16 kHz:
Horizontal 55° +/- 20°
Vertical 10° +/- 4°
Directivity Factor, Q (Mean, 1.6 kHz
to 12.5 kHz):
47.6, +92/-36
Directivity Factor, Di (Mean, 1.6 kHz
to 12.5 kHz):
16.8 dB, +4.6 dB/-6.3 dB
Transducer complement:
Low frequency section:
2 x 12" woofer, 1212-4 Neo Black
Widow
4" Dual VC Woofer in a
®
sealed box
Mid frequency section:
10 x 2.5" in Neo Midranges,
arranged in two banks of 5 each
1
High frequency section:
4 x 4.75" in Planar Dynamic
Ribbon Tweeter line sources on a
manifold-loaded waveguide
Box tuning frequency (Sealed):
Low frequency section: 94 Hz
Midrange section: 220 Hz
Harmonic Distortion
:
*
1 watt power
2nd Harmonic:
200 Hz
0.32%
1 kHz
0.47%
4 kHz
048%
3rd Harmonic:
200 Hz < 0.10%
1 kHz
0.19%
4 kHz
0.18%
10 watt power
2nd Harmonic:
200 Hz
1.38%
1 kHz
1.52%
4 kHz
0.72%
3rd Harmonic:
200 Hz
< 0.10%
1 kHz
0.32%
4 kHz
0.16%
*Note: Distortion levels may be measurement
setup limited in some instances
Electroacoustic crossover point,
Peavey active digital crossover:
(Applies to VSX and Digitool settings provided by
Peavey)
Sub - Low frequency:
120 Hz at 24 dB/octave
Low frequency - Mid frequency:
440 Hz at 24 dB/octave
Mid frequency - High frequency:
2.51 kHz at 24 dB/octave
Recommended active crossover
frequency region and slope:
Sub - Low frequency:
125 Hz at 24 dB/octave LR
Low frequency - Mid frequency:
440 Hz at 24 dB/octave LR
Mid frequency - High frequency:
2.6 kHz at 24 dB/octave
Time Offset:
Low frequency: -0.33 milliseconds
Mid frequency: -0.25 milliseconds
