Belkin YourType Product Overview

YourType Keyboard Case
™
for Kindle Fire HD 8.9"
Delivering the best typing experience. Enjoy!
Product Overview
1. Bluetooth ® keyboard 3. Charging port (micro-USB)
2. Status LED 4. Bluetooth pair button
To start, charge your keyboard by connecting the USB cable to an
appropriate USB power source (e.g. laptop, USB wall charger, etc.) and
the micro-USB to your keyboard.
When the battery is fully charged, the Status amber LED turns OFF.
Then pair it with your Kindle Fire HD. The Status LED light will flash
blue while the keyboard is not paired.
To initiate pairing between the keyboard and iPad, ensure that they are
in close proximity:
4
For Kindle Fire HD:
Go to the Home screen on your Kindle Fire HD and slide down the
1 1
settings menu on "Settings menu > Wireless > Bluetooth."
2
Turn Bluetooth to "On."
2
Turn on the keyboard and press and hold the "Pair" key. The Status
3
LED will flash blue on the keyboard and the keyboard will show up
3
under "Devices" on the tablet. Select "Belkin Bluetooth Keyboard."
Note: When pairing and charging simultaneously, the amber
charging light will remain on while the blue pairing light flashes.
A code will appear on the Kindle Fire HD screen. Use the keyboard
4
to enter this code followed by the "Enter" key.
5 If, after 60 seconds, pairing fails, you will have to repeat the steps
above. You can view the status from the screen of the Kindle Fire HD.
Note: For other Bluetooth devices, follow device's Bluetooth pairing
instructions.
After creating a paired link, you do not need to repeat the pairing process;
the keyboard automatically links to the tablet or smartphone when both
devices are switched on. Pairing must be performed every time you want
to use the keyboard with a different tablet or smartphone. Note that
when the power switch is OFF and you plug the USB cable to charge the
keyboard, it'll attempt to pair the device.
The keyboard is designed to prolong battery life and will enter into
battery-saving mode under prolonged inactivity. To wake the keyboard,
press any button. The Status LED will flash blue while the connection
is being reestablished, and will be solid blue for two seconds when the
connection is successfully established. The Status LED then turns off
during ongoing operation.

Bluetooth Wireless Technology

Bluetooth wireless technology has revolutionized the personal
connectivity market by providing seamless freedom from wired
connections. It offers a small form factor and a low-cost radio solution,
providing links between mobile computers, mobile phones, and other
portable and handheld devices as well as connectivity to the Internet.
The Bluetooth Special Interest Group (SIG), composed of leaders in
the telecommunications, computing, and network industries, is driving
development of the technology and bringing it to market. The Bluetooth
SIG includes promoter companies 3Com®, Ericsson®, IBM®, Intel®,
Lucent®, Microsoft®, Motorola®, Nokia®, Toshiba®, and more than 2,000
adopter companies.

Safety Precautions

Please read the following carefully before using the product. Incorrect
use or incompatibility
with your device may result in reduced performance or damage to your
device.
• Do not attempt to disassemble product.
• Store and operate between 32° F–113° F.
• Do not allow this product to have contact with liquids.
• Do not place this product near a heat source or flame or it may explode.
• Do not throw or shake the Keyboard Case.
• Do not crush or puncture the Keyboard Case.
• Use soft cloth to clean the exterior. Do not use harsh chemicals or
strong cleaning solvents.

Recycling/Discarding

This product should be disposed of properly. Please do not dispose in
trash receptacles or incinerate. Recycling programs for this product/
packaging may not exist in your area.

FCC Statement

This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to
operate this equipment.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
