- Page 1 ODK U500 (V2) Electric Bicycle Ownerʼs Manual (English) _______________________________________________ R130101 Juiced Riders Inc. 8724 Approach Road, San Diego, CA 92154, U.S.A. mail@juicedriders.com Tel: +1 (619) 746-8877 www.Juicedriders.com...
-
Page 2: How To Charge The Battery
Juiced Riders | ODK U500 V2 | User Manual How to charge the battery Charge the battery fully before the first use. The longer you ride using the battery, the longer it will need to charge. • Be sure the bike is powered off. - Page 3 Juiced Riders | ODK U500 V2 | User Manual Turning the bicycle ON and OFF The electric bicycle can be ridden like a normal bicycle with the power turned ON or OFF. However the throttle will be active only if the power is turned on.
- Page 4 Juiced Riders | ODK U500 V2 | User Manual Using the twist throttle The motor speed is controlled with a twist throttle similar to a motorcycle. The farther you twist the throttle backwards, the faster the bike will travel. •...
-
Page 5: Using The Brakes
Juiced Riders | ODK U500 V2 | User Manual Using the brakes The bike comes equipped with front and rear brakes. You can use the brakes to slow the bicycle down. • The front brake lever is located on the left-hand side of the handlebar. - Page 6 Juiced Riders | ODK U500 V2 | User Manual Shifting the gears You can change the gears to find a more comfortable pedaling cadence when going up hills or riding at a fast pace. If your bike comes equipped with a 3-speed internal transmission, the gears can be shifted at anytime.
-
Page 7: Using The Cruise Control
Juiced Riders | ODK U500 V2 | User Manual Using the cruise control The cruise control system can be used to maintain a constant speed. It works similar to a cruise control in an automobile. The cruise control will deactivate if the brakes are applied, if the throttle is moved, or if the CRUISE button pushed again. - Page 8 Juiced Riders | ODK U500 V2 | User Manual How to read the battery level There are 4 LED lights on the display panel which will give you an indication of the batteryʼs voltage. Because the battery gauge measures voltage, only an approximate estimation of the battery's state can be obtained.
- Page 9 Juiced Riders | ODK U500 V2 | User Manual Understanding the battery's range All electric bicycles have a riding range that can vary greatly depending on how it is ridden, terrain, tire pressure, temperature, payload and wind. After a few rides, you will get a sense of the electric bicycle’s range capability.
-
Page 10: Battery Safety Information
Juiced Riders | ODK U500 V2 | User Manual Battery Safety Information About the Lithium battery Your Lithium battery does not have a “memory effect” associated with older battery technologies. It is highly recommended you charge the battery after every ride even if the battery is only lightly used. - Page 11 Juiced Riders | ODK U500 V2 | User Manual Key parts of the electric bicycle An electric bicycle is a lot like a normal bicycle. The major difference is the inclusion of a motor which provides a boost when desired. An onboard rechargeable lithium battery supplies the motor with electric power.
- Page 12 Juiced Riders | ODK U500 V2 | User Manual Key parts of the electric bicycle (continued) Gear Shifter The gear shifter changes the ratio between the pedals and the rear wheel. It is used to find a more comfortable pedaling cadence under different riding conditions.
- Page 13 Juiced Riders | ODK U500 V2 | User Manual Adjusting the bicycle for riding comfort 1. Adjusting the seat height Pull the seat clamp lever outward to loosen the seat post. Adjust the seat the desired height. The maximum height should not extend beyond minimum extension mark marked on the seat post.
-
Page 14: Important Safety Information
Juiced Riders | ODK U500 V2 | User Manual Important Safety Information Basic Bicycle Safety • Always wear a helmet. • Use a light and wear reflective clothing when riding at night. • Reduce speed when riding on a wet surface. - Page 15 Juiced Riders | ODK U500 V2 | User Manual Bicycle Specifications...
- Page 16 Juiced Riders | ODK U500 V2 | User Manual Warrantee Information Juiced Riders Inc. provides a Limited Warrantee for one year covering the frame, components, and electronics including the battery. A battery pack that has been damaged, disassembled, submerged in liquid, used to power another device, or short- circuited will void the battery warrantee.
- Page 17 Juiced Riders | ODK U500 V2 | User Manual NOTES...
