Blackheart BH15-112 Handsome Devil User Manual

Combo guitar amplifier
Hide thumbs

Advertisement

Quick Links

BH15-112 Handsome Devil
Combo Guitar Amplifier
User's Guide

Advertisement

loading

Related Manuals for Blackheart BH15-112 Handsome Devil

Summary of Contents for Blackheart BH15-112 Handsome Devil

  • Page 1 BH15-112 Handsome Devil Combo Guitar Amplifier User’s Guide...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Introduction................3 BH15-112.Special.Features..........4 The.Front.Panel..............5 The.Rear.Panel..............6 Important.Information.About.Tubes.and.Tube.Products.....8 System.Block.Diagram............11 Technical.Specifications............12 CAUTION PRECAUCION ATTENTION RISK OF ELECTRIC SHOCK RIESGO DE CORRIENTAZO RISQUE D'ELECTROCUTION NE PAS OUVRIR DO NOT OPEN NO ABRA WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC PRECAUCION: PARA REDUCIR EL RIESGO DE INCENDIOS O DESCARGAS ATTENTION: PROTÉGEZ CET APPAREIL DE LA PLUIE ET DE L'HUMIDITÉ...

  • Page 3: Introduction

    We.like.the.way.you.do.your.hair..You’ve.got.style..Speaking.of.which,.take.a.look.at.the.way. this.amp.is.built..16.gauge.steel,.½".radius.corners.in.a.void-free.birch.ply.cabinet.that.looks. like.Michelangelo.covered.it.for.you.personally..How.about.a.double-sided.PCB.with.2.oz..cop- per.traces,.so.your.big.fat.sound.has.lots.to.hold.on.to.traveling.through.a.classic.boutique. circuit.path.designed.by.none.other.than.Pyotr.Belov.himself..The.guy’s.got.a.soldering.iron.in. his.hands.most.hours.of.the.night.so.if.he.says.“make.the.thing.like.a.tank,”.everyone.agrees. real.quickly..Who.knows,.you.might.be.in.some.sort.of.edge.band;.knock.the.thing.around.a. bit..That’s.a.Blackheart.thing..We.make.rock-solid,.no.compromise.music.gear.that.sounds. like.choruses.of.angels.who.sing.in.big,.beefy.power.chords..We.work.with.glass,.metal.and. wood.just.like.the.powers.that.be.intended.when.they.created.rock.and.roll..We.take.every. amp.personally.and.we.do.it.assuming.you.worked.hard.to.get.it.and.we’re.not.letting.you. down..That.fancy.tattoo.logo.was.inspired.by.one.of.our.test.animals.*.He.said.a.great.amp. leaves.a.permanent.mark.on.your.tone,.and.shapes.how.you.play,.write,.perform,.etc..So,. when.you.laid.down.coin.for.a.Blackheart,.you.kind.of.got.hitched. And.it.didn’t.set.you.back.much,.especially.when.you.consider.what.you.got..Every.Blackheart. design.starts.as.a.hand-built.masterpiece.with.no.thoughts.about.cutting.cost.or.going.for. it.on.the.cheap..Pyotr.picks.every.component.one.by.one.and.tweaks.until.his.ears.hear.the. tone..Once.he’s.given.birth.to.the.prototype.(ouch!),.he.personally.works.with.offshore.manu- facturing.to.translate.that.exact.tone.into.the.most.affordable.piece.of.gear.that.won’t.let.you. down..Literally,.he.works.in.the.factory,.training.other.people.how.to.build.boutique-quality. amps.and.sits.on.the.QC.line.before.anything.gets.into.a.box..Blackheart.isn’t.the.cheapest— plenty.of.other.amps.are.cheap.and.you.can.have.your.pick..We.prefer.to.be.ultra-high.quality. and.performance.for.a.price.that.anyone.can.afford.. So.thanks.for.laying.down.your.hard-earned.cash.for.a.Blackheart.Engineering.product..We’re. not.going.to.disappoint.you..You’ve.got,.in.your.hands,.one.of.the.best.sounding,.best.quality,. old.school.inspired.amps.that’s.ever.been.made.. Vous.avez.notre.coeur, Pyotr.Belov. Kevin.Van.Pamel.. Walter.Hsu Blackheart Engineering *.We.don’t.test.on.little.furry.helpless.animals.of.course..We.call.our.artists.animals.because,.well,.we’ve. eaten.with.them..They.give.their.time.and.opinions.to.us.on.a.regular.basis.and.have.a.lot.to.do.with.how. good.your.Blackheart.is.

  • Page 4: Bh15-112.Special.features

    BH15-112 Special Features: •. Push-Pull.Class.A.circuit. •. All.tube.signal.path. •. Two.12AX7/ECC83.dual-triode.preamp.tubes.and.two.EL84/6BQ5.pentode.output.tubes. •. Pentode.(15W.RMS).Triode.(7W.RMS).switch. •. DC.filament.power.supply.for.preamp.tubes. •. 3-band.EQ,.Level.(Master.Volume).Control.and.Presence.Control •. 16-gauge.(1.5.mm).thick,.folded.and.spot.welded.steel.chassis. •. Double-sided.custom.color.PCB.with.2.oz..copper. •. 15-ply,.18.mm.thick,.void-free.birch.plywood.construction. •. 16.ohm,.two.8.ohm,.and.two.4.ohm.speaker.outputs •. Built-in.12-inch.custom-designed.Eminence.speaker.rated.at.16.ohms •. Trans-dimensional.hyper-extragalatic.Teriyaki-Net™.option.allows.you.to.think.about.lunch. from.any.point.in.the.Universe...

  • Page 5: The.front.panel

    The Front Panel DRIVE LEVEL TREBLE MIDDLE BASS PRESENCE INPUT 15 WATTS 7 WATTS BH15-112 PRESENCE:.Use.this.to.boost.high. INPUT:.Use.this.jack.to.connect.your. frequency.response.and.overall.punch. guitar.to.the.amplifier.using.a.high-qual- of.the.output.section..The.adjustment. ity.shielded.instrument.cable.. range.is.+28dB.at.20.kHz. DRIVE:.Use.this.to.adjust.the.amp.gain. INDICATOR LAMP:.This.illuminates. of.the.amplifier.. when.the.amplifier.is.turned.on.(power,. LEVEL:.Use.this.to.adjust.the.output. that.is). volume.of.the.amplifier. 15 WATTS/7 WATTS:.This.is.the. TREBLE:.Use.this.to.adjust.the.output. Pentode/Triode.switch..It.allows.you. level.of.the.high.frequencies..The.adjust- to.operate.the.amplifier.in.two.distinct. ment.range.is.+14.dB.at.10.kHz.. modes.of.operation.and.output.power. MIDDLE: Use.this.to.adjust.the.output.

  • Page 6: The.rear.panel

    The Rear Panel Using external cabinets The.rear.panel.is.located.inside.the.open. back.of.the.cabinet,.towards.the.top..It.has. The.hookup.diagrams.on.the.next.page. connections.for.the.AC.power.cord,.the.built- show.some.different.cabinets,.their.imped- in.speaker,.and.external.speaker.cabinets.. ance,.where.to.plug.them.in,.and.the.total. WARNING!.Never.turn.on.the.amplifier.with- load.placed.on.the.amplifier. out.a.load,.the.built-in.speaker.or.external. ALWAYS.use.good.quality.(non-shielded). speakers.connected.to.the.amplifier. speaker.cable.to.connect.speaker.cabinets.. AC Power Input with Mains Fuse:. Never.use.(shielded).instrument.cable. The.amplifier.is.equipped.with.a.detach- ALWAYS.match.the.amplifier’s.speaker. able.power.cord.that.plugs.into.this. output.impedance.to.the.impedance.of.the. IEC.Mains.socket..The.AC.power.cord. speaker.that.is.being.used. should.only.be.plugged.into.a.grounded. Unplug.the.built-in.speaker.from.the.16. power.outlet.that.meets.all.applicable. •. electrical.codes.and.is.compatible. ohm.output.when.connecting.external. with.the.voltage,.power,.and.frequency. speakers.to.the.8.ohm.or.4.ohm.out- requirements.stated.on.the.rear.panel.
  • Page 7 Typical connections to external speaker cabinets Note:.Where.the.built-in.speaker.is.not. shown.below,.it.is.not.connected. External Built-in 16Ω 16Ω 16Ω 16Ω Cabinets Speaker in parallel Built-in speaker with a 16 ohm external cab. Two 16 ohm cabinets. Total Load = 8 ohm Total Load = 8 ohm. Use both 8 ohm outputs. Use one 8 ohm output jack.

  • Page 8: Important.information.about.tubes.and.tube.products

    Important Information about Tubes and Tube Products: The Nature Of Tubes — Why (And When) To Replace Them: Tubes.are.made.up.of.a.number.of.fragile.mechanical.components.that.are.vacuum-sealed.in.a. glass.envelope.or.bubble..The.tube’s.longevity.is.based.on.a.number.of.factors.which.include. how.hard.and.often.the.amplifier.is.played,.vibration.from.the.speakers,.road.travel,.repeated. set.up.and.tear.down,.etc. Any.time.you.notice.a.change.in.your.amplifier’s.performance,.check.the.tubes.first. If.it’s.been.a.while.since.the.tubes.were.replaced.and.the.sound.from.your.amplifier.lacks. punch,.fades.in.and.out,.loses.highs.or.lows.or.produces.unusual.sounds,.the.power.tubes. probably.need.to.be.replaced..If.your.amplifier.squeals,.makes.noise,.loses.gain,.starts.to. hum,.lacks.“sensitivity”,.or.feels.as.if.it.is.working.against.you,.the.preamplifier.tubes.may. need.to.be.replaced. The.power.tubes.are.subjected.to.considerably.more.stress.than.the.preamplifier.tubes.. Consequently,.they.almost.always.fail/degrade.first..If.deteriorating.power.tubes.aren’t. replaced.they.will.ultimately.fail..Depending.on.the.failure.mode,.they.may.even.cause.severe. damage.to.the.audio.output.transformer.and/or.other.components.in.the.amplifier..Replacing. the.tubes.before.they.fail.completely.has.the.potential.to.save.you.time,.money.and.unwanted. trouble..Since.power.tubes.work.together.in.an.amplifier,.it.is.crucial.that.they.(if.there.is.more. than.one).be.replaced.by.a.matched.set..If.you’re.on.the.road.a.lot,.we.recommend.that.you. carry.a.spare.matched.set.of.replacement.power.tubes.and.their.associated.driver.tubes. After.turning.off.the.power.and.disconnecting.the.amplifier.from.the.power.source,.carefully. check.the.tubes.(in.bright.light).for.cracks.or.white.spots.inside.the.glass.or.any.other.appar- ent.damage..Then,.with.the.power.on,.view.the.tubes.in.a.dark.room..Look.for.preamplifier. tubes.that.do.not.glow.at.all.or.power.tubes.that.glow.excessively.red. Whenever.you.replace.the.power.tube(s): •.
  • Page 9 Important Information About Tubes and Tube Products (continued): The Importance Of Proper Biasing: For.the.best.performance.and.longest.tube.life,.proper.biasing.is.imperative..Bias.is.the.nega- tive.voltage.which.is.applied.to.the.power.tube’s.control.grid.to.set.the.level.of.idle.current.. We.cannot.over.emphasize.the.difference.in.warmth.of.tone.and.dynamic.response.that.come. with.proper.biasing..If.the.bias.is.set.too.high.(over.biased),.the.sound.from.the.amp.will.be. distorted.at.all.levels..If.the.bias.is.set.too.low,.(under.biased).the.power.tubes.will.run.hot.(the. plates.inside.the.tubes.may.glow.red.due.to.excessive.heat).and.the.sound.from.the.amplifier. will.lack.power.and.punch..The.excessive.heat.greatly.reduces.tube.life.–.from.a.few.days.to. as.little.as.a.few.hours.in.extreme.cases..Setting.the.bias.on.your.amp.is.like.setting.the.idle. on.your.car..If.it’s.too.high.or.hot.it’s.running.away.with.you.and.if.it’s.too.low.or.cold.it.will. choke.when.you.step.on.it. The.bias.is.adjusted.at.the.factory.in.accordance.with.the.type.of.power.tube(s).installed.in. your.amplifier..It.is.important.to.point.out.that.tubes.of.the.same.type.and.specification.typi- cally.exhibit.different.performance.characteristics..Consequently,.whenever.power.tubes.are. replaced,.the.bias.voltage.must.be.checked.(unless.the.amplifier.is.equipped.with.“self-biasing”. circuitry).and.readjusted.to.accommodate.the.operating.parameters.of.the.replacement.tubes. Depending.on.the.model.and.amplifier.type,.there.may.be.hum.balance.controls,.trim.pots,.or. bias.adjustment.controls.on.its.rear.panel..However,.the.bias.adjustment.should.be.performed. only.by.qualified.service.personnel.with.the.proper,.calibrated.test.equipment.
  • Page 10 Important Information About Tubes and Tube Products (continued): Survival Tips For Tube Amplifiers: To.prolong.tube.life,.observe.these.tips.and.recommendations: •. Match.the.impedance.of.your.speaker.cabinet(s).to.your.amplifier..Improper.impedance. matching.will.contribute.to.early.tube.degradation.and.may.cause.premature.tube.failure. •. Make.sure.the.speaker(s).are.properly.connected.prior.to.turning.on.the.amplifier. •. After.playing.the.amplifier,.allow.sufficient.time.for.it.to.properly.cool.down.prior.to.moving. it..A.properly.cooled.amplifier.prolongs.tube.life.due.to.the.internal.components.being.less. susceptible.to.the.damage.caused.by.vibration. •. Allow.the.amplifier.to.warm.up.to.room.temperature.before.turning.it.on..The.heat.gener- ated.by.the.tube.elements.can.crack.a.cold.glass.housing. •. Replace.the.output.tube(s).before.the.performance.degrades.or.the.tubes.fail.completely.. Replace.the.tube(s).on.a.regular.basis.(at.least.once.per.year.or.as.often.as.every.4.to.6. months.if.you.play.long.and.hard.every.day). •. Always.have.the.bias.checked.after.replacing.the.output.tubes.(unless.the.amplifier.is. equipped.with.“self-biasing.circuitry”)..This.should.be.done.ONLY.at.a.qualified.service. center..Improper.biasing.could.result.in.the.tubes.running.too.hot,.which.greatly.reduces. the.life.of.the.tubes.–.or.too.cold,.which.results.in.distorted.sound.regardless.of.level. settings..Do.not.play.the.amplifier.if.it.exhibits.these.symptoms.–.get.the.bias.checked/ adjusted.immediately.to.prevent.tube.failure.and/or.other.damage. •. If.the.locating.notch.on.the.base.of.a.power.tube.breaks.off,.replace.the.tube..This.signifi- cantly.reduces.the.risk.of.damaging.your.amplifier.by.incorrectly.inserting.the.tube. •.

  • Page 11: System.block.diagram

    16 OHM 8 OHM PRESENCE 8 OHM 4 OHM 4 OHM EMINENCE BUILT-IN SPEAKER 16 OHM 12 INCH Declaration Of Conformity Manufacturer: LOUD Technologies Inc.   16220 Wood-Red Rd. NE Woodinville, WA 98072, USA Product Name: Blackheart BH15-112 Product Type: Audio Amplifier Complies with Standards: LVD: 92/31/EEC, 93/68/EEC, & 73/23/EWG   Safety: EN60065   EMC: EN55013, EN55020, EN55022, EN55103, EN61000-3-2, & EN61000-3-3 The official Declaration of Conformity for this product is kept on file at: LOUD Technologies Inc., 16220 Wood-Red Road NE, Woodinville, WA 98072 • Tel: 1-866-858-5832...

  • Page 12: Technical.specifications

    Crate continually develops new products, as well as improves existing ones. For this reason, the specifications and information in this manual are subject to change without notice. “Blackheart” and “Crate” are registered trademarks of LOUD Technologies Inc. All other brand names mentioned are trademarks or registered trademarks of their respective holders and are hereby acknowledged.
