IP Phone

User manual

June 25, 2005

Table of Contents

Need help?

Do you have a question about the 10 and is the answer not in the manual?

Questions and answers

Summary of Contents for ServComp 10

Page 1 IP Phone User manual June 25, 2005...
Page 2 IP Phone User manual Dear customer: First thank you to select and purchase our company's network telephone,In order to make it work at the optimum condition, please carefully read this user manual. Attention: 1. The product specification and the information mentioned in this user manual supply the reference merely.
Page 3: Table Of Contents
IP Phone User manual Catalogue Introduction ······································································································································ Suitable Users of IP Phone ··············································································································· Spec and Install ································································································································· Appearance ··················································································································································· Performance and Features ····························································································································· Installation ···················································································································································· Setting and configuration ··············································································································· Configured by keypad ································································································································· Configured by WEB···································································································································· Network Setting ····················································································································································· Audio settings ························································································································································ Dial Plan settings ···················································································································································...
Page 4: Introduction
IP Phone User manual Introduction IP is abbreviation of Internet Protocol. An IP Phone is a telephone transporting voice using grouping data package of IP protocol. It can be used widely for audio communication in the broad band IP Network environment which accord with TCP/IP protocol, such as in the LAN or WAN of Enterprises and Institutions、Telecom IP Phone services provider’s network and broad band INTERENT user, who log on internet through LAN 、Cable Modem or XDSL and so on.
Page 5: Suitable Users Of Ip Phone
IP Phone User manual Suitable Users of IP Phone IP Phone is the ideal choice for those who always place international or long distance calls. If two parties both use IP Phone, they can communicate with each other even free. ●...
Page 6: Spec And Install
IP Phone User manual Spec and Install Appearance 1. 10Model: Front Panel Fig. 1 10 Model Front Panel 2. 100 Model: Front Panel Fig. 2 100 Model Front Panel - 5 -...
Page 7 1. LCD 2. Handset 3. Curve 4. Light 5. Number 6. Speaker 7. Redial 8. Vol/+ 9. Vol/- 10. Local num 11. Local IP Redial 12 Missed 13. Answered 14. Dialed 15. Back Space 16.Phone Book 17.Transfer 18. Hold 19. Flash 20.Service IP...
Page 8: Performance And Features
Hardware ● Main chip—50MHz ● Data Memory—2MB SDRAM ● Program Memory—1 MB Flash memory ● Ethernet Port—10/100M Connectors ● AC/DC adapter—Input AC 110V or 220V OR 110--- 240V，Output 9V DC, 500mA Software ● DHCP support for LAN or Cable modem ●...
Page 9: Installation
● Support PoE ( only for 500 Model) Standard and Protocol ● IEEE 802.3 /802.3 u 10 Base T / 100Base TX ● Major G.7XX,GSM610,iLBC audio codec ● H.323 V4, MGCP RFC2705, SIP RFC3261, IAX2 Protocol, Net2phone private protocol ● TCP/IP: Internet transfer and control protocol ●...
Page 10 IP Phone User manual Insert Handset cord into handset cord jack of the base. 2. Connect Phone and Power Place the phone nearby of Power socket, Plug the power cord adapter into the Power or DC9V Jack. Then plug the other end of the power cord adapter into the appropriate power socket. 3.
Page 11: Setting And Configuration
If the errors come forth when you enter the settings, press “Backspace” key to delete it and enter the settings again. ● Abort the settings If there is no need for the modified settings, press “Redial” key to return to the main menu, and - 10 -...
Page 12 IP Phone User manual press “VOL+” or “VOL-” to page the menu up or page the menu down; When “exit settings ” “Spk” key to confirm, IP Phone will reboot and be used the submenu item is selected, press current settings. ●...
Page 13 IP Phone User manual Fig. 8 Network submenu structure Illustration Set the audio submenu ● Audio Submenu Structure Fig. 9 Audio submenu structure Illustration Set the dial plan submenu ● Dial plan submenu Structure - 12 -...
Page 14 IP Phone User manual Fig. 10 Dial plan submenu structure Illustration Set the protocol menu ● Protocol Submenu Structure Fig.11-1 H323 Protocol Fig.11-2 SIP Protocol - 13 -...
Page 15 IP Phone User manual Fig.11-3 MGCP Protocol Fig.11-4 IAX2 Protocol Fig. 11 Protocol submenu structure Illustration Set the other menu ● Other Submenu Structure Fig. 12 other submenu structure Illustration Set the Advanced menu ● Advanced Submenu Structure Fig. 13 advanced submenu structure Illustration - 14 -...
Page 16: Configured By Web
IP Phone User manual Appendix Table： Keys Press Once Press Twice Press Thrice Press quartic Press quintic space \ /& Case change Configured by WEB Double click icon to open the IE browser. Input the IP address of the phone into address bar ), and then input password of the phone into the following page.
Page 17 IP Phone User manual Fig. 15 Http Setting When debug set as 0[disable], and if input ordinary password (default one is 1234), the following page will pop up after clicking . And only those parameters can be modified. - 16 -...
Page 18: Network Setting
IP Phone User manual Fig .16 Setting Page using ordinary pin with Debug set as 0 [disable] Network Setting Fig. 17 Network Setting ● iptype: Set how IP Phone gets relevant network parameters by selecting corresponding item from drop down list. static ip: Select this item to authorize users set IP address, subnet mask and router IP address of IP Phone manually.
Page 19: Audio Settings
IP Phone User manual ● ppp id: With pppoe or modem selected in iptype drop down list, please enter the user name here. ● ppp pin: With pppoe or modem selected in iptype drop down list, please enter the password here.
Page 20 IP Phone User manual ● codec5: Set the priority 5 of the audio compression algorithm. The options are g729，g7231， g711u，g711a and gsm. ● codec6: Set the priority 6 of the audio compression algorithm. The options are g729，g7231， g711u，g711a and gsm. ●...
Page 21: Dial Plan Settings
● ddd code: With enable or dialnum selected in use dialplan drop down list, set area code according to E.164 dial rule. For example, Beijing is 10; Shanghai is 21. ● idd code: With enable or dialnum selected in use dialplan drop down list, set country code according to E.164 dial rule.
Page 22: Protocol Setting
IP Phone User manual ● forward number: Enter receiving forwarded calls phone number into this field; If the IP Phone used with modem, with modem item selected in iptype list box, and then fill ISP number into this field. ● fwd poweroff: Forward calls if power off by checking this box. Please enter receiving forwarded calls phone number into fwd number field.
Page 23 IP Phone User manual Fig.20-4 SIP protocol Fig.20 Protocol Setting ● use service: Enable/disable service by checking/clearing this box. To make calls through gatekeeper, please check this box; otherwise, phone can only make IP to IP calls or calls through gateway.
Page 24 IP Phone User manual § vfone: Use vfone’s service ● service addr : Please set the URI (domain name/IP address : service port) of the server into “service addr ”. When the default service port is used, “: service port ” can be omitted. Please note, if you use SIP protocol,this item will not appear! If “use service”...
Page 25 ● nat ttl: When IP Phone sit behind a NAT device, it will send packets to server every “nat ttl ” “nat ttl” is an integer between 10 seconds to keep the port mapping on the NAT device alive. and 65535 .default value is 20.
Page 26 224. ● register ttl : IP Phone will send a keep-alive registration message to H323 gatekeeper every “register ttl ” seconds. The value range is 10-65535. Default is 60. This setting can only appear in the H.323 protocol ●...
Page 27: Other Settings
IP Phone User manual ● dtmf: Set DTMF signal sending way by selecting inband audio, h245 string ,q931 keypad ， rfc2833，sip info，inband signal，outband signalfrom list box. ● dtmf payload: This item only apprea in SIP and MGCP protocol,it can be used to set the RTP playloay type during using RTP to send DTMF signal.
Page 28: Configured By Palmtool
IP Phone User manual ● use daylight: Enable/disable daylight. ● timezone: Select correct time zone in list box. ● Save Settings: Click this button to save the configuration and the phone will reboot. Once the phone reboots successfully, the new configuration is effective. After entering set page, if button is not clicked within 5 seconds, then when you Note...
Page 29: Usage Of The Phone
IP Phone User manual icon to open the PalmTool. The index page of PalmTool popup. 2.) Input the IP address of the phone into Local IP field (such as 192.168.1.100), and then click “Phone Settings” button. From Version1.24, use PalmTool to set the IP phone, please set debug as output or output all firstly, or PalmTool cannot connect IP phone.
Page 30 IP Phone User manual established and the ring tone has sounded, wait for the other party to answer. When the other party answers, you can begin speaking. When the call is over, put back the handset. The dialed number has been saved into the buffer. ②.
Page 31: Faq
IP Phone User manual 1.when the program in phone is being upgrading, why read-in data is not acceptable and “invalid update method” is shown? Answer: open Palmtool and choose not to check for the model of the program as the debug level. 2 .
Page 32 IP Phone User manual other than press “#” as ending when the number you dial is accord with the rules. 7.when the phone connect to the auto-telephone exchange, failed dialing to the extension occurs. Does it means extension could not be dialed any further after the telephone exchange is connected? Answer: this problem if related to the DTMF transmission.
