1553 PCI CARD
User's Manual
TEST SYSTEMS, Inc.
217 West Palmaire
Phoenix, Arizona 85021
(602) 861-1010
TEST SYSTEMS, Inc., believes this information to be accurate and reliable but assumes no
responsibility or liability arising out of the application or use of the information or product.
1553 PCI CARD User's Manual
NOTICE
The contents of this manual are for informational purposes only and
are subject to change without notice. The material in this document shall
not be reproduced in any form in whole or in part without written consent of
TEST SYSTEMS, Inc.
PREFACE
The 1553 PCI CARD provides an intelligent interface between a PCI
slot in a PC compatible computer and up to four (4) MIL-STD-1553
channels. The card is designed and manufactured by TEST SYSTEMS,
Inc., in Phoenix, Arizona. TEST SYSTEMS, Inc., is an Arizona corporation,
and has been specializing in MIL-STD-1553 test equipment since 1979.
WARRANTY
TEST SYSTEMS, Inc., warrants the equipment manufactured by
them to be free of defects in materials and workmanship for a period of 90
days from the date of shipment to the original purchaser. TEST SYSTEMS,
Inc., will replace or repair any defective part or parts, free of charge, when
the equipment is returned freight prepaid, and when examination reveals
that the fault has not occurred because of misuse or abnormal conditions
of operation. The current applicable rates will be charged for equipment
repaired beyond the effective date of warranty or when abnormal usage has
occurred. If requested, TEST SYSTEMS, Inc., will submit an estimate for
charges before commencing repair.
February 2001
ii
TEST SYSTEMS, Inc.

Advertisement

Table of Contents
loading

Summary of Contents for TEST SYSTEMS 1553

  • Page 1 If requested, TEST SYSTEMS, Inc., will submit an estimate for charges before commencing repair. TEST SYSTEMS, Inc., believes this information to be accurate and reliable but assumes no responsibility or liability arising out of the application or use of the information or product.

  • Page 2: Table Of Contents

    1553 PCI CARD Test Program ... . . bus network. The SuMMIT chip in each of the channels may be configured WINDOWS 1553 PCI CARD DLL .

  • Page 3: Software

    128K words / channel the SuMMIT and the status/control register are mapped into the upper part of memory on the module. The operation of each of the 1553 channels on Word Size: 16 bits the 1553 PCI CARD is based on the combination of the information written...

  • Page 4: Card Configuration

    Each module can be connected transformer coupled or direct where each module is a dual standby redundant MIL-STD-1553 channel. coupled to the 1553 data bus. The 1553 PCI CARD is configured from the For a single 1553 channel, one module is provided for Channel 2. For two factory to be connected to a transformer coupled stub of the 1553 data bus.
  • Page 5 1553 PCI CARD User's Manual 1553 PCI CARD User's Manual SuMMIT for LOCK, A/B STD, MODE M0 & M1 and the RT ADDRESS & 3.2.4 RT ADDRESS & PARITY PARITY. All pins except the RT ADDRESS & PARITY have jumpers on the bottom side of the module PCB which must be cut if the configuration is to The jumper pads for the RT ADDRESS &...

  • Page 6: Card Operation

    1553 PCI CARD User's Manual CARD OPERATION Status/Control Register A Block Diagram of the 1553 PCI CARD with one 1553 channel is The Status/Control Register provides additional information and shown below. The PCI Interface can control up to four 1553 channels. A control for the operation of the 1553 channel.

  • Page 7: Interrupts

    (channel status bit 2 is 'one'). The interrupt from 1553 RT status word can be set by writing to SuMMIT Register 9 or by Channel 0 and the interrupt from Channel 1 are ORed together to generate writing to the Control Register.

  • Page 8: Trigger Output

    4.6.2 Monitor With Automatic Page Switching A 1553 channel on a 1553 PCI CARD can be enabled for automatic page switching by writing a 'one' to bit 14 of the Control Register after the SuMMIT has been configured as a monitor. For proper operation of the automatic page switching, the SuMMIT must be configured with the Monitor Block Count Interrupt enabled and the Message Error Interrupt masked.

  • Page 9: Software Support

    1553 PCI CARD Test Program The 1553 PCI CARD Test Program is provided so that it can be run to verify that the 1553 PCI CARD is functioning properly.
