- Page 1 USER’S MANUAL Digital Satellite Receiver HTS 7300 HTS 7300 + E109000206A...
-
Page 2: Table Of Contents
Contents 1. Introduction 1.1 Overview 1.2 Main Features 2. Safety/Precautions 2.1 Safety 2.2 Precautions 3. Check Point before Use 3.1 Accessories 4. Controls/Functions 4.1 Front Panel 4.2 Rear Panel 4.3 Remote controller 5. How to Connect 6. Operation 6.1 Getting Started 6.2 System Setting 6.3 Channels 6.4 Guide... -
Page 3: Introduction
Introduction Safety/Precaution 1.1 Overview 2.1 Safety This satellite receiver is designed for using digital free-to-air channel reception. Enjoy the rich choice of more than 4,000 different channels, broadcasting a large range of culture, Be sure to read the user's manual before Do not touch the power cord with wet sports, cinema, news, events, etc. -
Page 4: Precautions
2.2 Precautions Check Points before Use When installing the unit 3.1 Accessories Install the unit horizontally. An uneven Do not put heavy items such as a TV installation may cause the unit to be on the unit. That may cause the unit to Accessories of this are as below damaged. -
Page 5: Controls/Functions
4.2 Rear Panel Controls/Functions 4.1 Front Panel No. Name Connector Function RF OUT UHF 21-69 IEC 169-2 male Output to TV TV ANT IN IEC 169-2 female Input from terrestrial antenna AUDIO L RCA cinch Left audio output Standby/Power on lndication Light : Flashing red on “Stand By” mode and no AUDIO R RCA cinch Right audio output... -
Page 6: Remote Controller
4.3 Remote Controller 4.3 Remote Controller Up & Down ( ) : Changes POWER : Turns the receiver On/Off. channels in non-menu mode and moves MUTE : Turns the sound On/Off. the cursor up/down in menu mode. Numeric Keys ( 0-9 ) : Controls the Left &... -
Page 7: How To Connect
How to Connect Operation 5.1 When Connecting IRD to TV with RF, AV connectors 6.1 Getting Started After your receiver is powered on, proceed with installation as follows: Connect the TV antenna to TV ANT IN Connect the RF-IN of TV to RF-OUT 1) Menu Language Setting Connect the Video and Audio of TV to the Video and Audio. - Page 8 6.1 Getting Started 6.1 Getting Started Note : When you change each parameter, you need to understand environment of connecting the receiver and antenna in order for you to set 22KHz and DiSEqC properly. After setting, press the EXIT button. 3) Satellite Scan Through this function, the receiver searches for all the available channels and saves them in the memory.
- Page 9 6.1 Getting Started 6.1 Getting Started Manual Scan <Figure 6-7> 4) Select Channel Select transponder which you want to scan. You can change the current channel to any other channel you want. If you want to change an information of current transponder ( Frequency, Symbol Rate In case you want to select a channel at random without knowing the channel name, and Polarization ) , just input information using NUMERIC button.
-
Page 10: System Setting
6.1 Getting Started 6.2 System Setting Channel Information 1) Time Setting Whenever press the INFO button, the information banner will be displayed for a few This sub menu allows you to set your local time, wake up time, wake up channel and sleep seconds. - Page 11 6.2 System Setting 6.2 System Setting - Age Limit : Prevents children or unauthorized people from watching programs. ( Free / 8 above / 12 above / 15 above / 18 above ) - Current Password : Input current password for change your password. - New Password : Input new password you want to change.
-
Page 12: Channels
6.3 Channels 6.3 Channels 1) Set Favorites This sub menu allows you to set up favorite name and favorite lists as you want. You can choose TV or Radio channels in an alternative way by pressing TV/RADIO button. This receiver support 8 favorite list. Press the on the "Set Favorites". -
Page 13: Guide
6.3 Channels 6.3 Channels 6) Delete Channels Press the on the "Lock Channels". The following menu will be displayed. <Figure 6-19> Press to select the channel that you want to lock. Lock icon will be displayed. This sub menu allows you to delete the channels. Press one more to cancel lock. -
Page 14: Games
6.4 Guide 6.5 Games 2) Timer This sub menu allows you to set the on/off time of your receiver. If you press RED button in guide menu, timer menu will be displayed. <Figure 6-23> Press the to move to other timer. Press the to change the parameter. -
Page 15: System Information
6.5 Games Trouble Shooting 3) Snake Press the on the "Snake". The following menu will be displayed. <Figure 6-28> There may be various reasons for the abnormal operation of the unit. Therefore, if the unit does You can select skill using not work properly, check it according to the procedures shown in the table below.: Press the to start game <Figure 6-29>, or press the EXIT button to return previous menu. -
Page 16: Specifications
Specifications System capabilities Fully DVB compliant Power supply Power consumption Max 20W LNB/Tuner input Connector IEC 169-24,female Supply voltage 90V - 250V ~ Frequency range 950MHz ~ 2150MHz Supply frequency 50Hz - 60Hz Video out ( CVBS, RGB ) Signal level -65dBm ~ -25dBm Rear Panel TV SCART...
