TECHNICAL BULLETIN Ri 2530/3530
Bulletin #
Ri 2530/3530-01
Affected Serial Number
From introduction
Subject
In this Bulletin, you will find Specifications and relevant Technical Information concerning the All
New Ri 2530/3530 Digital Copier/Network Printer. The Ri 2530/3530 shares the same engine and
enhancement
devices
9100DN/9500DN Technical Bulletin #1 for more details). Some special features unique to the Ri
2530/3530 are as follows:
The new Kyocera Mita designed, embedded
Print/Scan System (N) Controller
Optional Fax System (C)
32 MB standard RAM on base machine
Various enhancement Devices.
1. DF-71 (3,000 sheet Finisher w/punch)
2. DF-75 (Saddle Stitch Finisher)
3. PF-70 (Dual 500 sheet Drawers)
4. PF-75 (3,000 sheet Drawer)
5. Enhanced SRDF-2
6. STDF-3 (2530 only)
(See Page 2 for a complete list)
High Productivity
Long Life Components
Low Service Cost.
We recommend reading the Ri 2530/3530 Operation Guide to understand the full capabilities of
the Machine functions.
Training for the Ri 2530/3530 is available at our Regional Offices. The length of the class is 3 days.
Please contact your Regional Office to sign up for Training Certification.
If you have any additional questions, please contact the Copystar Diagnostic Center or email us at
support@Kyoceramita.com.
Model
Ri 2530/3530
NEW MODEL PRODUCT INFORMATION
with
the
Printer
RECOMMENDED ACTION FOR FIELD MACHINES
!
AT SETUP
!
NEXT PM
version,
the
FS-9100DN/9500DN
Ri-2530
!
NEXT SERVICE CALL
)
INFORMATION ONLY
Date
09/19/01
(see
FS-

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ri 2530 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Copystar Ri 2530

Summary of Contents for Copystar Ri 2530

  • Page 1 We recommend reading the Ri 2530/3530 Operation Guide to understand the full capabilities of the Machine functions. Training for the Ri 2530/3530 is available at our Regional Offices. The length of the class is 3 days. Please contact your Regional Office to sign up for Training Certification.

  • Page 2: Service Documentation

    $25.00 DF-75 Parts List 5FG70770 $15.00 Ri 2530/3530 Parts Price List Available on Dealernet Only Note: The 2530/3530 Service Manual contains the AD-63, DF-78, J-1402, PF-70, PF-75, RA-1 and, Fax System C Manuals. The 2530/3530 Parts List contains the AD-63, DF-78, J-1402, PF-70, PF-75, RA-1, Fax System C, and Printing System (N), Scan System (B) Lists.
  • Page 3 (TR-700) Transfer Ass’y 84395575 400,000 The Toner Cartridge is exclusive to the Ri 2530/3530. ¬ A Main Charger Cleaner and two Waste Toner Bottles are included with each Toner Kit. The Maintenance Kit contains the Drum Ass’y, Developer Ass’y, Fixing Unit and Transfer Ass’y.
  • Page 4 DF-75 B438 Note: Ri 2530/3530 Firmware is only upgradeable via CompactFlash Card . The requirements are as follows: Either a standard PCMCIA Type I & II slot, eFilm CompactFlash Type I & II Parallel Port Reader, or eFilm CompactFlash Type I & II USB Port Reader are needed to copy firmware files to the CF Card. An 8MB or larger CF Card can be used.

  • Page 5: Preventative Maintenance

    90 days from the date of its installation. Repair PCB Price includes credit issued after return of old Board. PREVENTATIVE MAINTENANCE Ri 2530 PM CYCLE Ri 2530 MAX MONTHLY VOLUME 400K prints 85K prints Ri 3530 PM CYCLE...
  • Page 6 Ri 2530/3530-01 September 19, 2001 Page 6 Ri 2530/3530 Machine Specifications Type..........Desktop Copying system ......Indirect electrostatic system Originals ......... Sheets and books Maximum size: 11" x 17" Original feed system ....... Fixed Copy paper ........Drawer: Plain paper (17~21lb.) Bypass table: Plain paper (16~53lb Bond, 53lb.

  • Page 7: Specifications

    Ri 2530/3530-01 September 19, 2001 Page 7 Ri 2530/3530 Machine Specifications (continued) Bit map memory ......9 MB (standard) Image storage memory ....23 MB (standard) ............32 MB total on Main Board Resolution ........600 x 600 dpi Light source........Inert gas lamp Dimensions........
  • Page 8 Ri 2530/3530-01 September 19, 2001 Page 8 J-1402 Specifications Type..........Enclosed Tray capacity ........100 sheets of 9.3~43lb paper Paper ..........Plain paper: 21lb. Special paper: colored paper Paper sizes........11" x 17" – 5 ½ " x 8 ½ "...
  • Page 9 Ri 2530/3530-01 September 19, 2001 Page 9 DF-75 Specifications (continued) Display ........... No Size..........26.18(W) × 24.21(D) × 21.85(H) Weight ........... 59.40 lb. (approx.) Power supply........24 VDC from host machine Maximum power consumption ..At standby: 13 W ............In operation: 84 W (staple sort) Stapling ..........
  • Page 10 Ri 2530/3530-01 September 19, 2001 Page 10 DF-71 Specifications (continued) ............When stapling 21 to 29 sheets: ............1400 sheets: 11" x 17" ............1500 sheets: 8 ½ " x 14" ............When stapling 21 to 49 sheets: ............3000 sheets: 8 ½ " x 11", 11" x 8 ½ "...
  • Page 11 ............Scanner NIC (NS-30) ............Clock PCB ............CD-ROM (Scanner Library) ............CD-ROM (Paper Port) Supporting Models ......Ri 2530/3530 Basic Function ........ Network Scanner (B/W) ............PC Transmission (with Scanner File Utility) ............E-mail Transmission ............TWAIN Scan (with TWAIN Source) Interface Card.........
  • Page 12 Ri 2530/3530-01 September 19, 2001 Page 12 Scan System Specifications (continued) Send from Selection......Max. 40 destinations, password check available Destination selection : (when sending to PC) Shared address book ..... Max 100 destinations ............Password check available ............Multiple selection: max. 20 destinations ............
  • Page 13 Ri 2530/3530-01 September 19, 2001 Page 13 Fax System (C) Specifications (continued) Modulation ........TCM, QAM, PhM Coding..........MMR, MR, MH, JBJG ............JBIG is applicable by the running change Transmission speed......33.6/31.2/28.8/26.4/24.0/21.6/19.2/16.8/14.4/ ............12.0/9.6/7.2/4.8/2.4 (KBPS) Minimum transmission time..... Normal:...

  • Page 14: Standard Memory

    2530/3530 Memory Management (Main PCB) The Ri 2530/3530 has two slots on the Main PCB (See Chart Below) with one standard 32MB DIMM. It uses 9 MB of Bitmap memory for both scanning and printing. 23MB is used for image storage.
  • Page 15 Ri 2530/3530-01 September 19, 2001 Page 15 Ri 2530/3530 Option Chart Note: The DF-71 and DF-75 require the Attachment Kit (AK-70C). It is not possible to install a DF-78 with a DF-71 or DF-75 attached. It is possible to install a J-1402 with a DF-71or DF-75.
