Page 1: User Guide
HDSR 400 Free-to-Air HD Digital Satellite Receiver USER GUIDE Please read this user guide carefully before use Customer Careline: 08457 573479 Local Rate - UK only Technical Support: www.philex.com/support... -
Page 2: Table Of Contents
8.1 To Record a Programme ..........................17 8.2 To Play or View a Recorded Programme ....................18 9. System Information ................................18 10. Technical Specification ..............................19 11. Troubleshooting ................................. 20 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 3: Important Safety Instructions
Your dish should be properly installed and azimuth and elevation must be precisely set up. This unit works with DisEqC 1.2 & 2.0 on a compatible antenna positioner. Ask your dealer for information. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 4: General Information
Please note that any software upgrades uploaded may change the functions on your receiver. Should you encounter any difficulties with the operation of your unit, please find help from the Trouble Shooting section in this manual, or call our Helpline. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 5: Front Panel
Phono sockets for standard stereo audio output 10. TV SCART - (max resolution 576i) Connects to TV/VCR using SCART 11. Power Lead AC~ 110-240V (Auto-selectable), 50-60Hz 12. Power Switch Switches the mains power on/off 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 6: Remote Control
To access your favourite channels list RECALL To switch from current to last channel viewed PAUSE To freeze the image during recording playback SUBT Yo switch between available subtitles Teletext on / off 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 7: Installing Remote Control Batteries
2. The remote control has a range of up to 7 metres from the set top box at an angle of up to 60 degrees. 3. The remote control will not operate if its path is blocked. Note: Sunlight or very bright light will decrease the sensitivity of the remote control. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 8: Receiver Connections
TV. 3). To ensure the best image quality, set the video output mode to HDTV, press the “FORMAT” button to select video resolution 1080i or 720p. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... - Page 9 Your satellite receiver is mains powered, insert the 3 pin plug into a standard UK 240V socket and switch on the socket and switch on the receiver using the switch shown below. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only...
-
Page 10: First Time Installation
Can be input with RCU numeric keys. - 22 kHz: AUTO Set the path of 0/22KHz switch box in On, Off or Auto mode. - DiSEqC : Set DiSEqC switch ON or OFF. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 11: Motorized Setting
28 satellites). 5. Press the button on the Save Current Position menu. Current position of the motor is saved according to the selected satellite. 08457 573479 Technical Support: www.philex.com/support Customer Careline: ocal Rate - UK only... -
Page 12: Channel Search
Now you have completed all the steps needed for watching programs. If you did not see any programs listed after finishing your setup, please call the Helpline shown at the bottom of the page. 08457 573479 Technical Support: www.philex.com/support Customer Careline: ocal Rate - UK only... -
Page 13: Operation
(if available). Press the BLUE button to view next day program schedule (if available). Press the EXIT button to exit the EPG menu. 08457 573479 Technical Support: www.philex.com/support Customer Careline: ocal Rate - UK only... -
Page 14: Channel Editing/Managing
2. All the channels will be listed on the left window. Select the channel you wish to edit and then press button to edit the channel you want to modify using the / , / buttons. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 15: To Move Channel
7.1 Time Setting You can set system time using this menu. Press the / buttons to select the Time Setting and press the button to enter the Time Setting menu. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 16: System Setting
: To verify the new password you have input. Note: The default Password/Pin is ‘0000’ . Write your new Password/Pin here __________ or somewhere safe where you can find it easily. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 17: Database Reset
To stop recording, press the YELLOW button and select when the prompt Want to stop recording? appears. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 18: To Play Or View A Recorded Programme
Enables you to view the software version information of this unit. Press the / buttons to select the System Information and press the OK button to display the information. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 19: Technical Specification
Power consumption 25W (operating) PYSICAL SPECS. Unit Dimension 300(W) X 230(D) X 58 (H) mm Unit Net Weight 3.5Kg Operating Temperature 5°C - 40°C Storage Temperature -40°C - 65°C 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only... -
Page 20: Troubleshooting
Please recycle where facilities exist. Check with your Local Authority for recycling advice. 08457 573479 Technical Support: www.philex.com/support Customer Careline: Local Rate - UK only © Philex Electronic Ltd. 2010. V1.3 MK42 0NX www.philex.com...
