Dalian GTH070IDW1-E00 User Manual

7.0" color tft-lcd module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SPECIFICATION
7.0"
GTH070IDW1-E00
1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GTH070IDW1-E00 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dalian GTH070IDW1-E00

  • Page 1 SPECIFICATION 7.0" GTH070IDW1-E00...
  • Page 2 Document Title GTH070IDW1-E00 Specification for Road Well Page No. 2/ 26 Document No. Revision Record of Revisions Rev. Date Sub-Model Description of change Sep, 18, 2009 Preliminary Product Specification was first issued.

  • Page 3: Table Of Contents

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 3/ 26 Document No. Revision Contents General description ……………………………….… Absolute maximum ratings …………………………. Optical characteristics ………………………………. Block diagram ……………………………..……….. p.10 Interface pin connection ……………………………. p.11 Electrical characteristics ……………………………. p.13 Reliability test items……………………………………...

  • Page 4: General Description

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 4/ 26 Document No. Revision 1.0 GENERAL DESCRIPTION 1.1 Introduction 7" TFT Display model GTH070IDW1-E is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device.

  • Page 5: Absolute Maximum Ratings

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 5/ 26 Document No. Revision 2.0 ABSOLUTE MAXIMUM RATINGS 2.1 Electrical Absolute Rating 2.1.1 TFT LCD Module Item Symbol Min. Max. Unit Note -0.3 GND=0 GND=0 Power supply voltage GND=0 AGND=0 Logic Signal Input Level -0.3...

  • Page 6: Optical Characteristics

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 6/ 26 Document No. Revision 3.0 OPTICAL CHARACTERISTICS 3.1 Optical specification Item Symbol Condition Min. Typ. Max. Unit Note － Contrast (1)(2) － Rising Response msec (1)(3) Θ=0 time － Falling...
  • Page 7 GTH070IDW1-E00 Specification for Road Well Page No. Document Title 7/ 26 Document No. Revision Note (1) Definition of Viewing Angle: Θ 12’ o’clock Φ=90 Θ Θ Φ=180 Φ=0 Θ 6’ o’clock Φ=270 Note (2) Definition of Contrast Ratio(CR) : measured at the center point of panel...
  • Page 8 Document Title GTH070IDW1-E00 Specification for Road Well Page No. 8/ 26 Document No. Revision Note (4) Definition of optical measurement setup Note (5) Definition of brightness uniformity 16.7% 83.3% 16.7% 83.3% (Min Luminance of 9 points) ×100% Luminance uniformity =...

  • Page 9: Block Diagram

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 9/ 26 Document No. Revision 4.0 BLOCK DIAGRAM 4.1 TFT LCD Module Scan LCD Panel Driver Source Driver Input 4.2 Pixel Format 1,800 LCD Display Area 1 Pixel 480 Lines 480,1...

  • Page 10: Interface Pin Connection

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 10/ 26 Document No. Revision 5.0 INTERFACE PIN CONNECTION 5.1 TFT LCD Module CN2 (Input signal): FPC Down Connector, (FH28-60S-0.5SH (HIROSE), 60pin,pitch = 0.5mm) Terminal Symbol Function AGND Analog Ground AVDD...
  • Page 11 GTH070IDW1-E00 Specification for Road Well Page No. Document Title 11/ 26 Document No. Revision Terminal Symbol Function Digital Power gate up or down scan control. UPDN="L" , DOWN shift : UPDN G1->G2…->G480 ; UPDN="H", up shift: G1<-G2…<-G480 Digital Ground AGND...

  • Page 12: Electrical Characteristics

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 12/ 26 Document No. Revision 6.0 ELECTRICAL CHARACTERISTICS 6.1 TFT LCD Module Item Symbol Min. Typ. Max. Unit Note 14.5 Supply Voltage -6.5 9.85 10.15 VCOM COMin 0.7 Vcc Note (1)
  • Page 13 GTH070IDW1-E00 Specification for Road Well Page No. 13/ 26 Document Title Document No. Revision 6.2 Back-Light Unit The backlight system is an edge-lighting type with 27 LED. The characteristic of the LED is shown in the following tables. Item Symbol Min.

  • Page 14: Document No. Revision

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 14/ 26 Document No. Revision Note (3) Suggested Schematic of LED Back-Light Driver Suggested Schematic of LED Back-Light Driver...
  • Page 15 Document Title GTH070IDW1-E00 Specification for Road Well Page No. 15/ 26 Document No. Revision 6.3 AC Characteristics Item Symbol Min. Typ. Max. Unit Note DCLK cycle time Tcph DCLK frequency fclk DCLK pulse duty Tcwh VSD setup time Tvst VSD hold time...
  • Page 16 Document Title GTH070IDW1-E00 Specification for Road Well Page No. 16/ 26 Document No. Revision 6.4 Timing Diagram of Interface Signal Tcph Tcwl Tcwh CLKIN Last Tdsu Tdhd Data First data 2nd data Last data Tesu CLKIN Tvst Tvhd Thhd Thst...
  • Page 17 Document Title GTH070IDW1-E00 Specification for Road Well Page No. 17/ 26 Document No. Revision tvpw tvfp Vertical timing...
  • Page 18 Document Title GTH070IDW1-E00 Specification for Road Well Page No. 18/ 26 Document No. Revision 6.5 Power Sequence Item Min. Typ. Max. Unit msec msec msec msec msec msec Level define Power On Sequence: VCC-> AVDD -> VGL -> VGH -> Data -> B/L Power Off Sequence: B/L->...
  • Page 19 Document Title GTH070IDW1-E00 Specification for Road Well Page No. 19/ 26 Document No. Revision 6.6 Gamma circuit ** Suggested Gamma Circuit. **...

  • Page 20: Reliability Test Items

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 20/ 26 Document No. Revision 7.0 Reliability test items Item Conditions Remark 1 High Temperature Storage Ta=+80 C, 240hrs 2 Low Temperature Storage Ta=-30 C, 240hrs 3 High Temperature Operation Ta=+70...

  • Page 21: Outline Dimension

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 21/ 26 Document No. Revision 8.0 OUTLINE DIMENSION U U nit : mm 8.1 Outline Dimension...
  • Page 22 Document Title GTH070IDW1-E00 Specification for Road Well Page No. 22/ 26 Document No. Revision BM Assembly Tolerance 0 ≦ (A’-A) ≦ 2 (mm) │B’-B│≦ 1 (mm)

  • Page 24: Package Specification

    GTH070IDW1-E00 Specification for Road Well Page No. 24/ 26 Document Title Document No. Revision 10.0 PACKAGE SPECIFICATION 10.1 Packing form (1) Package quantity in one carton: 80 pieces. (2) Carton size: 451mm×375mm×284mm. 10.2 Packing assembly drawings Material Notice (AB Flute)

  • Page 25: General Precaution

    Document Title GTH070IDW1-E00 Specification for Road Well Page No. 25/ 26 Document No. Revision 11.0 GENERAL PRECAUTION 11.1 Use Restriction This product is not authorized for use in life supporting systems, aircraft navigation control systems, military systems and any other application where performance failure could be life threatening or otherwise catastrophic.
  • Page 26 GTH070IDW1-E00 Specification for Road Well Page No. 26/ 26 Document Title Document No. Revision 11.6 Operation 11.6.1 Do not touch, push or rub the polarizer with anything harder than HB pencil lead. 11.6.2 Use fingerstalls of soft gloves in order to keep clean display quality, when persons handle the LCD module for incoming inspection or assembly.
