Summary of Contents for DiviNet Wice.box WB01-A
- Page 1 WICE.box USER MANUAL USER MANUAL WICE.box MODEL NO: WB01-A WICE.box User Manual...
- Page 2 DiviNet Access Technologies Ltd reserves the right to revise this document and to make changes in the content from time to time without obligation on the part of DiviNet Access Technologies Ltd to provide notification of such revision or change.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents Packing List -----------------------1 Installation of WICE.box -----------2 Front Panel Controls ---------------5 Remote Control -------------------6 Trouble Shooting ------------------13 Technical Specifications------------14 Service Record --------------------15 Notes -----------------------------16 WICE.box User Manual... -
Page 4: Packing List
1. PACKING LIST Please check the contents of the package immediately upon opening the sealed box and before installation. The package should contain the following: WICE.box unit Remote Control Audio Video Cable (AV Cable) User Manual If any of the items are found missing please contact where it was purchased from. -
Page 5: Installation Of Wice.box
2. INSTALLATION OF WICE.box 2. INSTALLATION OF WICE.box The installation can be done only where a WICE.MAN (RAMNet) connection is available. Authorized personnel will do this connection. The Fig.1 below shows the back panel of WICE.box. This unit works on 230VAC, 50Hz power supply. Fig.1 For televisions having AV type input, an AV cable (provided with the kit) is connected from... - Page 6 2. INSTALLATION OF WICE.box Any TV can be tuned for the WICE.box video signal by using the “TEST SIGNAL” switch when it gives vertical bars to TV. Fig.4.1 (WICE.box on DSL network) Fig.4.2(WICE.box on DSL network) Input Connectivity : For WICE.box on DSL network, as shown in Fig. 4.1, connect the input telephone line to the splitter (LINE).
- Page 7 2. INSTALLATION OF WICE.box 2. INSTALLATION OF WICE.box WICE.box and AV cable to VIDEO/AUDIO ports of WICE.box. For WICE.box on Pure Ethernet network, as shown in Fig. 4.2, connect the port line from Distribution Module to the Input of WICE.box (RAMNET port) through UTP cable.
-
Page 8: Front Panel Controls
2. INSTALLATION OF WICE.box quality. Some newer TV sets have an S-Video input facility where a suitable S-Video cable can be connected to view the picture. The same can be used to get better picture quality from a LCD projector in a home theatre. -
Page 9: Remote Control
4. REMOTE CONTROL The Remote Control of WICE.box is as shown in below. The Main menu can be seen on the TV screen by pressing the MENU button on the remote control. You may use the PROG~ or the PROG€ to change the current option from the displayed list. -
Page 10: Main Menu Options
4. REMOTE CONTROL ƒ ƒ - VOLUME DOWN Decreases volume level. +„ „ VOLUME UP It increases volume level. Note : Press ƒ ƒ - and +„ „ simultaneously to Mute the audio. To resume the audio, press either button and set the volume. - Page 11 4. REMOTE CONTROL the current movie and start new movie press K4 from remote. 7. While watching VOD if power goes off or WICE.box resets, then after booting up select VOD and enter password (default 1234). It will ask you to continue the same movie or start the new movie.
- Page 12 4. REMOTE CONTROL ESC)”. 2. Now enter the mobile number to which you need to PROBLEMS SOLUTIONS send the SMS. ? Check if the LED on the left is glowing The WICE.box 3. Press Esc key on the keyboard to go to the next does not work when power is applied.
- Page 13 4. REMOTE CONTROL 6. Enter the mobile number to which you want to forward the SMS and press ESC. (Remember not to press the Enter key). 7. The same SMS will be displayed back in confirmation to forward SMS. 8. To save the mobile number in your friend list select SAVE IN FRIEND LIST and press OK.
- Page 14 4. REMOTE CONTROL USER PASSWORDS The default passwords are Press 1234 for VOD menu. Press 3792 to get the default settings. To change the default password to your own password, press MENU key of the remote and then press SETUP key. A menu shown below will be displayed USER PASSWORD MENU 1.
- Page 15 4. REMOTE CONTROL 10. A message will be displayed “PRESS KEY SEQUENCE:” 11. Enter the key sequence 3792 and press OK from remote. 12. The WICE.box will get reset to the default settings. NOTE: The key sequence to get the default settings can not be changed.
-
Page 16: Trouble Shooting
5. TROUBLE SHOOTING PROBLEMS SOLUTIONS ? Check if the LED on the left is glowing The WICE.box does not work when power is applied. If not, check the at all AC power source. ? Check if Menu selection can be done When power is applied, the from the switches on front-panel. -
Page 17: Technical Specifications
6. TECHNICAL SPECIFICATIONS Power Source : AC 230V +/- 10%, 50 Hz Power Consumption : 8 W maximum Input Connectivity : UTP Cable to RAMNet Data Connectivity : Ethernet 10Mbps, Half-duplex S-Video : Y-C signal (mini-DIN) Composite Video : 1V p-p CCVS Audio Out : Stereo left and right channel Line level signal... -
Page 18: Service Record
7. SERVICE RECORD WICE.box User Manual... -
Page 19: Notes
8. NOTES WICE.box User Manual... - Page 20 ADDRESS: DiviNet Access Technologies Ltd. Shivdatta Plaza, Opp. Bus Depot, Paud Road, Kothrud, Pune - 411038, Maharashtra, India. : +91(20) 25284696/25286996 25284796 e-mail :enquire@divinetaccess.com info@divinetaccess.com www.divinetaccess.com for latest update of User Manual please visit “www.divinetaccess.com/manuals” Document Version : 3.0 WICE.box User Manual...
