Oakton 91100-85 User Manual

Rs-232c adapter

Advertisement

Quick Links

68X343601 Rev 1 05/07

USER GUIDE

RS-232C Adapter
(Model 91100-85)

Advertisement

Table of Contents
loading

Summary of Contents for Oakton 91100-85

  • Page 1: User Guide

    68X343601 Rev 1 05/07 USER GUIDE RS-232C Adapter (Model 91100-85)
  • Page 2: Table Of Contents

    CONTENTS Before You Begin… …………………………………1 Devices that can be used with this RS232 Adapter……1 What this adapter enables you to do…………………..1 What you need before using the adapter……………...1 Connecting Your RS232C Adapter………………….2 Setting Up Your Devices……………………………..3 Setting Up Your Thermo Devices…………………..4 91100-50 DuaLogR Set-Up…………………………….4 93210-50 and 93410-50 ThermoLogR Set-Up………..4 37003-02 HumidityLogR Set-Up………………………5...
  • Page 3: Before You Begin

    BEFORE YOU BEGIN… Devices that can be used with this RS232 Adapter: 91100-50 DuaLogR Thermocouple Thermometer 93210-50 ThermoLogR Thermister Thermometer 93410-50 ThermoLogR RTD Thermometer 37003-02 HumidityLogR Thermohygrometer pH/ ORP/ Ion/ Conductivity/ TDS/ Salinity/ Resistivity/ Dissolved Oxygen Handheld Meters: PCD 650 PC 650 &...
  • Page 4: Connecting Your Rs232C Adapter

    CONNECTING YOUR RS232C ADAPTER If you are connecting to a Laptop or computer, please use the 9-pin plug. Connect the phone jack cable to your RS232C adapter and the other end to the 9-pin connector plug or 25-pin connector plug. If using a PC, ensure that your PC is plugged into a power source or has sufficient battery power.
  • Page 5: Setting Up Your Devices

    SETTING UP YOUR DEVICES For 600 series devices: PCD 650, PC 650 & PD 650 CD 650, pH 620, 610 & 600 COND 610, 600 & DO 600 In order to start printing on your Microprinter, you must first configure your device to be compatible with it.
  • Page 6: Setting Up Your Thermo Devices

    SETTING UP YOUR THERMO DEVICES For these devices: 91100-50 DuaLogR Thermocouple Thermometer 93210-50 ThermoLogR Thermister Thermometer 93410-50 ThermoLogR RTD Thermometer 37003-02 HumidityLogR Thermohygrometer 91100-50 DuaLogR Set-Up The interval may be set to any time from once every 3 seconds to once every hour.
  • Page 7: 37003-02 Humiditylogr Set-Up

    37003-02 HumidityLogR Set-Up The interval may be set to any time from once every 4 seconds to once every hour. This example will set the thermohygrometer to print live readings once every 4 seconds. Press SETUP, then PRINT. The display indicates “minutes:seconds” with the last printing interval setup shown.
  • Page 8: Port Settings For All Other Models

    Port Settings for all other models: Baud Rate Data Bits Parity Flow Control Stop Bits 2400 8 None None 1 1) Click on OK. A red light should now be visible in the window of the RS- 232C adapter. 2) To transfer the data, click on “Transfer”. Then “Capture Text”. 3) Enter a descriptive file name and click OK.
  • Page 9: Accessories

    ACCESSORIES Order Code Part No. Description 01X344202 01X344202 RS232 (LED) Interface Adaptor (for Meter to PC/Microprinter Communication) ECMICROPRNTR01 01X230001 Serial Impact Microprinter (110 VAC) ECMICROPRNTR02 01X230002 Serial Impact Microprinter (220 VAC) ECMICROPRNTRO2CLK 01X230004 Serial Impact Microprinter with Real Time Clock (220 VAC) ECMICROPRNTRO1CLK 01X230005 Serial Impact Microprinter (110/120 VAC) power adapter...
