- Page 1 15"17"20"LCD TV / MONITOR USER'S MANUAL TFT-LCD TV High Brightness & Co ntrast NICAM/A2 Stereo Sound MODEL: Please read this manual carefully before L15SV6-A0, L17LV6-A1,L20AV6-A0 using your television and keep this manual in a good place for future reference. L17L6A-G1,L20L6A...
-
Page 2: Table Of Contents
1. Introduction ...1 2. Warnings and Cautions ... 2 3. Control Location...5 4. Remote Control Hand Unit...7 5. Control Your TV...8 6. Tuning Procedure..12 7. TELETEXT Operation ...13 8. Menu Operation ...15 9. Install the Table Bracket ..17 Install the Ferrites ...17 11. -
Page 3: Warnings And Cautions
2 Warnings and Cautions Minimum 10cm distances 20cm Warning High voltages are used in the operation of this product. Do not remove the cabinet back from your set. Refer servicing to qualified service personnel. Warning To prevent fire or electrical shock hazard, do not expose the main unit to rain or moisture. - Page 4 Caution Never stand on, lean on, push suddenly the product or its stand. You should pay special attention to children. Caution Do not place the main unit on an unstable cart stand, shelf or table. Serious injury to an individual, and damage to the television, may result if it should fall.
- Page 5 3 Main Unit Descriptions FRONT CONTROL PANEL MENU Display the menu. V- V+ ( volume down /up button) Adjust the volume or change the menu set. P- P+ (programme number down/ up button) Select a channel or select an option in the menu. TV/AV To exchange between TV and other available video inputs Power Turns the TV set on/off.
- Page 6 BACK COVER INTERFACE The figure is just for referrence, please see the real.) SCART AUDIO DC IN D-SUB IN S-VIDEO VIDEO HEADPHONE (L15SV6-A0, L17LV6-A1,L17L6A-G1) (L20L6A,L20AV6-A0) 1 . DC power cord socket 2. VGA input socket 3. S-VIDEO input socket 4. AV input socket 5.
-
Page 7: Remote Control Hand Unit
Remote Control Hand Unit Please refer indicated pages. Power/Standby (Ref;P7) Direct Access Numeric Keys (Ref.P7) Quick View (Ref.P8) SIZE (Size adjustment) SOUND SYSTEM (Ref.P10) PICTURE (Picture adjustment) SLEEP TIME (Ref.P10) Teletext (Ref.P12) GAME (Ref.P10) Sound Volume Up/Down Ref;P7 -/-- Mute (Ref.P8.) TV/AV Select (Ref;P8.) -
Page 8: Control Your Tv
Control Your TV 5-1 Power On/Off A blue indicator lights when the power is on and a red indicator lights when in the standby mode.With Mains status On, you can also turn off using Remote Control Hand Set. This status is called Stand-By mode. -
Page 9: Quick View
5-6 TV/AV Selection You can select your video source by the [TV/AV] key. 5-7 MUTE By pushing this key, sound output will be muted. Push [MUTE] again, or Volume Up/Down, and sound Volume will return. 5-8 QUICK VIEW IN TV Mode: Program will be quickly switched back to the previous Program viewed. -
Page 10: Picture Effect
5-10 Picture Effect By repeatedly pushing this key, picture effects will change as follows. DYNAMIC SOFT 5-11 SOUND EFFECT USER THEATRE 5-12 LOCK By pushing this key, LOCK menu will Appears on the screen. While entering this menu, the cursor will stay in the password, then input the password of child lock firstly, after which press [P+]/[P-]to enter other items and then... -
Page 11: Sound System
Sleep 5-13 ¿ Control the auto time of turn off. Press [¿] Following: among which 0 means to quit this function. 5-14 SOUND SYSTEM SUBCODE Double entry function key. While watching TV program, it can be used to choose the sound processing system BG I BG ,After entering the text mode, it carries out the SUBCODE function in the text. -
Page 12: Tuning Procedure
6 Tuning Procedure 6-1 Auto Search Function: Automatic Search and Memory (ASM) is available for program installation from Antenna input. Using [MENU] key on the front or [MENU] key on the Remote for ASM. A. Push [MENU] key repeatedly to select B. -
Page 13: Teletext Operation
7 TELETEXT Operation 7-1 SELECT TELETEXT MODE Select the Program which is broadcasting the TELETEXT you want to watch. Press [TEXT] key on the remote control and enter to TELETEXT mode. By this Key, mode will be changed as The overview station page or the last page viewed (in case you already watched TELETEXT at this channel previously) appears. - Page 14 7-7 TIME TELETEXT broadcasts sometimes transmit certain pages of information at particular times.To automatically display these pages when they are transmitted, ¿ select the required page number then press [ ] key the symbols T**** are displayed at the top of the screen, now enter the time of the broadcast Timed Page.
-
Page 15: Menu Operation
8 Menu Operation Menu Operation Under TV/AV/SVHS/EURO xxx Input Source 8-1 [MENU] key Push [MENU] key continuously, to scroll through the MENU selection, as follows. PICTURE 8-2 PICTURE MENU Function: Brightness, Contrast, Colour, Sharpness, Tint A. Select each function using the [P+]/[P-] keys. B. - Page 16 Press [V+] to setup minutes of auto off time, which changes as follows: F. REPEAT Setup the effective times of auto on and auto off. EVERYDAY means the setup is effective everyday 8-5 setup Function: other functions setting A.LANGUAGE:Language setup. Press[V+]/[V-], language will switch follows English Francais...
- Page 17 Item: To adjust screen contrast. Item: To adjust screen brightness. Item: To adjust the sampling clock of the system for input signal. Item: To adjust the sampling phase of the system for input signal. Item: To adjust the horizontal place of the picture. Item: To adjust the vertical place of the picture.
-
Page 18: Install The Table Bracket
9 Install the Table Bracket Face the LCD screen upside down on a clean blanket or the bracket and pay attention not to indent the casing . Offload the 4 Mx8 screws in the bracket,and you can fix the bracket with them. And the other product please take this for reference. -
Page 19: Television Installation
Television Installation 1 Use 75 coaxial cable plug or 300-75 in antenna input terminal on the rear of the cabinet. 2 Connect the video facility to the audio, video in jack on the rear of the cabinet. VHF antenna UHF antenna 75 W Co-axis cable Mixer Battery installation and replacement for remote control unit... -
Page 20: Trouble Shooting
12 Trouble Shooting Before arranging for service, firstly know the status and then check simply as follows: Problems No picture or sound. Picture is OK, no sound. Remote control doesn't work No TV signal. No external video signal. Picture lacks colour or picture too dark. -
Page 21: Specifications
13 Specifications Specifications of the television that you have just purchased may vary from the information in this table due to technical innovations. Dimensions Model (WXDXH mm) 552X210X440 L20AV6-A0 552X210X440 L20L6A 419X170X353 L15SV6-A0 490X170X355 L17LV6-A1 445X210X395 L17L6A-G1 Picture, sound system Antenna input impedance Audio output... - Page 22 V0.1 0090506268...
