Summary of Contents for Tibo TI420
-
Page 1: User Guide
Turn it back on User Guide TI420 Please read this user manual carefully before using your TI420 Hi-Fi system and retain for future reference. -
Page 2: Table Of Contents
DAB/FM Tuner connections ......... . . 7 CONNECTING A TV TO THE TI420 Option 1 . -
Page 3: Safety
Turn it back on SAFETY Safety precautions A triangle with a A triangle with an ex- The symbol for a lighting symbol draws clamation mark draws CLASS II (double the user’s attention to the user’s attention to insulation) product. “dangerous voltage” important instructions without insulation in the cabinet, for use and maintenance in the ac-... -
Page 4: Important Safety Instruction
Turn it back on SAFETY Important safety instructions Penetration of objects and liquid Never push any foreign objects through the openings into the unit, as they may touch dangerous voltage points or short-circuit parts and cause fi re or an electric shock. Do not spill liquid onto the unit. Accessories Do not place the unit on unstable surfaces such as a trolley, stand, tripod, shelf or table. -
Page 5: Included In The Box
Turn it back on INCLUDED IN THE BOX Accessories Included with this TI420 Hi-Fi system are the following accessories: Box 1 1 x User Manual 1 x Quick Start Guide 1 x TI420 CD Player 1 x TI420 DAB/FM Tuner... -
Page 6: Setting Up The System
Turn it back on SETTING UP THE SYSTEM Connecting to the mains TI 420 BT/AMPLIFIER TI 420 CD-PLAYER TI 420 DAB/FM TUNER Audio connection layout Speakers (right) (left) Turntable (optional) DAB/FM Tuner TI 420 DAB/FM TUNER DVD Player (optional) Active subwoofer (Optional) CD Player TI 420 BT/AMPLIFIER... -
Page 7: Bt / Amplifi Er Connection
CD Player TI 420 CD-PLAYER 1. Stereo output: Analogue stereo output. For connection to the TI420 BT/AMPLIFIER. 2. AC input: For connection of the mains input. Make sure that the plug has been correctly inserted into the wall outlet. -
Page 8: Connecting A Tv To The Ti420
CONNECTING A TV TO THE TI420 Option 1 How to connect without a scart adaptor? 1. Connect a line cable L/R to TI420 BT/Amplifi er – Line-in. 2. Connect a 3.5 mm end to headphones output on a TV. Headphones out on TV TI420 BT/Amplifi er Note: RCA audio to 3.5 mm jack cable not included. -
Page 9: Remote Control
Turn it back on REMOTE CONTROL Installation of batteries 1. Remove the cover as illustrated. 2. Position two batteries of 3. Replace the cover. the type AAA in the battery compartment. Make sure that the polarity of the batteries is correct (see drawing at bottom of the remote control). -
Page 10: Remote Control Functions
22. DAB/FM: To activate the TI420 DAB and FM function. 23. Bluetooth: To activate the Bluetooth audio function. 24. CD: To activate the TI420 CD Player and the TI420 AMP on and selects the CD input on the TI420 BT/AMP. -
Page 11: Amplifier
14. Headphone: 6 mm jack that suits most headphones. Using the function menu The TI420 AMP features a “function menu” that allows the adjustment of the following when accessed via the remote: Bass, Treble, Balance and Loudness (see menu structure on right side). A description of the individual functions will follow on the next few pages. -
Page 12: Bass
Turn it back on AMPLIFIER Bass This amplifi er features a bass control that allows adjustment of the bass level. Please note that the high bass boost level offered by the bass control may lead to permanent damage to your loudspeakers if high volume is used for prolonged period of time. 1. -
Page 13: Dab/Fm Tuner
Turn it back on DAB/FM TUNER Front panel TI 420 DAB/FM TUNER Mains switch: Used to turn On/Off the mains power. LED indicator: Lights up blue when the amplifi er is turned On. Lights red in standby mode. Control/Tuning: Used to switch between the tuned in DAB stations. Manual tuner in FM mode. Press the button to select the DAB station. -
Page 14: Info And Function
Turn it back on DAB/FM TUNER Info and function 1. As this tuner can receive both normal FM radio and DAB (Digital Audio Broadcasting), it features a function that can switch between the two reception types. To switch between DAB and FM, you must either press the DAB/FM button on the front panel or the DAB/FM button on the remote control. -
Page 15: Fm Tuning - Automatic
FM tuning The TI420 DAB offers both manual and automatic tuning on the FM band. This makes it possible to save just one specifi c channel. It also makes it possible to adjust the supplied antenna for the best possible signal. -
Page 16: Cd Player
Turn it back on CD-PLAYER Front panel TI 420 CD-PLAYER Mains switch: Used to turn On/Off the mains power. LED indicator: Lights up blue when the amplifi er is turned On. Lights red in standby mode. Rewind/Forward: Fast forward and reverse. Program: Play the tracks of a CD in a programmed order. -
Page 17: Load A Disc
Turn it back on CD-PLAYER Load a disc If you want to play a disc, you must load a CD. You do this by pressing the eject button the remote control or on the front panel of the CD player. When the disc has been read, the display will show the number of tracks on the disc and the total playback time. -
Page 18: Previous/Next
Turn it back on CD-PLAYER Previous/Next When a CD track is being played it is possible to switch to the previous track or to the next track. If you want to continue to the next track, you must press the >>| (next) button on the remote control or on the front panel once. -
Page 19: Loudspeakers
Loudspeakers positioning Ideally the TI420 loudspeakers should be positioned at least 50 cm from a rear wall, 1 meter from a side wall and at least 2 metres apart. The space between the two loudspeakers and the distance form the listeners are important. -
Page 20: Technical Data
Turn it back on TECHNICAL DATA Amplifi er 150 Watts Max. power consumption: > 90 dB Signal to noise ratio: 2 x 50 Watts Power output: +/- 14 dB Tone controls - Bass: +/- 14 dB Tone controls - Treble: <... -
Page 21: Trouble Shooting
The unit is positioned on an unstable surface. The display on the DAB does not show DAB information. The TI420 DAB has not found any stations on DAB. The selected station does not broadcast any information. The antenna signal is poor (see page 13). -
Page 22: Index
CONNECTING A TV TO THE TI420 | Option 1 ....... . -
Page 23: Contacts
Turn it back on CONTACTS Tibo Ltd. DSV House Maidstone Road Milton Keynes MK10 0AJ United Kingdom tel.: +44 (0) 845 2711 906 e-mail: info@tibo-electronics.com Proof of purchase (attach your receipt here). - Page 24 Turn it back on www.tibo-electronics.com...
