15-1283.fm Page 7 Thursday, July 15, 1999 2:19 PM
3. Connect the 75-ohm coaxial cables to the RF Modu-
lator following these guidelines:
• If your TV is already connected to another VHF
input source (such as cable TV, VCR, etc.):
RF Modulator
Ant In
CATV
a. Disconnect the input source's 75-ohm cable from
the TV's 75-ohm VHF input terminal, and recon-
nect it to the RF Modulator's
RF Modulator
Ant In
Reconnect
here
CATV
b. Then add a 75-ohm coaxial cable connected
between the
TO TV
tor and 75-ohm VHF input terminal on your TV.
TV
VHF
To TV
75 Ohm
300 Ohms
Disconnect
from here
terminal.
ANT IN
TV
VHF
To TV
75 Ohm
300 Ohms
Add this
cable
terminal on the RF Modula-
7
