EZ100 PC/SC Series

Smart Card Reader

User's Manual

V1.3

Version: 1.3

Date: December 04, 2000

Castles Automation Co., LTD.

Tel: 886 (2) 2648-5929

Fax: 886 (2) 2648-5928

E-Mail: casauto@casauto.com.tw

Web: www.casauto.com.tw

Table of Contents

Need help?

Do you have a question about the EZ100 PC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Castles Automation EZ100 PC Series

Page 1: Smart Card Reader
EZ100 PC/SC Series Smart Card Reader User’s Manual V1.3 Version: 1.3 Date: December 04, 2000 Castles Automation Co., LTD. Tel: 886 (2) 2648-5929 Fax: 886 (2) 2648-5928 E-Mail: casauto@casauto.com.tw Web: www.casauto.com.tw © Castles Automation Co., LTD. 1999-2000 All rights reserved...
Page 2: Table Of Contents
K-TYPE ........................14 SOFTWARE INSTALLTION ...............15 A. EZ100PR PC/SC D ........16 RIVER NSTALLATION Windows 95/98: ....................16 Windows NT4.0:....................21 Windows 2000: ....................22 B. EZ100PK PC/SC D ........27 RIVER NSTALLATION Windows 95/98: ....................27 1999~ Castles Automation Co., Ltd.. All rights reserved. 2 / 42...
Page 3 EZ100 PC/SC User’s Manual V1.3 Windows NT4.0:....................27 Windows 2000: ....................30 Part 1:......................30 Part 2:......................36 APPENDIX A:......................42 TECHNICAL SPECIFICATIONS..............42 1999~ Castles Automation Co., Ltd.. All rights reserved. 3 / 42...
Page 4: Warning
Castles Automation Co., LTD. All trademarks mentioned are proprietary of their respective owners.
Page 5: Introduction
Note: All the EZ series IC card readers can do both read and write functions to IC cards. However, the term “card reader” or “reader” is usually and commonly in use for this kind of devices. 1999~ Castles Automation Co., Ltd.. All rights reserved. 5 / 42...
Page 6: Features
Automatic detection for memory card or smart card n IC card interface short circuit protection n Push-Pull type IC card acceptor, insertion cycle >= 200,000. n LED indicator indicates reader’s status. 1999~ Castles Automation Co., Ltd.. All rights reserved. 6 / 42...
Page 10: Ic Card Interface
The EZ100PK/PR PC/SC reader provides a push-pull type of card acceptor. It has guaranteed 200,000 insertion cycles. D. Card Insertion Detection There is a card detecting switch in the IC card acceptor to detect the card is present or absent. 1999~ Castles Automation Co., Ltd.. All rights reserved. 10 / 42...
Page 11: Led Indicator
The EZ100PK/PR PC/SC reader provides a mechanism to protect itself from being damaged by the short circuit caused by a bad card or other objects. The current limit mechanism will shutdown the card interface once it detects an over-current. 1999~ Castles Automation Co., Ltd.. All rights reserved. 11 / 42...
Page 12: Supported Card Types
Simens SLE4418/4428 compatible memory cards u Simens SLE4432/4442 compatible memory cards Philips 2042 C memory cards ATmel AT88SC153, AT88SC1604, AT88SC1608, AT24CXX SCS-Thomson ST14C02C, ST14C04C Xicor X24026, X24165, X24645 1999~ Castles Automation Co., Ltd.. All rights reserved. 12 / 42...
Page 13: Smart Cards(Asynchronous Interface)
D (CODED BY DI) 0000 Internal 1,2,4,1/2,1/4 0001-372 1,2,4,1/2,1/4 0010-558 1,2,1/2 0011-744 1,2,4,8,1/2 0100-1116 1,2,4 0101-1488 1,2,4,8,16 0110-1860 2,4,8 1001-512 1,2,1/2 1010-768 1,2,4,8,1/2 1011-1024 1,2,4 1100-1536 1,2,4,8,16 1101-2048 2,4,8 1999~ Castles Automation Co., Ltd.. All rights reserved. 13 / 42...
Page 14: Interface
The following communication parameters are used by EZ100PR PC/SC Transmission protocol : Serial asynchronous Start Bits Parity none Data Bits Stop Bits Baudrate 19200bps K-TYPE EZ100PK PC/SC uses standard IBM PS/2 compatible interface. ® 1999~ Castles Automation Co., Ltd.. All rights reserved. 14 / 42...
Page 15: Software Installtion
Manager in Windows 2000. To start the resource manager: 1.Login with Administrator. 2.Enter MyComputer / Control Panel / Administrator Tools / Services 3.Find “Smart Card” service and Start it. 1999~ Castles Automation Co., Ltd.. All rights reserved. 15 / 42...
Page 16: Ez100Pr Pc/Sc Driver Installation Step-By-Step
EZ100 PC/SC User’s Manual V1.3 A. EZ100PR PC/SC Driver Installation Step-by-Step Windows 95/98: Step1: Plug the reader into a serial port. Step2: Start the Device Manager(right-click MyComputer, select Properties select Device Manager tab). 1999~ Castles Automation Co., Ltd.. All rights reserved. 16 / 42...
Page 18 Insert the Driver-CD into a CD-ROM Drive. Select “Search for the best driver for your device” then click <Next>. Step6: Specify a location for wizard to search. Specify the path to ”(CD-Rom Drive):\Drivers \EZ100PR\Win9x”. 1999~ Castles Automation Co., Ltd.. All rights reserved. 18 / 42...
Page 19 EZ100 PC/SC User’s Manual V1.3 Step7: Installation Wizard will find “ezpr_98.inf” in the location, then click <Next>. Step8: Installation Wizard will start the driver automatically, then click <Finish> 1999~ Castles Automation Co., Ltd.. All rights reserved. 19 / 42...
Page 21: Windows Nt4.0
Press <Next> when it shows the "Start Copying Files" dialog. Step4: Press <Finish> when it shows the "Setup Complete" dialog. Step5: Choose the "Y es, I want to restart my computer now" to restart your computer. 1999~ Castles Automation Co., Ltd.. All rights reserved. 21 / 42...
Page 22: Windows 2000
EZ100 PC/SC User’s Manual V1.3 Windows 2000: Step1: Plug the reader into a serial port. Step2: Start the Device Manager (right-click MyComputer, select Properties, select Hardware tab, and click <Device Manager>). 1999~ Castles Automation Co., Ltd.. All rights reserved. 22 / 42...
Page 23 EZ100 PC/SC User’s Manual V1.3 Step3: Select “Scan for hardware changes” from the Action menu. Step4: The Found New Hardware wizard will appear, then click <Next>. 1999~ Castles Automation Co., Ltd.. All rights reserved. 23 / 42...
Page 24 EZ100 PC/SC User’s Manual V1.3 Step5: Select “Search for a suitable driver for my device”, then click <Next>. Step6: Select “Specify a location”, then click <Next>. 1999~ Castles Automation Co., Ltd.. All rights reserved. 24 / 42...
Page 25 Specify a location to where the driver located. Specify the path to ”(CD-Rom Drive):\Drivers \EZ100PR\Win2k”. Step8: Wizard will find the ezpr_w2k.inf and start to install the driver, then click <Next>. 1999~ Castles Automation Co., Ltd.. All rights reserved. 25 / 42...
Page 26 EZ100 PC/SC User’s Manual V1.3 Step9: Wizard will start the driver automatically, then click <Finish> Finish: EZ100PR-PC/SC is shown in Device Manager, in the SmartCardReaders category. 1999~ Castles Automation Co., Ltd.. All rights reserved. 26 / 42...
Page 27: Ez100Pk Pc/Sc Driver Installation Step-By-Step
EZ100 PC/SC User’s Manual V1.3 B. EZ100PK PC/SC Driver Installation Step-by-Step Windows 95/98: Windows NT4.0: Step1: Plug the reader into PS/2 port. Step2: Execute "(CD-Rom Drive):\Drivers\EZ100PK\Win9x_WinNT4\Setup.exe" 1999~ Castles Automation Co., Ltd.. All rights reserved. 27 / 42...
Page 29 “Y es,I want to restart computer now” to restart the system, or choose “No,I will restart my computer later“ to finish the installation. Note : We suggest to click <Finish> directly to restart the system. 1999~ Castles Automation Co., Ltd.. All rights reserved. 29 / 42...
Page 30: Windows 2000
Part 1: Step1: Start the “Device Manger”(right-click MyComputer, select Properties, select Hardware tab, and click <Device Manger>) Step2: Select Keyboard category, right click the keyboard installed, and select Properties. 1999~ Castles Automation Co., Ltd.. All rights reserved. 30 / 42...
Page 31 EZ100 PC/SC User’s Manual V1.3 Step3: Select the Driver tab, and click <Update Driver>. Step4: When the welcome message shows, click <Next> to continue. 1999~ Castles Automation Co., Ltd.. All rights reserved. 31 / 42...
Page 32 Select "Display a list of the known drivers for this device so that I can choose a specific driver", then click <Next>. Step6: Select “Show compatible hardware “, and click <Have Disk> to specify where the driver is. 1999~ Castles Automation Co., Ltd.. All rights reserved. 32 / 42...
Page 33 EZ100 PC/SC User’s Manual V1.3 Step7: Specify a location for wizard to search. Specify the path to ”(CD-Rom Drive):\Drivers \EZ100PK\Win2k”. Step8: Select "Keyboard that needs filtering for EZ100PK", then click <Next>. 1999~ Castles Automation Co., Ltd.. All rights reserved. 33 / 42...
Page 35 EZ100 PC/SC User’s Manual V1.3 Step11: System will ask to restart the system, click <Y es> to restart.(Driver needs to restart system in order to work properly). 1999~ Castles Automation Co., Ltd.. All rights reserved. 35 / 42...
Page 36: Part 2
EZ100 PC/SC User’s Manual V1.3 Part 2: Step1: Plug the reader to PS/2 port. Step2: Start the “Hardware Wizard”(right-click MyComputer, select Properties, select Hardware tab, and click <Hardware Wizard>) 1999~ Castles Automation Co., Ltd.. All rights reserved. 36 / 42...
Page 37 EZ100 PC/SC User’s Manual V1.3 Step3: When the welcome message shows, click <Next> to continue. Step4: Select "Add/Troubleshoot a device", then click <Next>. 1999~ Castles Automation Co., Ltd.. All rights reserved. 37 / 42...
Page 38 Select “Add a new device” , then click <Next>. Select "No, I want to select the hardware from a list", then click <Next>. Step6: In "Hardware Type " page, select "Other devices", then click <Next>. 1999~ Castles Automation Co., Ltd.. All rights reserved. 38 / 42...
Page 39 EZ100 PC/SC User’s Manual V1.3 Step7: Click <Have Disk> to specify where the driver is. Step8: Specify a location for wizard to search. Specify the path to “(CD-Rom Drive):\Drivers \EZ100PK\Win2k” then click “OK” 1999~ Castles Automation Co., Ltd.. All rights reserved. 39 / 42...
Page 40 EZ100 PC/SC User’s Manual V1.3 Step9: Select "EZ100PK PC/SC Smart Card Reader", then click <Next>. Step10: Click <Next> to continue, and follow the instruction shown in wizard. 1999~ Castles Automation Co., Ltd.. All rights reserved. 40 / 42...
Page 41 EZ100 PC/SC User’s Manual V1.3 Finish: Click <Finish> to finish the part 2 installation. After finishing the installation, Device Manager will look like the picture below. 1999~ Castles Automation Co., Ltd.. All rights reserved. 41 / 42...
Page 42: Appendix A
EZ100PR: Y-type cable with female D-SUB 9 pin connector and combined with a T-type cable for power O.S. Supported Windows NT4.0,Windows 2000,Windows95/98,Windows ME Environmental Operating Temperature ¡G 0~50 Storage Temperature ¡G -35~70 Operating Humidity¡G 20 ~90 1999~ Castles Automation Co., Ltd.. All rights reserved. 42 / 42...
