Sonic Safety HG-1500 Owner's Manual

Wireless safety and security system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Sonic
Sonic Safety
Safety
Wireless Safety and Security System
HG-1500 System
For System Package
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HG-1500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sonic Safety HG-1500

Summary of Contents for Sonic Safety HG-1500

  • Page 1 Sonic Sonic Safety Safety Wireless Safety and Security System HG-1500 System For System Package OWNER’S MANUAL...

  • Page 2: Table Of Contents

    Table of Contents Introduction (HG-1500) … … … … … … … … … … … … … … … … … … … … … … .. System Package … … … … … … … … … … … … … … … … … … … … … … .
  • Page 3 Important Safety Instruction WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE OR POWER ADAPTER TO WATER OR MOISTURE Read Instructions – All the safety and operating instructions should be read before operating this equipment. These instructions should be retained for future reference Heed Warnings –...

  • Page 4: Introduction (Hg-1500)

    Introduction Thank you for choosing the Sonic Safety wireless security system. The HG-1500 system is a high-quality, reliable and versatile security system. This system provides both two-way voice communication and built in Auto-dialer function. To ensure the best performance of your system, please read this manual thoroughly and follow the precautions and instructions presented.

  • Page 5: Planning For Installation

    Planning for Installation The HG-1500 system is designed to be as flexible as possible in order to meet your present needs, and also to adapt as your needs change. For this reason, we recommend that you read the following information and plan your system before installing devices.

  • Page 6: Setting The Antenna

    Setting the Antenna Carefully extend the antenna upward in order to maximize the range of communication between sensors and the Main console. Mounting the Main Console The Main Console may be set on a table top, or mounted on a wall. To mount the console on a wall, follow these steps.

  • Page 7: About The Main Console Operation

    Please review the illustration below which labels all of the parts of the Main Console. LCD Panel Illustration WIRELESS SECURITY SYSTEM Sonic Safety HG-1500 LEGEND TWO-WAY VOICE COMMUNICATION 1. LCD PANEL 2. ARMED LED 3. POWER LED 4.

  • Page 8: Terminal Block Function Illustration

    Install the Main Console Terminal Block Function Illustration HG-1500 BACK CABLE OUT LEGEND RESET SWITCH TAMPER SWITCH VOICE/DTMF JUMPER PULSE TONE SWITCH TERMINAL BLOCK DC INPUT JACK TEL JACK RECHARGEABLE BATTERY BATTERY CONNECTOR 1. Reset button Press reset button to back to factory defaults 2.

  • Page 9: Function For Installer-Factory Default Password

    Place the rechargeable battery to the proper position Function for Installer – Factory Default Password :123456 1. Enter password to start the menu. LCD shown as below (Enter the password and do the function setting according to your needs) Code : ****** Pass Install Mode ?? Incorrect password entered will show “...
  • Page 10 3. Select the Number setting (Remember to press Cancel after each task) 0 -SET Function menu : Press 0 to start setting Setting : 0 – T 1 2 3 4 5 6 – P 7 – MSG 8 – DIAL 9 - CODE (1) 0-T : For time setting (Default is 30 seconds.) minimum 1 second, maximum 255 seconds.
  • Page 11 (3) 7- MSG : To set recorded message which contains 4 segments of different recorded messages and each segment is maximum to 15 seconds. If the recorded message is less than 15 Secs, press ENTER to end the recorded message. When alarm is triggered, it will play one of the first 3 segments depending on what sensor designated and next together with Msg 4 recording.
  • Page 12 (5) 9 – CODE : To change password. (factory defaults, Install code 1-123456, Master code 2-135246). If you want to change the password, key-in 6 digits and will automatically show “OK”( max set 6 digits), if the word is less than 6 digits, you can press ENTER after key-in the number and it will show ”OK”.
  • Page 13 2. Door / Window Detector ( HG-123/HG-122/HG-124) : First to install Battery and let the magnetic switch from close to open, the led will light on for 1 Sec, The sensor will be learned into main console. 3. Remote Control handset (SR-119) : First to install Battery and press PANIC button, the led will light on for 1 Sec, The sensor will be learned into main console.

  • Page 14: Function For Master-Factory Default Password

    into the main console. Press 2 to go into overlay learning mode. Learning : OVER Overlay Num : xx 3. CLR : Clear Sensors (clear 1 - Single zone or 2 - All zones). Select 1- Single, you can key-in learned sensor order code and press ENTER .

  • Page 15: Check Function

    ?? When the password is incorrect, It will introduce Beep … Warning sound. LCD display shown as below. Access Denied ?? If the password is correct, It will introduce a long Beep sound. LCD display shown as below. MASTER A-AWAY H-HOME * -CODE You can select the arm mode to set as below: A - AWAY : Press AWAY button to set “...

  • Page 16: Panic Alert Function

    Check : 0 – T : To review (1- Exit) Exit time, (2-Alarm) Alarm time, (3- Entry) Entry time. 123456 – P : To review phone number sets. 7 – MSG : To review recorded message (Press number key will play back the recorded message).

  • Page 17: Two-Way Voice Communication

    Two-Way Voice Communication Operation method: Main console to remote party ?? When the remote party receives the main console emergency help call, they will hear the recorded message (which is stored in main console). If you want to know what happened, press number on the phone then you can communicate with occupants or threaten the intruder via Main Console.

  • Page 18: Setting The Alarm Sound On/Off

    ENTER again will read next message… etc. DOOR SENSOR Open When Backup Battery is in battery low condition HG-1500 Backup Bat Low Press CANCEL button to delete all ‘ MSG’ . It will show as below. MESSAGE DELETED Setting the Alarm Sound ON/OFF To turn ON/OFF alarm sound, it depends on what you need.

  • Page 19: Hg-120 Pir Motion Detector

    HG-120 PIR Motion Detector The PIR Motion Detector is designed to detect the movement of object in rooms or hallway. The effective range of the motion sensor is 10 metres, and with an 84 degree horizontal angle. Before using the sensor, the sensor needs to be learned into main console. If main console is armed in HOME mode.

  • Page 20: Installing The Motion Sensor

    SENSOR battery Zone Address Setting Enter the Installer password and the main console is in learning mode, after installing the battery on the PIR. Set the power switch from “ OFF ” to “ C ” position. In the PIR panel, The red LED will blink for 1 sec, It means to transmit out a signal for 1 sec or to activate PIR sensor by detecting people pass by, then the Main Console emits one ‘Beep’...
  • Page 21 To install the Motion Sensor, please follow these steps: ?? Take out the screws or double sided adhesive and install the mounting bracket on the wall. press the ball joint portion into the bracket until it snaps securely.( To secure the mounting bracket to the wall at 2 meters above the floor).

  • Page 22: Hg-122/Hg-123 Door/Window Detector

    HG-122/123 Door/Window Detector The magnetic Door/Window detector is a contact sensor applied on door or window. When the magnetic contact is opened (broken) or the battery low, the sensor will send out a signal to main console. The message from the triggered sensor can be read from the Main Console’s LCD display.
  • Page 23 Zone address setting You can set the sensor (HG-122/HG-123) as “ Door “ or “ Window “ detector by using the jumper selector. If you want to set the sensor as Door sensor, put the Jumper on side marked “D”. (If Jumper set on side marked “W”, the sensor becomes a Window sensor). HG-123 DOOR / WINDOW SELECT HG-122 DOOR / WINDOW...
  • Page 24 ?? Window battery cover opened Door battery cover opened WINDOW SENSOR DOOR SENSOR 01 Tamper 01 Tamper Installing the Door/Window Detector Installing for HG-122: To install a Door/Window Detector, follow these steps: 1. Before installing the sensor, ensure the sensor has been learned in main console successfully 2.
  • Page 25 INSTALLING POSITION REFERENCE FOR HG-122/HG-123...

  • Page 26: Sr-119 Remote Control Handset

    SR-119 Remote Control The key chain Remote Control is a convenient way to arm ( Home / Away mode) or disarm this system. Before using the sensor, it is necessary to learn into main console. LEGEND 1. TRANSMIT LED : When any button pressed on remote, LED will light 2.

  • Page 27: Ss-207 External Siren And Strobe Light

    External Siren and Strobe Light The system can operate an external siren and strobe light is an optional accessory. The device is an important deterrent to intruders. When the siren is installed and the system is set to Arm, it will emit a piercing 115 decibel siren when any sensor is triggered. The console can power the siren and light as long as they remain under 500mA otherwise another power source is required.

  • Page 28: Lcd Display On The Main Console For Wire Sensors Message

    LCD display on the Main Console for wire sensors message Connect the wire sensor to Terminal ( HELP , SMOKE , BGL ) and GND. Refer to page 7. If the wire sensors triggered, you can check the message on the LCD display. Once wire sensor triggered, the message shown as below ?? Wire sensor help triggered.

  • Page 29: Specifications Of Hg-1500 System

    Specifications of HG-1500 System Items Specifications Frequency - 303 / 433Mhz Power Source - 240V DC12V 1000mA adapter Power Consumption 70mA (idle), 300mA (activated) Burglary : NC (normal close) /1 Wired Input Trigger - Smoke : NC (normal close) /1...

  • Page 30: Summary Of Hg-1500 Programmed

    Summary of HG-1500 Programmed Use the following form to record your programming choices for future reference. Item Descriptions Install Code Master Code Exit Time Alarm Time Entry Time Auto-dialing Mode Sensor No. of Learning Preset Telephone No. for Auto-dialing : No.

  • Page 31: Summary Of Sensor And Zones Setting

    Summary of Sensors and Zones Setting Use the following form to record the setting details of sensors for future reference. For example Learn Install Place Posi Comment Learn Install Place Posi Comment tion tion 2F-xx room Learn Install Place Posi Comment Learn Install Place Posi...
  • Page 32 LCD Display – Master Setting Structure 01 HOME SECURITY Disarmed (Enter Master Password: 135246-default) Code : ****** Pass Master Mode : Master A-AWAY H-HOME *-CODE 01 HOME SECURITY 01 HOME SECURITY Setting : Codes Armed AWAY Armed HOME 1-ID 2-Central Setting: ID Mode 1 Setting: Centr.

  • Page 33: Lcd Display - Installer Setting Structure

    01 HOME SECURITY Disarmed LCD Display – Installer Setting Structure Code : ****** Pass (Enter Install Password: 123456-default) Install Mode : Learning : 0-SET 1-SEQUE 2-OVR 3-CLR Learning: Sequent etting : Trigger Sensor : 01 123456-P 7-MSG 8-DIAL 9-CODE Learning: Over Overlay Num: Setting Time Setting: Message Rec...
  • Page 34 LCD Display – Checking Mode Structure CHECK Press Button Check : 123456-P 7-MSG 8-DIAL *-CODE Check Time Check:Message Play Check: Codes Sel Msg: 1 2 3 4 1-ID 2-Central 1-Exit 2-Alarm 3-Entry Check:Message Play Check: ID Mode Check: Centr. Code Sel Msg: 1 Sec Check: Time Check: Time...
