Summary of Contents for Amprobe LAN-1
- Page 1 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com LAN-1 Lan Cable Tester Users Manual...
- Page 2 LAN-1 Lan Cable Tester Users Manual LAN1_Rev001 © 2008 Amprobe Test Tools. All rights reserved.
- Page 3 REMOTE TERMINATOR 1 2 3 4 5 6 7 8 G HOLD ➊ ➑ RJ45 jack for sourcing end BATTery TeST button. (oUT). ➒ hoLd button. ➋ RJ45 jack for receiving end (iN). ➓ MANUal scan button. ➌ Led indicators for sourcing end Low BATTery indicator.
-
Page 4: Table Of Contents
LAN-1 Lan cable tester CoNtENtS Symbols ........................5 Unpacking and inspection ..................5 introduction ......................5 operation ......................6 Loopback Test (cable with both ends in one location) ........6 Remote Test (cable with both ends at different locations) ......6 hold ........................6 Test examples ......................7 Specifications ......................7... -
Page 5: Symbols
BNC to female BNC connector Users Manual if any of the items are damaged or missing, return the complete package to the place of purchase for an exchange. INtRodUCtIoN The LAN-1 Cable Tester is designed for testing opens, shorts and miswired cable installations . -
Page 6: Operation
BATT to verify proper operating voltage. The BATT Led will not light and LAN-1 will not operate correctly if battery is below 7 volts. green Leds are the source indicators. Red Led’s are the test indicators. -
Page 7: Test Examples
tESt ExAmPLES Continuity green o n o o o o o o o pin 2 has continuity 1 2 3 4 5 6 7 8 g o n o o o o o o o open green o n o o o o o o o pin 2 is open 1 2 3 4 5 6 7 8 g o o o o o o o o o Short green... -
Page 8: Maintenance And Repair
1. Turn off the meter and slide out the battery cover. Replace the battery with a NedA type 1604 or equivalent 9V alkaline battery. Replace the cover. 2. Remove battery when the LAN-1 is not used for extended period. OPEN Battery Replacement Visit us at www.TestEquipmentDepot.com...
