OPTICAL RECEIVER
VL2510
• 5001 Hadley Road • South Plainfield • NJ 07080 • Phone 800.969.3427 • In New Jersey 908.757.7444
USER'S MANUAL
Radiant Communications Corporation
• Fax 908.757.8666 • Email
sales@rccfiber.com
• Web
www.rccfiber.com
.
Radiant
Communications
Corporation
•
Optical Receiver VL2510
Advertisement
Table of Contents
Summary of Contents for Radiant Communications VL2510
- Page 1 Corporation OPTICAL RECEIVER VL2510 USER’S MANUAL Radiant Communications Corporation • 5001 Hadley Road • South Plainfield • NJ 07080 • Phone 800.969.3427 • In New Jersey 908.757.7444 • Fax 908.757.8666 • Email sales@rccfiber.com • Web www.rccfiber.com • Optical Receiver VL2510...
-
Page 2: General Desciption
GENERAL DESCIPTION VL2510 is a low price, high performance optical receiver specially designed for optical systems. It can be used at headend node locations of a fiber optic link to convert the optical signal to RF signal. FEATURES • Optical receiver module and RF amplifier module together •... -
Page 3: Board Illustration
Optical Receiver VL2510 Optical Characteristics Optical Wavelength 1290~1600nm Optical Input Return Losses >45dB Spectral Sensitivity 0.85A/W (1310nm typical) Optical Fiber Mono (9/125µm) Optical Input Power 0dBm (max.) Fiber Connector type FC/APC or SC/APC Storage Temperature -30°C to 80°C Operating Temperature -20°C to 40°C... -
Page 4: Block Diagram
The optical power test point inside the receiver is scaled at 2 Volts per million watt and provides an indication of received optical signal power. The expected DC voltage at this test point should between 0.5V and 2.0V. Optical Receiver VL2510... -
Page 5: Installation And Adjustment
The output of the receiver is a function of the optical input power and the modulation of the transmitter is generally set at 3.5%/CH. The optical input power vs the minimum RF output level is listed in Table 2. Optical Receiver VL2510... - Page 6 The Optical Power Monitoring Lamp is lit if the Input Power below –15dBm. If the output level needs to be changed, open the machine and adjust the rheostat W1. In return path of the fiber system, the output level of VL2510 is 100dBµV provided that the optical input level is –5dBm. (See Table 2) Table 3...
- Page 7 (4) Considering the different demand of systems, we can supply a series of pre-slope pin-board. (See Table 3) (5) The Power Indicating Lamp is lit if the optical input level is low than –15dBm. Please check the working condition of the optical link. (i.e., fiber connection, the output level of the Transmitter, etc.)
