Chapter 2

ZFR800 Recording Operation

Card Formatting

The memory card must be formatted by the ZFR800 before recording is possible.
To format the memory card do the following.
1. With the power off insert the memory card into the ZFR800
2. When the unit has fully initialized, press the menu key repeatedly until the instruction appears
in the display indicating how to erase the memory card.
3. Press the up arrow key 5 times to begin the Erasing and formatting of the memory card.
The ZFR800 displays its progress in formatting the memory card.
Important: Ensure the ZFR800 indicates that the formatting was successful before the card is used for actual
recording. If the formatting fails do not use the memory card for recording in the ZFR800.
A 2 GB MiniSD card takes approximately 20 seconds to format.

Jamming ZFR800 Time Code

Time code is jammed into the ZFR800 by IFB800 time code/remote control transmitter. The
ZFR800 sets itself to the rate transmitted. Time code accuracy of the ZFR800 is about 1 frame in 5
hours.
Important:
The ZFR800 will not keep time code running with power off.

Setting the ZFR800 Name

The name set into the ZFR800 becomes part of the file name of the audio files generated by the
ZFR800. It is also included in the metadata. 8 characters are provided for the ZFR800 name. The
ZFR800 name will appear for a few seconds on power up in the LCD display window.
Setting the ZFR800 name
1. Press and hold the menu key as the ZFR800 is powered up.
2. Release the menu key when the unit has fully initialized.
3. Press the menu key repeatedly until NAME: appears in the display with an arrow pointing to
the first character.
4. Press the up and down arrow keys to change the character that the arrow is pointing to.
The characters A-Z and 0 to 9 are the available characters.
5. Press the menu button to proceed to the next character.
When finished press and hold the menu button to leave this function or power down the ZFR800
and the power it on to resume normal operation.
