Summary of Contents for Axon POS System POS 700 series
-
Page 1: User Manual
User Manual January 2008 Revision 1.0 Point - of - Sale Monitor... - Page 2 Copyright 2008 Jan. All Rights Reserved Manual Version 1.0 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Important Safety Instructions
Safety IMPORTANT SAFETY INSTRUCTIONS 1. To disconnect the machine from the electrial power supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. 2. - Page 4 LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dustbin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.
-
Page 5: Revision History
Revision History Revision Description Revision Date Number Initial release 2008 January... -
Page 6: Table Of Contents
Table of Contents Item Checklist....................7 1.1. Standard Items..................7 1.2. Optional Items..................8 System View ....................9 2.1. Front View....................9 2.2. Rear View ....................9 2.3. I/O View ....................10 Drivers Installation..................11 3.1. Driver List....................11 3.2. ELO Touch Driver Installation..............11 3.3. POSTouch Driver Installation ..............13 System Installation ..................16 4.1. -
Page 7: Item Checklist
1. Item Checklist Take the system unit out of the carton. Remove the unit from the carton by holding it by the foam inserts. The following contents should be found in the carton: 1.1. Standard Items a. Driver CD b. Power Adapter c. -
Page 8: Optional Items
1.2. Optional Items a. MSR b. VFD... -
Page 9: System View
2. System View 2.1. Front View Touch Screen 2.2. Rear View Hole Plug VESA Mount Cable Cover... -
Page 10: I/O View
2.3. I/O View COM in PS/2 in USB in Power Left Select DC- In COM out VGA in PS/2 out USB out Menu Right... -
Page 11: Drivers Installation
3. Drivers Installation 3.1. Driver List Folder/File File Description <CD>:\POS720.htm B13 Driver List <CD>:\COMMON\Elo_Touch ELO Touch Driver <CD>:\COMMON\POS_Touch POSTouch Driver -The following procedures are for Windows 2000/XP, other platforms are similar. 3.2. ELO Touch Driver Installation a. Click ”sw500930” on the My computer b. - Page 12 e. Click the “Yes” button on the License Click the “Next” button on the on the “Select the COM ports…” window. Agreement window. g. Select “COM5” and click the “Next” h. Click the “Next” button on the You have button on the Choose the COM ports… selected the COM ports…window.
-
Page 13: Postouch Driver Installation
k. After the computer has restarted, click l. Follow the instructions on the screen to “Align” on the Elo Touchscreen calibrate the touch panel. Properties window. 3.3. POSTouch Driver Installation a. Double click the ”Setup” on the “My b. Click the “Next“ button on the “Welcome Computer”... - Page 14 e. Click the “Next” button on the “Select f. Click the “Finish” button on the “Install Program Folder” window. Shield Wizard Complete” window. g. Click the “Continue Anyway “button on h. Select the “Yes” and click the”OK” button the “Hardware Installation” window. and restart your system.
- Page 15 k. Select “Programs àTouchUtility àTouch l. Click “Scale / Offset” on the POSTouch Utility”. Utility window. n. Select “Device à9Pts Calibration” on the m. Follow the instructions on the screen to do a three point calibration of the touch POSTouch Utility window. panel.
-
Page 16: System Installation
4. System Installation 4.1. VESA Installation a. Place the panel bracket on the on the back of the system, and align the bracket holes with the VESA holes of the system. Tighten the screws (4)" b. Place the wall mount kit on the c. -
Page 17: Stand Holder Installation
4.2. Stand Holder Installation a. Slide the stand bracket into the position b. Tighten the screws (6), 3 on each side c. Attach the stand holder to the VESA holds and tighten the screws (4) -
Page 18: Vfd Installation
d. Attach the panel to the stand bracket e. Tighten the thumbscrew (1) 4.3. VFD Installation a. Place the VFD holder on the VFD bracket and tighten the thumb screws (2) - Page 19 b. Attach the VFD holder on the rear cover and tighten the screws (2). Put the VFD cable through the VESA bracket c. The cable should come out from the bottom side of the VESA bracket and band over in order to connect to the I/O port d.
-
Page 20: Msr Installation
4.4. MSR Installation a. Loosen the screws (2) b. slide the MSR into the position c. Tighten the screws (2) - Page 21 d. Put the MSR cable through the holders(2) e. Connect the MSR cable to the PS2 socket to finish the installation...
-
Page 22: Power Cord Installation
4.5. Power Cord Installation a. Connect the power cord to the adaptor b. Place the cable on the holder and clip to properly locate it. Route through the base gap for cable management... -
Page 23: System Disassembly
5. System Disassembly 5.1. Removing the Stand and the Stand holder a. Loosen the thumbscrew (1) b. Lift the panel up and separate it from the stand bracket... -
Page 24: Opening The I/O Cover
5.2. Opening the I/O Cover To open the I/O cover, please first follow the steps in chapter 5.1 a. Loosen the thumbscrews (2) b. Remove the I/O cover from the panel 5.3. Opening the Rear Cover To open the rear cover, please first follow the steps in chapter 5.1 a. -
Page 25: Replacing The Scalar Board
5.4. Replacing the Scalar Board To replace the scalar board, please first follow the steps in chapter 5.1, 5.2 and 5.3 a. Remove the hex screws(4) b. Disconnect the cables (4) c. Remove the screws (5) then slide the scalar board to the direction as shown by the arrows to replace it... -
Page 26: Replacing The Inverter Board
5.5. Replacing the Inverter Board To replace the inverter board, please first follow the steps in chapter 5.1, 5.2, and5.3. a. Disconnect the cables (3) b. remove the screws (2) to replace the inverter board... -
Page 27: Replacing The Osd Board
5.6. Replacing the OSD Board To replace the OSD board, please first follow the steps in chapter 5.1, 5.2, and5.3. a. Disconnect the cables (4) b. Remove the screws (6) to replace the OSD board... -
Page 28: Specification
6. Specification Main board LCD Panel Panel Size 12.1" TFT LCD 15" TFT LCD 17" TFT LCD Brightness 400nits 350nits 300nits Resolution 800 x 600 1024 x 768 1280 x 1024 Touch Resistive / IR type (Option, replace Tempered Glass) External I/O Ports PS/2 2 (1XPS/2 in to PC, 1XPS/2 out to MSR /Keyboard) -
Page 29: Connectors And Jumper Settings
7. Connectors and Jumper Settings 7.1. B13 Scalar board... -
Page 30: Jumper Settings
7.2. Jumper Settings 7.2.1 Power Mode Setting Function ◎ On 7.2.2 COM3 Power Setting Function ◎ COM3 PIN10_RI COM3 PIN10_+5V COM3 PIN10_+12V 7.2.3 USB Touch Setting Function JP10 ◎ Docking 3-5, 4-6 On Board 1-3, 2-4 7.2.4 COM Port RS232 Touch / Int. COM / RS232 Card Reader/ Ext. COM Setting Function ◎... -
Page 31: Connectors
7.3. Connectors Connector Function LCD Interface Connector Inverter Connector Resistive Touch Panel Connector Power State LED Connector VGA Extender Connector Power ON/OFF Connector (Reserve) GM2621 SPI Connector (Reserve) Internal USB Device Connector (Down-Stream) CN10 Internal COM Device Connector (Output) CN11 Keypad Connector CN12 Card Reader Connector... -
Page 32: Connectors Pin Definition
7.4. Connectors Pin Definition CN1: LVDS Interface Pin 1 LVDS_B0+ Pin 2 LVDS_A3+ Pin 3 LVDS_B0- Pin 4 LVDS_A3- Pin 5 Pin 6 Pin 7 LVDS_B1+ Pin 8 LVDS_CLKA+ Pin 9 LVDS_B1- Pin 10 LVDS_CLKA- Pin 11 Pin 12 Pin 13 LVDS_B2+ Pin 14 LVDS_A2+... - Page 33 CN4: Power State LED Connector Pin 1 LED_On Pin 2 Pin 3 LED_Off CN5: VGA Extender Connector Pin 1 +5_+12V Power Pin 2 +5_+12V Power Pin 3 Pin 4 VGA_CAT5_DATA Pin 5 VGA_CAT5_CLK Pin 6 VGA_CAT5_VSYNC Pin 7 VGA_CAT5_/HSYNC Pin 8 Pin 9 CAT5_EN# Pin 10 GND...
- Page 34 CN12: Card Reader Connector Pin 1 Pin 2 Pin 3 KDATA_SIO_TO_MSR Pin 4 KDATA_SIO_TO_MSR Pin 5 KDATA_MSR_TO_GFINGER Pin 6 KCLK_MSR_TO_GHINGER Pin 7 RS232_6_RX# Pin 8 RS232_6_TX# Pin 9 RS232_6_CTS# Pin 10 RS232_6_RTS# Pin 11 KB_EN Pin 12 Pin 13 USB20_MSR_P0+ Pin 14 USB20_MSR_P0- Pin 15...
