Sky Sat Mini HD PVR Ready User Manual

Full hd digital satellite receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Full HD Digital Satellite Receiver
Digital Innovation Life
Sky Sat Mini HD PVR Ready
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini HD PVR Ready and is the answer not in the manual?

Questions and answers

Summary of Contents for Sky Sat Mini HD PVR Ready

  • Page 1 Full HD Digital Satellite Receiver Digital Innovation Life Sky Sat Mini HD PVR Ready User's Manual...

  • Page 3: Table Of Contents

    INDEX INDEX ............................. 3 Precautions ........................... 5 1. Important Safety Instructions...................... 5 2. Notice ............................5 3. Copyright ............................ 6 4. Disclaimer ........................... 6 5. Trademarks ..........................6 Before You Begin ........................8 1. Main Features ..........................8 2. Accessories ..........................9 Hardware Description ......................
  • Page 4 PVR (Personal Video Recorder) Function ................ 28 1. Recording ..........................28 1.1 Recording methods ......................28 1.2 Recording Edit ........................30 1.3 Long Time recording ......................30 1.4 Pause during recording ....................... 30 2. Time Shifting ..........................32 3. Playback (Play List) ........................33 3.1 Recorded Files ........................

  • Page 5: Precautions

    Precautions 1. Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

  • Page 6: Copyright

    The mains plug is used as the disconnect device. The disconnect device shall remain readily operable. To reduce the risk of electric shock, do not remove the cover (or back). No user serviceable parts are inside. Refer servicing to qualified service personnel. The Lightning Flash with arrowhead symbol The exclamation point within an within an equilateral triangle, is intended to...
  • Page 7 Laboratories.

  • Page 8: Before You Begin

    Before You Begin 1. Main Features Full HD Satellite PVR receiver Supports H.264/MPEG4/MPEG-2 (HD/SD), DVB-S2 Compliant Powerful Compatibility through Embedded Linux OS Time Shifting, Recording & Playback with External Storage Devices ( USB 2.0 ) Simultaneous Recording of 3 Services and Watching 2 others (PIP) USB 2.0 Host ports (MP3 Player &...

  • Page 9: Accessories

    2. Accessories User's Manual Remote Control AAA size Batteries HDMI Cable ADAPTOR mount bracket (Option) IR extension (Option) RCA cable (Option) NOTE : If any accessories listed above are missing, contact the sales representative where you purchased this unit. It is ready to be mounted behind of the TV. Use the screws provided to hold the components in place.

  • Page 10: Hardware Description

    Hardware Description 1. Front Panel Configuration POWER Button: Press to switch between STANDBY and POWER ON modes. CH Up/Down Button: Press to change services in normal mode, to move the highlighted-bar UP/DOWN in menu mode. STANDBY / REMOTE Indication LED (RED / GREEN): The LED (RED) lights on in standby mode.

  • Page 11: Rear Panel Configuration

    2. Rear Panel Configuration 1. IR extension : The 2.5mm mini plug is connected to the “IR Rec” jack to use IR extension when HS 7110 is mounted with optional bracket. (Front remote sensor will not be operated when IR Extension is connected) 2.

  • Page 12: Remote Control Unit

    3. Remote Control Unit 1. POWER : Turns the STB On/Off. 2. MUTE / Resolution : Turns the sound On/Off. / To select the resolution format press and hold Resolution button. You will see the resolution menu. Each time you press the Resolution button, the resolution changes in the following sequence: 576i >...
  • Page 14 11. Favorite : To display the satellite group and the favorite groups. 12. EPG(Electronic Program Guide) : Show the TV/Radio program guide. 13. Recall : Moves to previous service. 14. Volume Up & Down : To change the Volume. 15. Play / Time shift : Display the progress bar of playback when no progress bar is displayed. Start playback with normal speed.
  • Page 16 24. Color Buttons a. RED : Used for special function in menu. RED key is used to sort lists in service list or go to previous day search in EPG or make/delete the current position as a bookmark. b. GREEN : Used for special function in menu. Green key is used to set favorites setting in service list or go to the next bookmark position.

  • Page 17: Connecting Diagram

    Connecting diagram 1. Receiver to A/C power Connect the A/C power cord between A/C power cord socket of receiver and A/C outlet. 2. Receiver to TV with Digital A/V Output Connect the HDMI Cable to the HDMI Connector of the TV. Connect SPDIF to Digital audio input of the equipment(Digital Audio) NOTE : Depending on the A/V equipment you own, there are various ways you can connect the STB.
  • Page 18 and multichannel audio in a single cable.

  • Page 19: Receiver To Tv With Analog A/V Output

    3. Receiver to TV with Analog A/V Output Connect the VIDEO and AUDIO L, R to VIDEO IN and AUDIO L, R IN of TV. NOTE : The composite connection(RCA cable) is recommended for analogue TV You cannot view high definition video with the composite video connector. 4.
  • Page 20 Using DiSEqC switch : Connect the cable of DiSEqC switch to LNB IN. Using DiSEqC motor : Connect the cable of DiSEqC motor to LNB IN.

  • Page 21: Guide To Mounting An Stb On Tv Back Panel (Optional)

    5. Guide to mounting an STB on TV back panel (Optional) Install the mount bracket on back panel of TV using the screws provided Mount your STB on the bracket. Connect IR Extension to the IR Rec Jack on the rear panel. PLACEMENT : The IR receiver should be located so that it is not directly facing a light source such as lamps or displays.

  • Page 22: Guide Of Functions

    Guide of Functions 1. Selecting a Service To select the desired service (channel), please refer to the instructions below. 1.1 Using CH UP/DOWN buttons You can navigate between services by pressing CH UP/DOWN buttons. Whenever you press the CH UP(DOWN) button, current service will be changed to next/previous service. Please press CH UP or CH DOWN button until you fine the service you want to watch.

  • Page 23: Using Recent Service List

    1.4 Using Recent Service List To display recent service list, press the RECALL button for a short time. To return to the previous service that you were watching, press RECALL button twice or for a longer time. Choose the service from the recent service list, use the ARROW button to select, and then press the OK button.

  • Page 24: Favorite Group

    Press the EPG button, then the EPG menu will be displayed. Use the ARROW buttons to move to other services or to see previous/next guide. Press the EPG button once to view full EPG with multi service list, and press it twice to view the additional EPG information of a specific channel service.

  • Page 25: Subtitle

    8. Subtitle You can select the language for a Subtitle, if the program provides subtitle information. Press the SUBTITLE button on your remote control unit. Select the desired subtitle language then press OK button. The subtitle will be displayed in the selected language at the bottom of the screen.

  • Page 26: Teletext

    10. Teletext When the TELETEXT icon on the INFO Banner, press the TELETEXT button to view the teletext. 11. PIP (Picture in Picture) When you press the PIP button, a sub picture screen will appear on the main screen view. If you press the PIP button one more time, the primary picture and the sub picture will appear together side-by-side with the same size.
  • Page 27 If you press the PAGE UP/DOWN button, the location of the sub picture is changed. If you press the PIP SERVICE LIST button, you can see the list of services of sub picture. You can change the service of the sub picture from the service list shown.

  • Page 28: Pvr (Personal Video Recorder) Function

    PVR (Personal Video Recorder) Function 1. Recording You can select a recording storage device with the following sequence : Menu > Configuration > Recording Option > Record Device. Default is set to ‘USB’. 1.1 Recording methods There are 3 type recording methods. (Instant Recording / Time Scheduled Recording / Event Scheduled Recording).
  • Page 29 Event Scheduled Recording via EPG : - In the EPG menu screen, you can choose the event you wish to schedule or record. - While watching the LIVE TV screen, press the EPG button to access the EPG menu screen. - Go to the event which you wish to view at the time indicated on the EPG schedule, then press OK.

  • Page 30: Recording Edit

    1.2 Recording Edit Press the REC button while recording to see the recording message window. Pause : Select Pause Recording then press OK to pause the current recording process. Duration : Set recording duration. Press LEFT/RIGHT ARROW button to change recording duration.
  • Page 31 Press PAUSE button once again and event will resume from the pause time. During recording, press the PLAY/TIMESHIFT button to show the Play bar screen. While the Play bar is shown on your screen, you may use the LEFT/RIGHT Arrow button to move (forward & backward) freely within recorded time.

  • Page 32: Time Shifting

    2. Time Shifting You can select a storage device for a temporary file of the Time shifting with the following sequence: Menu > Configuration > Recording Option > TimeShift Device. Default storage device is set to ‘USB’ If pressing the PAUSE button during Time shift, the live video is paused but the temporary recording for time shift is continued at the selected storage device.

  • Page 33: Playback (Play List)

    3. Playback (Play List) You can playback many files with the Playlist which you access by the PLAYLIST button. In the Playlist, you can check and playback recorded files, multimedia movie files, MP3 music files, and image files. With the LEFT/RIGHT ARROW button, go to the Recorded Files, Imported Files, Music and Photo category and check &...

  • Page 34: Imported Files

    File Option : If you press the BLUE button, you can select a option for Delete, New Folder, Move to Folder, Copy to Device, Rename, Lock/Unlock. You can select multiple files together and delete or move all of them at once. - Delete : To delete file(s) - New Folder : To make new folder.

  • Page 35: Bookmark

    4. Bookmark When the Play bar is displayed, you may move to desired time and book mark it by pressing the RED button. Bookmark(s) are indicated with a Green line on the play bar. Also, you may press the RED button to activate the play bar to mark your bookmark(s). When the play bar is on, user can move / jump between the bookmarks by pressing the GREEN button.

  • Page 36: Trick Mode

    5. Trick mode The user can change the speed of a fast forward play with FF(Fast Forward) button. Press FF button to change the speed to x2, x4, x6, and x8. If you once again press FF button in its x8 mode, it returns to normal(x1) speed play. You can also change rewind speed with the REWIND button.

  • Page 37: Menu Map

    Menu Map Main Menu 1. Storage Manager 2. Timer Settings 3. Service List Manager 4. Data Transfer System Tools 1. Recording Option 2. Parental Control 3. Display Setting 4. Time Setting 5. Language Setting Configuration 6. A/V Output Setting 1. Dish Setting 2.

  • Page 38: Main Menu Of Guide

    Main Menu of Guide To display the menu, press the MENU button at any time. You can select the sub menus by using the ARROW buttons. The selected sub menu becomes highlighted. After selecting (highlighting) the sub menu you want to access, press the OK button.

  • Page 39: Timer Settings

    1.2 Timer Settings Insert a new timer entry or modify an existing timer entry. To add new timer entry : Press the GREEN button. Timer Edit window will popup. You can set the specific start date, time, duration and service for its reservation. And you can choose one of Timer Modes as 'Once' or 'Daily' or 'Weekly'.
  • Page 40 Delete Services : All service lists will be shown on left side of the window. By using the ARROW and OK buttons you may select services to be deleted by placing them in the middle window. The press the GREEN button to delete the selected services.

  • Page 41: Data Transfer

    1.4 Data Transfer When the data transfer task is in process, the Front USB slot is set to a default device slot. But, if no USB device is connected on a front USB slot, then the Rear USB slot is set as a device to be used for the data transfer process.

  • Page 42: Configuration

    2. Configuration 2.1 Recording Option Alarm Confirm Message : Turn ‘ON’ this Alarm message to indicate and show the alert pop-up message when there is a reserved recording event. The alert message will show 3 minutes before the starting time of the reserved recording event.

  • Page 43: Parental Control

    2.2 Parental Control User’s access rights to a service and programs are controlled by a 4-digit secret code that is defined by the user. Whenever you attempt to access the parental control menu, a pop-up window will ask you to input a PIN code. (If necessary, you can change it.) NOTE : The default PIN code is ‘0000’...

  • Page 44: Time Setting

    2.4 Time Setting Time Setting : To set the current time, you can use two modes; Auto or Manual. Local Offset : Enter the offset value by using the standardized information of current service area. Daylight Saving : If you want to apply daylight saving, select the counter by using the ARROW buttons.

  • Page 45: A/V Output Setting

    2.6 A/V Output Setting TV Type : Select the TV types.(PAL/NTSC/Auto) In Auto mode, the STB is automatically selected to NTSC or PAL accordingly to the service played. TV Aspect Ratio : Select the aspect ratio of TV which is connected to the STB (4:3/16:9).

  • Page 46: Installation

    3. Installation 3.1 Dish Setting Select the satellite/antenna and LNB settings for service se arch. The values that are set in this menu will be availabl e for selection in other service searching menus. Satellite : Select the satellite which you want to do a search for.

  • Page 48: Service Search

    - Using USALS : Dish Longitude : Enter the longitude position of the antenna using the NUMERIC buttons. Dish Latitude : Enter the latitude using the NUMERIC buttons. Go To : Press the OK button to rotate the dish to the selected antenna position.

  • Page 49: Network Setting

    - Search Type : Select the search type. - Dish Setting : Press the OK button to move to the Dish Setting menu directly. - Start Search : Press the OK button to start a search. Fast Scan : - Select operator : Press the OK button to select Operator. - Select HD/SD Service : Press the OK button to select HD/SD Service.
  • Page 50 device must be connected with your receiver(STB) when firmware upgrade from server. MAC Address : This will display the MAC address of the STB Ethernet interface and is a fixed assignment unique to each STB.

  • Page 51: System Recovery

    Control of the files via the network and your PC : - Check the IP Address of the STB on the Network Setting menu. - Press Enter button on your PC, after writing IP Address browser address line. Ex.) \\168.158.10.146\storage - You can see the folder name of USB in the Storage folder.

  • Page 52: System Information

    Store system data : If you want to use system parameters and service data in the future, this menu allows you to store current state. Press the OK button to store current state. Delete store position : Delete stored system data. 3.6 System Information This menu displays general information about the hardware and software version of your receiver.
  • Page 53 the screen. After the message disappears, you can watch the service you want.

  • Page 54: Plugin

    CAM information You can view the current status of CAM. Select the slot which you want to view using the ARROW buttons, and press the OK button. If the CAM is available, you can view information about each slot. NOTE : The displayed information of each CAMs may be different depending on the CAM used.

  • Page 55: Youtube

    Executing WebZeal with USB Storage device - Stored the WebZeal file to the USB storage device. File name : ‘WebZeal-201xxxxx.mnt’. - Connect the USB storage device to your receiver then go to Menu > System Tools > Storage Manager. Set the Current Device to File Mount Drive. Set the Mount File Name to WebZeal-201xxxxx.mnt Press Connect then go to Menu >...
  • Page 56 of the selected thumbnail is being displayed.- - Use the ARROW buttons to navigate through the menu - And press the OK / Play buttons to start viewing the selected content. - While playing, use the PAUSE / STOP buttons to pause, or stop playing the service. - Trick play modes (FAST FORWARD / REWIND) are not support in the STB’s YouTube menu.

  • Page 57: Troubleshooting

    Troubleshooting Problem Solution Check the main power cable and check that it is plugged Does not display any into a suitable power outlet. message on the front panel. Check the STB main power switch ‘ON’ at the rear of the STB.

  • Page 58: Specifications

    Specifications Tuner & Channel Decoder Input Connector F-type, IEC 169-24, Female Loop through out F-type, IEC 169-24, Female Frequency Range 950MHz ~ 2150MHz Input Impedance 75Ω, unbalanced Signal Level -65 to -25dBm LNB Power 13/18VDC, max.400mA 22KHz Tone (22±2)KHz, (0.6±0.2)V DISEqC Control V1.0/1.2/USALS Compatible Demodulation...
  • Page 59 Audio / Video & Data IN/OUT CVBS Video Output, Audio L, R Output HDMI Video & Audio Output OPTIC AC-3 Dolby Digital (SPDIF) RS-232C 9 pin D-SUB (Male) type, Transfer rate 115Kbps USB 2.0 Host Support Ethernet TX 10/100M Base IR extension Removable IR extension Front / Rear Panel...
