FEATURES
Voltage Gain 36dB.
Input sensitivity 350mV
Use of very low distortion high quality audio OPAMPAD797, 0.9nV at 1kHz
typical and -120dB THD at 20kHz.
Symmetric PCB design for both R and L channels.
Implemented with WIMA, Nichicon capacitors and Dale resistors.
High quality PCB with dimension 116 x 58cm, blue solder mask, double layer,
2.4mm thickness, 2oz copper.
Required power supply: +/-15V DC
www.analogmetric.com
[RIAA Pre-Amplifier ]
