NTI ENVIROMUX-MINI Installation And Operation Manual

Enviromux series mini server environment monitoring system
Table of Contents

Advertisement

®
ENVIROMUX
Series
ENVIROMUX-MINI
Mini Server Environment Monitoring System
Installation and Operation Manual
MAN061
Rev Date 7/15/2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENVIROMUX-MINI and is the answer not in the manual?

Questions and answers

Summary of Contents for NTI ENVIROMUX-MINI

  • Page 1 ® ENVIROMUX Series ENVIROMUX-MINI Mini Server Environment Monitoring System Installation and Operation Manual MAN061 Rev Date 7/15/2011...
  • Page 2 Shielded cable must be used to connect to the DRY CONTACT ports in order to meet CE emission requirements CE Statement We, Network Technologies Inc, declare under our sole responsibility that the ENVIROMUX-MINI is in conformity with European Standard EN55022.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction..................................1 Materials ..................................2 Supported Web Browsers ............................6 Connectors and LEDs..............................6 Installation..................................7 Mount the Unit ................................7 DIN Rail Mounting..............................7 Connect Sensors ................................. 8 Connect to Ethernet..............................9 Connect the Power ..............................10 Connect a Modem ..............................
  • Page 4 Figure 4- Secure liquid detection sensor with tape ..........................8 Figure 5- Terminal block for contact sensors ............................. 9 Figure 6- Connect ENVIROMUX-MINI to the Ethernet ........................9 Figure 7- Connect the AC adapter and power-up ..........................10 Figure 8- Connect a Modem ................................10 Figure 9- Device Discovery Tool page .............................
  • Page 5: Introduction

    Specifically, the ENVIROMUX-MINI will monitor temperature, humidity, and detect the presence of water on a flat surface (such as the floor). The unit also has four sets of terminal block pairs for the connection of contact-closure sensors. Remote monitoring is provided via a 10BaseT Ethernet web interface.
  • Page 6: Materials

    CD containing a pdf of this manual, pdf of a Quick Installation Guide, Discovery Tool, and an SNMP MIB file Printed Quick Installation Guide 2- Mounting tabs for Zero-RU mounting (pre-assembled to back of ENVIROMUX-MINI- see page 7) Additional materials may need to be ordered, depending upon the configuration: CAT5/5e/6 unshielded twisted-pair cable(s) terminated with RJ45 connectors wired straight thru- pin 1 to pin 1, etc.
  • Page 7 ∗ Sensor type: open/closed contact switch. ∗ Attached 3-foot power cord. ∗ ENVIROMUX-ACVD-515M: Standard US 120V 15A NEMA 5-15 plug (When using with ENVIROMUX-MINI that was purchased before 11/1/2007, use part number ENVIROMUX-ACVD-515) ∗ ENVIROMUX-ACVD-C14M: Universal 250V IEC C14 socket (When using with ENVIROMUX-MINI that was purchased before 11/1/2007, use part number ENVIROMUX-ACVD-C14) ∗...
  • Page 8 ∗ Regulatory approvals: UL ENVIROMUX-2W-xx Sensor Cables * 2-wire sensor cable * Used to connect dry contact sensors to the ENVIROMUX-MINI * Available lengths (ft): 3/6/10/25/50/100 There are more sensors to be added. See our webpage for the latest available.
  • Page 9 ∗ Quad band EDGE/GPRS/GSM: 850/900/1800/1900 MHz ∗ Includes 12V/1A power supply. Contact your nearest NTI distributor or NTI directly for all of your cable needs at 800-RGB-TECH (800-742-8324) in US & Canada or 330-562-7070 (Worldwide) or at our website at http://www.networktechinc.com...
  • Page 10: Supported Web Browsers

    Mozilla Firefox 2.0 or higher Netscape Navigator 9 Mac Safari 3.0 or higher Note: Support for Firefox and Netscape requires ENVIROMUX-MINI firmware version 1.34 or higher. Support for Safari requires ENVIROMUX-MINI firmware version 1.40 or higher. CONNECTORS AND LEDS LABEL...
  • Page 11: Installation

    Mount the Unit The ENVIROMUX-MINI can either be placed on a solid surface, mounted to a wall, or mounted to an accessible surface within rack (Zero-RU). To mount to a wall or other surface, first remove the screws holding the mounting tabs to the rear of the box.
  • Page 12: Connect Sensors

    Note: Mounting the sensor in the path of a fan or on a heated surface may affect the accuracy of the sensor’s readings. Note: For best results, use the ENVIROMUX-T-IND with model ENVIROMUX-MINI-IND (see Sensors, page 11). Figure 3- Connect sensors to ENVIROMUX-MINI 2.
  • Page 13: Connect To Ethernet

    10kΩ or less will be interpreted by the ENVIROMUX-MINI as a closed contact. To install the dry-contact sensor(s): A. Attach the positive lead to a terminal corresponding to a "+5V" marking on the ENVIROMUX-MINI and the ground lead to the next terminal to the right that will correspond to a marking on the ENVIROMUX-MINI.
  • Page 14: Connect The Power

    Connect the Power Note: Sensors should be connected before supplying power to the ENVIROMUX-MINI. Connect the AC adapter to the connection marked "PWR" on the ENVIROMUX-MINI and plug it into an outlet. N T I N e t w o r k T e c h n o l o g i e s I n c...
  • Page 15: Overview - Use And Operation

    All settings are saved in memory when applied. A user may also restore the unit to its default settings via the web interface or the Restore button on the ENVIROMUX-MINI (see page 27).
  • Page 16: Data Logging

    (page 16). Note: The SNMP MIB file (enviromux-mini.mib), for use with an SNMP MIB browser, can be found on the manual CD. Click on the link to open the file, then save the file to your hard drive to use with the SNMP MIB browser.
  • Page 17: Device Discovery Tool

    DEVICE DISCOVERY TOOL In order to easily locate the ENVIROMUX-MINI on a network, and change the IP settings, the NTI Device Discovery Tool may be used. A link to the Discovery Tool is provided on the web page that appears when the instruction manual CD is inserted into the computer's CD ROM drive.
  • Page 18: Use And Operation Via Web Interface

    USE AND OPERATION VIA WEB INTERFACE A user may monitor and configure the settings of any device connected to the ENVIROMUX-MINI using the Web Interface via a web browser (see supported browsers on page 6). To enable the Web Interface, connect the ENVIROMUX-MINI to the Ethernet (page 9).
  • Page 19: General Settings

    Press Apply if any changes are made above to the fields or the changes will not be saved upon leaving this page. Note: If the Restore or Reboot buttons are pressed, the ENVIROMUX-MINI will erase the system logs. It is recommended that the logs be downloaded if they need to be saved before using the Restore or Reboot buttons (see page 23 to download System Logs).
  • Page 20: Network Settings

    If a mistake has been made and the user cannot find the ENVIROMUX-MINI by entering the new IP address in the address bar, the Discovery Tool may be used to locate and correct the address of the ENVIROMUX-MINI (see page 13).
  • Page 21: Email Configuration

    NTI MINI SERVER ENVIRONMENT MONITORING SYSTEM Email Configuration Figure 14- Email configuration page The Email Page allows users to configure the necessary settings that enable the ENVIROMUX-MINI to send emails via an SMTP server. It requires the following settings: •...
  • Page 22: Date And Time

    The Date and Time page in the ADMINISTRATION menu enables the administrator to either manually set the date and time or to have the ENVIROMUX-MINI synchronize with a TIMEP server. If a TIMEP server is specified, the ENVIROMUX-MINI will synchronize with the TIMEP server every 10 minutes. The format in which the date is displayed on other pages can be configured with the Format box.
  • Page 23: User Management

    Anyone listed as an administrator has full access to change anything as if they were the administrator. In the event administrator password(s) are lost, see pages 15 or 27 for "Restore Defaults" to restore the ENVIROMUX-MINI to all factory default settings.
  • Page 24: Guest User

    Figure 17- Status Summary and menu for Guest users On this screen the status of each sensor connected to the ENVIROMUX-MINI is displayed. The guest may view the system log and the status of any sensor. To be able to configure system settings, the user must log in. Click on the "LOG IN" link at the bottom left of the menu.
  • Page 25: Sensor Management

    NTI MINI SERVER ENVIRONMENT MONITORING SYSTEM Sensor Management In the SUMMARY page each of the sensors attached to the ENVIROMUX-MINI are listed. To view the details of a particular sensor, click on the sensor name in the left column of the screen.
  • Page 26: Name

    Email For the ENVIROMUX-MINI to send an email alert, the Email settings (on the “Email” page) and the IP address of the DNS server (on the “Network” page) must be properly configured. Put a checkmark in the "Email" box to enable this option. The email addresses chosen for alerts from the Email configuration page will be pre-filled in the text box below the check box.
  • Page 27: Message To Send With Alerts

    The alerts for a sensor can also be disabled completely by selecting the "Disable alerts for this sensor" box. System Log Information collected from any of the ENVIROMUX-MINI sensors, as well as from other system events, can be stored in a log and reviewed by anyone (Administrator, User, or Guest).
  • Page 28: Events To Log

    NTI MINI SERVER ENVIRONMENT MONITORING SYSTEM Events to Log The Events to Log page enables the user to specify what type of events sensed by the ENVIROMUX-MINI should be recorded in the Log. The user can select each type of event that should be recorded and can change these selections at any time. Events that can be logged include sensor readings, alert conditions, actions taken by the user in response to an alert, end of alert conditions, and user logging in or out of the ENVIROMUX-MINI web interface.
  • Page 29: Overflow Actions

    Figure 22- Define log methods Overflow Actions There is a maximum limit of 100 event records that can be stored in the ENVIROMUX-MINI. The Overflow Action page enables the user to configure how the ENVIROMUX-MINI handles records when log memory capacity is exceeded.
  • Page 30: Wap Login

    NTI MINI SERVER ENVIRONMENT MONITORING SYSTEM WAP Login The user can login to the ENVIROMUX-MINI through a WAP 2.0 compatible device (firmware version 1.34 or higher required) to view a Summary Page for the sensor status (below). To login, type the current IP address of the ENVIROMUX-MINI into the address bar of the WAP browser and add the word “mobile”...
  • Page 31: Pc-To-Enviromux-Mini Crossover Cable

    Crossover Cable RESTORE DEFAULTS In the event that the ENVIROMUX-MINI needs to be returned to all default settings, either the web interface, or the Restore button on the front of the ENVIROMUX-MINI (see Figure 26) can be used. To use the Restore button,...
  • Page 32: Update The Firmware

    NTI MINI SERVER ENVIRONMENT MONITORING SYSTEM UPDATE THE FIRMWARE It may be desired, on occasion, to update the firmware in the ENVIROMUX-MINI, or even to change the MAC address of the unit. To Update the Firmware The following is needed: •...
  • Page 33: Specifications

    Supports 3-wire interface (Tx, Rx, and GND) Environmental Operating temperature 32°F to 104°F (0°C to 40°C) (32°F to 167°F (0°C to 75°C) for ENVIROMUX-MINI-IND) Storage temperature -20°F to 140°F (-30°C to 60°C) Operating and Storage Relative 17 to 90% non-condensing RH...
  • Page 34: Troubleshooting

    NTI MINI SERVER ENVIRONMENT MONITORING SYSTEM TROUBLESHOOTING Problem Cause Solution • • Sensors readings are not being Configuration for sensor updates is not Configure sensor updates under General updated set properly Settings (page 10) • • Browser is incorrectly going to cache for...
  • Page 35: Index

    NTI MINI SERVER ENVIRONMENT MONITORING SYSTEM INDEX AC adapter, 10 Overflow actions, 25 Alert Actions, 24 Password, 14, 19, 26 alert methods, 22 password authentication, 11 alert timing, 22 port channel, 16 Alerts, 11 privileges, 19 connect sensors, 8 Restore button, 27...
