HOME2US SMP-6200 User Manual

Irdeto ca satellite receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

DIGITAL SET-TOP-BOX
Irdeto CA Satellite Receiver
SMP-6200
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMP-6200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HOME2US SMP-6200

Summary of Contents for HOME2US SMP-6200

  • Page 1 DIGITAL SET-TOP-BOX Irdeto CA Satellite Receiver SMP-6200 USER’S MANUAL...

  • Page 2: Table Of Contents

    Digital Satellite Receiver SMP-6200 Table of Contents 1. PRE-INSTALLATION CHECKUP 2. SAFETY WARNINGS 3. CONNECTIONS 4. REMOTE CONTROL Remote Control Unit 5. MENU INSTRUCTION Main Menu 5.1.1 TV Guide 5.1.2 Radio Guide 5.1.3 Installation 5.1.3.1 Installation 5.1.3.1.1 Antenna Setting 5.1.3.1.2 Auto Searching 5.1.3.1.3...

  • Page 3: Pre-Installation Checkup

    Digital Satellite Receiver SMP-6200 1. PRE-INSTALLATION CHECKUP Please check the following items after opening the package: digital satellite receiver, remote control, battery, A/V cable, RF cable, and user’s manual. Please keep the packing box, packing materials, and plastic bag in safe place for...

  • Page 4: Safety Warnings

    Digital Satellite Receiver SMP-6200 2. SAFETY WARNINGS The normal operating temperature of the digital satellite receiver is between 0ºC and 40ºC. Please prevent the receiver from operating in dusty conditions. The receiver shall be operated in ventilated environment away from heat sources.
  • Page 5 Digital Satellite Receiver SMP-6200 The satellite antenna that is connected to the receiver shall be equipped with anti-shock device from lightning. When the receiver is inoperative, please consult the Customer Support.

  • Page 6: Connections

    Digital Satellite Receiver SMP-6200 3. CONNECTIONS Please refer to Figure 1 and Figure 2 for the following instructions. Connect the LNB cable from the dish antenna to the LNB IN connector on the back of the digital satellite receiver. Use the RCA audio/video cables to connect the Audio Left, Audio Right, and Video Output to the corresponding connectors on TV.
  • Page 7 Digital Satellite Receiver SMP-6200 Figure 2 Rear Panel LNB OUT Satellite signal loop through terminal LNB IN Satellite signal input terminal from LNB RS-232 RS-232 serial port S-VIDEO Connect to S-VIDEO Jack of the TV or VCR VIDEO (Yellow) Line signal output of video...

  • Page 8: Remote Control

    Digital Satellite Receiver SMP-6200 4. REMOTE CONTROL FUNCTION POWER Turns power ON/OFF of the receiver. MAIL Directly goes into mail screen. TV/AV Switch output between TV, AV and VCR. TV/RADIO Switches between TV and Radio mode. Enters number of the required menu item or selects a channel number to watch.

  • Page 9: Remote Control Unit

    Digital Satellite Receiver SMP-6200 Remote Control Unit Please refer to the following diagram (Figure 4) when using the remote control. The maximum distance for usage is 10 meters (30 feet) with look angle 60 degrees. Please aim the infrared transmitter in the front of the remote control to the front panel of the receiver.

  • Page 10: Menu Instruction

    Digital Satellite Receiver SMP-6200 5. MENU INSTRUCTION Main Menu The contents of main menu are as follows: Main Menu Installation Channel Management System Setting System Information EXIT Move Select Exit Installation Installation is used to search for new services or to edit existing ones. It can also be used to load the default setup of the receiver.

  • Page 11: Radio Guide

    Digital Satellite Receiver SMP-6200 5.1.1 TV Guide This shows the list of TV program, press OK button can enter to TV guide. You can select one of the TV programs (event name) by pressing keys follow with pressing the OK key.

  • Page 12: Installation

    Digital Satellite Receiver SMP-6200 5.1.3 Installation Installation is used to search for new services or edit existing ones. It can also be used to load the default setup of the receiver. To enter this menu, you have to input the PIN Code first. The default PIN Code is 0000.
  • Page 13 Digital Satellite Receiver SMP-6200 5.1.3.1.1 Antenna Setting You can select the Antenna and LNB settings for service searching, as well as the settings of 22KHz tone and DiSEqC switch and dish options. There are 32 possible antenna settings. The values set in this menu are available for selection in other Service Searching Menus.
  • Page 14 Digital Satellite Receiver SMP-6200 LNB Type There is two options to be selected from: normal and universal. Press keys to switch between the options. If normal is selected, the figure is as above, if the universal is selected, the figure is as...
  • Page 15 Digital Satellite Receiver SMP-6200 Frequency When the LNB Frequency is single, press OK to display the list of Frequency, then press keys to select. User can always select “user defined” to add a new Frequency. Antenna Setting Installation Main Menu ●...
  • Page 16 Digital Satellite Receiver SMP-6200 Antenna Setting Installation Main Menu ● Antenna AMC-4 ● LNB Type Normal ● Frequency 11300 Message Box ● LNB Power 13/18V Saving data, Please wait… ● 22KHz AUTO ● DiSEqC ● Dish FIXED ● Save ● Auto Search Move ●...
  • Page 17 Digital Satellite Receiver SMP-6200 5.1.3.1.2 Auto Searching To enter this menu, user can press OK key from the installation screen. There are two bars on the bottom to indicate the signal strength and quality. The bars in green color show the signal is in good condition. This menu will automatically search for the existing channels by the frequencies.
  • Page 18 Digital Satellite Receiver SMP-6200 5.1.3.1.3 Manual Searching After setting the search parameters like frequency, symbol rate etc, you can find the services in the transponder you selected. There are two bars on the bottom to indicate the signal strength and quality. The bars in red color show the signal is in good conditions.
  • Page 19 Digital Satellite Receiver SMP-6200 Satellite It shows the satellite name. User can select the satellite name by pressing keys. The total number is 32. Press OK key to show all satellite lists. Manual Search Installation Main Menu ● Satellite AMC-4...
  • Page 20 Digital Satellite Receiver SMP-6200 Frequency It shows the frequency of the transponder user selected. Press OK to display the list of existing frequencies. If the frequency exists in the list, the corresponding symbol rate and polarization are also confirmed. Manual Search...
  • Page 21 Digital Satellite Receiver SMP-6200 Manual Search Installation Main Menu ● Satellite AMC-4 ● Frequency ● Symbol Rate ● Polarization ● Scan Mode ● Network Search ● PID Search Strength Quality ● Start Scan ● Edit TP Move ● Antenna Setup...
  • Page 22 Digital Satellite Receiver SMP-6200 Manual Search Installation Main Menu AMC-4 ● Satellite ● Frequency 12120 ● Symbol Rate 30000 ● Polarization ● PID Search ● Video PID ● Audio PID ● PCR PID Strength Quality ● Start Scan ● Edit TP Move ●...
  • Page 23 Digital Satellite Receiver SMP-6200 TP Scan Menu Manual Search Installation Main Menu Radio 1. Lawyers TV 2. TV TWRAM 3. VPTV 4. Planeta TV 5. CGNTV 12120 V 30000 Ksps Strength Quality EXIT Move Select Exit Start Scan Press Red key to get into TP Scan menu.

  • Page 24: Favorite/Lock Channel

    Digital Satellite Receiver SMP-6200 5.1.3.1.4 Factory Default When you select YES, the system setup and channel data will be changed to the default values. All the service information manually entered by user will be lost! To exit, select NO or press MENU key.
  • Page 25 Digital Satellite Receiver SMP-6200 5.1.4.1 Favorite/Lock Channel This menu allows users to mark favorite/lock the existing channels. 1. Press OK key to enter the favorite/lock menu 2. Press key to select a channel. 3. Press Yellow key to mark favorite for channel you selected.
  • Page 26 Digital Satellite Receiver SMP-6200 5.1.4.2.1 Move 1. Press key to select a channel that you would like to move. 2. Press OK key to confirm. The color of this service will become grey. 3. Press the key to move the highlighted channel to a new position.
  • Page 27 Digital Satellite Receiver SMP-6200 5.1.4.2.3 Rename 1. Press key to move to the service. 2. Press OK key, the ‘Rename’ box will appear. 3. Press / key to select the desired character. 4. Press key to select OK key. 5. Press OK key to confirm or MENU key to discard the changes and exit.

  • Page 28: System Setting

    Digital Satellite Receiver SMP-6200 5.1.5 System Setting 5.1.5.1 Time Setting Time Zone Set the local time zone offset of GMT from –12 to +12. Summer Time Set it to ON or OFF. ‘ON’ means summer time function works. Year/Month/Day/Hour. This option is only provided to show the current time. It is not changeable by user.
  • Page 29 Digital Satellite Receiver SMP-6200 Menu Language User can select the menu language, such as English, Chinese, etc. Brightness User can select the brightness value. Color User can select the color value. TV Screen User can set the screen aspect ratio of TV (4:3,4:3panscan, 4:3LB, 16:9, or 16:9pillar) TV Type User can set the video output mode to Auto, NTSC or PAL.

  • Page 30: Parental Control

    Digital Satellite Receiver SMP-6200 Parental Control User can press / key to switch select parental control option among UNBLOCK, 10,13, 16, 18 and ALL_BLOCK. Parental Control System Setting Main Menu ● Parental Control UNBlock ● New Password ● Confirm Password...

  • Page 31: Timer

    Digital Satellite Receiver SMP-6200 5.1.5.4 Timer This menu provides the users to record the programs they want to view. Timer System Setting Main Menu 01/05 THU 06:08 am Timer Lock . On START CHANNEL DEST 19,775 Mo 2,715 Ph’ 3,721 Mov 1,749 Sta ●...

  • Page 32: System Information

    Digital Satellite Receiver SMP-6200 1. Press key to select the channel you want. 2. Press OK key to confirm this channel to be the power up channel, a confirmation message box will appear. 3. Select Yes to save or No to cancel.

  • Page 33: Load Status

    Digital Satellite Receiver SMP-6200 5.1.6.2 IRD Status To view the system status. IRD Status System Information Main Menu Smart Card 12121212 No Card IRD: 55 .5 .55 Firmware: None CA Module: Softcell: 2.26B Loader: -1:0:27 L-17 OpenTV SW: None App SW: Driver SW: v1.3...

  • Page 34: Mail Message

    Digital Satellite Receiver SMP-6200 5.1.6.4 Mail Information To view the mail content sent from head-end. 1. Press key to wrap the mail. 2. Press Exit key to exit this menu. 3. Press Erase key to clear all the emails. Mail Information...

  • Page 35: Specifications

    Digital Satellite Receiver SMP-6200 6. SPECIFICATIONS 6.1 Compliance This Digital Satellite Receiver meets the DVB-S/MPEG-2 standards for the reception of free-to-air digital satellite broadcast. It is compatible for SCPC/MCPC, C band, and Ku band signals. The menu of this receiver is designed such that the customer may set or change the channel frequency, symbol rate.
  • Page 36 DIGITAL SET-TOP-BOX COPYRIGHT Home2US Communications, Inc.
