HUMIDIFIED DRAWER WARMER
MANUFACTURED BY:
CARTER-HOFFMANN
1551 McCORMICK AVENUE
MUNDELEIN, IL 60060 U.S.A.
PHONE: 847-362-5500
FAX: 847-367-8981
EMERGENCY SERVICE: 800-421-3744
EMAIL: service-carterhoffmann@carrier.utc.com
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from CARTER-HOFFMANN.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your CARTER-HOFFMANN DEALER if you
have any questions concerning installation, operation or maintenance of this equipment.
Knowledge of proper installation, operation and maintenance procedures is essential to ensure the safe operation of this unit.
1.
Always have dry hands prior to using the ON/OFF switch.
2.
Turn OFF the ON/OFF switch anytime the cabinet is not in use, for extended periods of time.
3.
If an electrical shock is felt when touching the cabinet, disconnect the power immediately and call Carter-Hoffmann
Technical Service for assistance or service.
4.
If the power cord is frayed or the plug damaged, DO NOT PLUG INTO THE ELECTRICAL POWER RECEPTACLE.
IF IT IS ALREADY PLUGGED IN, SHUT OFF THE MAIN CIRCUIT BREAKER, LOCATED IN THE BREAKER BOX,
THEN DISCONNECT THE PLUG.
5.
DISCONNECT THE POWER CORD BEFORE ATTEMPTING ANY REPAIRS TO THE CABINET AND/OR CLEANING
THE UNIT. REPAIRS TO THIS UNIT MUST BE PERFORMED BY QUALIFIED PERSONNEL.
6.
DO NOT SPRAY WITH WATER HOSE OR SUBMERGE THE CABINET. ELECTRICAL COMPONENTS AND
WIRING PRESENT A HIGH SHOCK HAZARD WHEN WET.
Rev: Jun 24, 2005
CARTER-HOFFMANN
OPERATION MANUAL
MODELS: HDW-1, HDW-2, HDWN-1, HDWN-2
SAFETY
Part Number: 18400-3109
SHOWN: HDW-2
Printed in The United Stated of America
Advertisement
Summary of Contents for Carter Hoffman HDW-1
- Page 1 CARTER-HOFFMANN HUMIDIFIED DRAWER WARMER OPERATION MANUAL MODELS: HDW-1, HDW-2, HDWN-1, HDWN-2 MANUFACTURED BY: CARTER-HOFFMANN 1551 McCORMICK AVENUE MUNDELEIN, IL 60060 U.S.A. PHONE: 847-362-5500 FAX: 847-367-8981 EMERGENCY SERVICE: 800-421-3744 EMAIL: service-carterhoffmann@carrier.utc.com SHOWN: HDW-2 IMPORTANT: DO NOT DISCARD THIS MANUAL This manual is considered to be part of the appliance and is to be given to the OWNER or MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of this appliance.
-
Page 2: Warranty Statement
WARRANTY STATEMENT Carter-Hoffmann, A division of Carrier Commercial assume any obligation or liability in connection with Refrigeration, Inc., warrants to the initial purchaser its products other than that covered in this warranty. of its standard Carter Line Products that Carter- This warranty applies only within the continental Hoffmann will, at its option, repair or replace, during United States and Canada. - Page 3 This manual contains the information needed to properly install this appliance, and to use and care for the appliance in a manner which will ensure its optimum performance. SPECIFICATIONS MODEL VOLTS 1ø WATTS AMPS POWER SUPPLY CORD HDW-1 1500 12.5 NEMA 5-15P HDW-2 1130 HDW-1 NEMA 6-15P...
- Page 4 FEATURES & OPERATING CONTROLS NOTE: HDW-2 DUAL-DRAWER STANDARD WIDTH UNIT SHOWN. SINGLE-DRAWER AND NARROW WIDTH UNITS ARE SIMILAR...
- Page 5 FEATURES & OPERATING CONTROLS (continued) This appliance is intended for use in commercial establishments WARNING: only. ELECTRIC This appliance is intended to hold previously prepared food at SHOCK HAZARD serving temperature for human consumption. No other use is All servicing requiring recommended or authorized by the manufacturer or its agents.
- Page 6 INSTALLATION NOTE: DO NOT discard UNPACKING & INSPECTION the carton or other packing Carefully remove the appliance from the carton. Remove all materials until you have protective plastic film, packing materials and accessories from the inspected the appliance for Appliance before connecting electrical power or otherwise performing hidden damage and tested it any installation procedure.
- Page 7 INSTALLATION (continued) ELECTRICAL WARNING: Refer to electrical specifications on page 1. Circuit must meet or ELECTRIC exceed the amperage and wattage requirements listed. SHOCK HAZARD 120 Volt units require a properly grounded NEMA 5-15R receptacle: All servicing requiring access to non-insulated elec- trical components must be performed by a factory au- thorized...
- Page 8 OPERATION INSTALL WATER PAN CAUTION: HOT SURFACE IMOPORTANT: The water pan must be installed with care in order to prevent damage to water heating element. Exposed surfaces can be hot to the touch and may cause burns. CAUTION: ELECTRICAL SHOCK HAZARD DO NOT splash or pour water onto control panel or wiring.
- Page 9 OPERATION (continued) NORMAL OPERATION CAUTION: Plug unit into an appropriate electrical receptacle. HOT SURFACE Add water to water pan. Proper water level is 1/2" from top. Exposed surfaces can be hot OPERATIONAL TIPS: to the touch and may cause Refill water pan as required during operation. burns.
- Page 10 OPERATION (continued) EXAMPLE: PROGRAM MODE Set Menu #3 AIR temp = 150ºF WATER temp = OFF TIME setting = 2hr 30min Press and hold MENU key, then UP ARROW key or DOWN ARROW key to select menu number. Release keys. Press and hold MENU key for 3 seconds to enter programming mode.
- Page 11 OPERATION (continued) RECOMMENDED TEMPERATURE SETTINGS AND HOLDING TIMES TEMPERATURE ºF TYPE OF FOOD TIME (HRS) WATER BREAD PRODUCTS 2 1/2 DAIRY & EGG PROD- UCTS MEATS & POULTRY ROASTED MEATS & POULTRY FRIED SEAFOODS 2 1/2 WITH SAUCE SEAFOODS 1 1/2 FRIED STARCHES BEANS...
- Page 12 CLEANING INSTRUCTIONS PRECAUTIONS: Disconnect appliance from electric power. CAUTION: Allow unit to cool before proceeding. ELECTRIC SHOCK HAZARD FREQUENCY: Minimum -Daily Disconnect appliance from electric power before cleaning. TOOLS: Mild Detergent Clean cloth or sponge CAUTION: HOT SURFACE 1. Disconnect warmer from electric power. Allow to cool before cleaning.
- Page 13 PARTS & SERVICE ACCESSORY PART NO. IMPORTANT: Use only factory authorized service PRODUCT PAN, all HDW-Series Warmer 22228 parts and replacement filters. For factory authorized service, or to order factory authorized replacement parts, contact Carter-Hoffmann at: Carter-Hoffmann 1551 McCormick Ave. Mundelein, Illinois, 60060 USA Phone: 847-362-5500...
- Page 14 Carter-Hoffmann A Division of Carrier Commercial Refrigeration 1551 McCormick Ave. Mundelein, Illinois, 60060 USA Phone: 847-362-5500 Toll Free (USA and Canada): 800-323-9793 Fax: 847-367-8981 After Hours Emergency: 800-421-3744 Service E-mail: service-carterhoffmann@carrier.utc.com Sales and Marketing E-mail: sales-carterhoffmann@carrier.utc.com Company Website: www.carter-hoffmann.com PRINTED IN UNITED STATES OF AMERICA file: 305986CH Rev.(-) 050624...
