TV One ATSC-100 User Manual

ATSC-100 Digital Terrestrial HDTV Receiver provides
an inexpensive yet high quality way to view local, off-air
HDTV Stations on a non-HD TV Set. The unit has both
Component and Composite Video outputs as well as
Stereo Audio. Comprehensive On-Screen Displays allow
the user to control the unit as well as view the Electronic
Program Guide (EPG).
Multiple profiles can be created and stored so that the
image will be best for the type of programming viewed
and closed captioning is fully supported as well as V-
Chip parental content control. Automatic channel scan is
standard and individual channels can also be added
manually. Audio levels are fully adjustable and a
Favorite Channel list can be constructed so that it isn't
necessary to scan through channels that are of no
interest to the viewer.
Displayed aspect ratios may be either 4:3 or 16:9 and
the unit can be controlled via panel mounted switches as
well as Infrared remote control. A transmitted resolution
display is provided so that the viewer can instantly
determine when High Definition programming is being
provided by the broadcaster. Output resolution can be
set to 480p, 720p or 1080i in the YPbPr mode as
needed for the type of display being used.
An optional indoor antenna, the ATSC-A50, is available
for those persons living near (<25 miles) to the television
transmitter who have no line of sight obstructions
present and do not wish to install an external antenna.
The antenna is designed to receive all channels and is
powered via an included DC power supply. It features a
built-in high gain amplifier

Specifications

RF Input Connectors

ATSC Channels 2-69

Video Output Connectors

Composite Video
Component Video

Audio Output Connectors

Stereo Audio

HDTV System Supported

US HDTV System

Video Signals Supported

HDTV Signals
SDTV Signals

Audio Signals Supported

MPEG-1
Sample Rate

Output Video Signals

Composite
Component

Audio Output Signals

Signals Supported
Signal Level
Warranty
Limited Warranty
www.tvone.com •
1x "F" Type Female
1x RCA Female
3x RCA Female
2x RCA Female
ATSC 8VSB
480p, 720p, 1080i
480i
Layer I & II
32 Khz, 44.1 Khz, 48 Khz
NTSC, 480i
YPbPr
Stereo, L/R or Mono L+R
2 Vpp +/- 1%
2 Years Parts and Labor
•
www.tvone.co.uk www.tvonela.com
HDTV Off-Air Receiver
Model ATSC-100

Key Features of the ATSC-100

• Receives all US Terrestrial HDTV Signals
• 1080i, 720p, 480p, 480i Resolutions Supported
• YPbPr HDTV Component or CV SDTV Outputs
• 16:9 or 4:3 Aspect Ratios available
• Comprehensive On Screen Display (OSD) System
• Transmitted Resolution Display
• Favorite Channel lists and Ratings Limits
• Multiple User Profiles can be stored
• 7 Day Electronic Program Guide Display
• V-Chip MPAA Rating Supported
• Closed Captioning Supported
• Optional ATSC-A50 Indoor Antenna
Mechanical
Size (H-W-D)
Weight (Net)
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity

Power Requirements

External Power Supply
Regulatory Approvals
Receiver
Power Adaptor

Accessories Included

1x AC Power Adaptor
1x Remote Control
1x HDTV Video Cable
1x A/V Cable
1x Operations Manual
Optional Accessories
ATSC100-A50
Product Item Number
•
www.tvoneasia.com
ATSC-100 Receiver
pictured with an
ATSC-A50Antenna
1.4"x7.7"x 5.1" (35x197x130mm)
1.0 lbs (454g)
0° to 40° C (+32° to +104° F)
20% to 90% Non-condensing
-20° to +60° C (+20° to +140° F)
20% to 90% Non-condensing
+12VDC@1A
FCC, CE, RoHS
UL, CE CSA, RoHS
12 Volts @ 1A
Infrared Type
Component Video
Composite Video & Stereo Audio
Digital Indoor HDTV Antenna
ATSC-100 HDTV Receiver
•
