Summary of Contents for record-USA 5100 Series
-
Page 1: Table Of Contents
AAADM American Association of Automatic Door Manufacturers AUTOMATIC SLIDING DOOR OWNER'S MANUAL Distributed by: Contents Section Page Caution To Our Customers Service Availability Compliance with Safety Standards What You Should Know Daily Safety Check Operation Limited Warranty 3/6/06... -
Page 2: Caution
CAUTION An Improperly Adjusted Door can cause injury and/or equipment damage. Inspect door operation daily using safety checklist in Owner's Manual and at door. Have door adjusted as described in Owner's Manual. Safety devices should be in place and operational. Have door inspected at least annually by an AAADM certified inspector. -
Page 3: Service Availability
Service Availability Automatic door products are distributed through a nationwide network of authorized automatic door suppliers for sales, installation, and service. Should you need service on your door system, consult the respective door manufacturer or its authorized representative. Compliance with Safety Standards Your door system was designed to the latest operating and safety standards. -
Page 4: Daily Safety Check
Daily Safety Check (All figures and diagrams are for purposes of illustration only) Perform the following safety checks daily on each automatic sliding door to ensure your customers' safety and your own protection. Perform these tests while traffic is restricted from all detection and sensing zones. - Page 5 2. Step through the doorway onto the mat on the other side. Door should remain fully open without interruption. Note: If there is more than one mat on each side, each AUTOMATIC DOOR mat should be tested. Figure 4 3. Step off the mat. After a brief time delay (at least 1 1/2 seconds), the door should close slowly and smoothly IN EMERGENCY without impact.
- Page 6 4. Activating Switch. (Knowing Act) Doors equipped with a AUTOMATIC DOOR manual operate switch shall, when activated, hold the ACTIVATE SWITCH door open for five seconds minimum after release of TO OPERATE activating switch. Figure 9 Doors equipped with manual activating switch shall have a decal as follows: “AUTOMATIC DOOR.
-
Page 7: Operation
OWNER’S MANUAL - SERIES 5100 CONTROL PANEL The Series 5100 Sliding Door System includes an electronic control panel to select the operating mode of the door, and provide feedback on the door status. Included are five pushbutton / keys- turns off automatic motion and allows the door to be moved manually LOCK Note 1: Depending on door configuration, this may close &... -
Page 8: Limited Warranty
This Warranty may not be changed, expanded or modified in any way except in writing, signed by our duly authorized representative. record-USA • 4324 Phil Hargett Court, Monroe, NC 28110 • PO Box 3099 • Monroe, NC 28111-3099 (704) 289-9212 Voice • (800) 438-1937 WATTS • (704) 289-2024 FAX • www.record-usa.com...
