CONTENTS AH-02412 FAMILY ITEM Page Introduction and Characteristics Fire Alarm System Assembly Diagram Fire Alarm Signal Flow Chart Panel Descriptions Standard Detector Wiring Method Method of Wiring Wiring Principle Operating Instructions 1.Fire Surveillance 2.Fire Alarm 3.Reset 4.Fault Alarm 5.Standby Power 6.Alarm Relay Output...
Introduction and Characteristics AH-02412 FAMILY Introduction Due to the creativity and progress of fire fighting technology among highly developed countries, we never give up any chance to upgrade our new generation fire alarm control panel. We are not only pursuing higher technology level, but also compact design to meet national quality standard.
Fire Alarm System Assembly Diagram AH-02412 FAMILY Fire Alarm System Assembly Diagram 1-Heat Detector 2-Smoke Detector 3-Gas Detector 4-Flame Detector 5-Alarm Bell 6-Indicating Lamp 7-Manual Call Point 8-Annunciator 9-Extinguishing Device 10-Control Panel Fire Alarm Signal Flow Chart 4-1.Alarm Bell 2-1.Detector 3.Control Panel...
Panel Description(AH-02412) AH-02412 FAMILY Dimensions and Specifications 130 mm Description 1.Zone Alarm LED 9.Fault LED 2.Zone Fault/Disable LED 10.System Normal LED 3.Zone Disable 11.System Fault LED 4.Silence Sounders 12.Supply Fault LED 5.Mute Internal Buzzer 13.Sounder Fault LED 6.Lamp Test 14.CPU Fault LED 7.Reset...
Page 6
Panel Description(AH-02412E) AH-02412 FAMILY Dimensions and Specifications 130 mm Active (Nac) Trouble Description 11.Fire Alarm LED 1.Zone Alarm LED 2.Zone Fault / Disable LED 12.Fault LED 3.Nac Active LED 13.System Normal LED 4.Nac Fault LED 14.System Fault LED 5.Zone Disable 15.Supply Fault LED...
Panel Description(AH-02412L) AH-02412 FAMILY Dimensions and Specifications Fire Alarm Control Panel AH-02412L Alarm Fault System Normal System Fault Alarm Supply Fault Fault / Sounder Fault Disable CPU Fault Disable Description 10.Sounder Fault LED 1.Fire Alarm LED 11.CPU Fault LED 2.Zone Alarm LED 12.Disable LED...
Standard Detector Wiring Method AH-02412 FAMILY Standard Detector Wiring Method Common Line(Zn-) Detector at the end of every Circult is Connect installed with to Control one terminal Panel resistor 4.7k 1/4W Circuit Line(L) Terminal Resistor 4.7K 4.7K 4.7K Control Panel (C) 1.6mmx1...
Method of Wiring AH-02412 FAMILY Method of wiring AC Power 110V AC 110/220V /220V 50Hz/60Hz Stand by DC 24V/A accroding Power to number of zone Max. connection = Sounder 1 no. of zone x 1.2 Max. connection = Sounder 2 no.
Page 10
Method of Wiring AH-02412 FAMILY Method of Wiring Control Panel Annunciator Reset 24V To Relay Output Device To Relay Output Signal Transfer Device (Voltage Free Contacts) To Relay Output Device To Gas Release Equipment Gas Relay To Gas Release Equipment...
Wiring Principle AH-02412 FAMILY Wiring Principle 1. Wiring Material Table (longer distance excluded; please refer to your local regulation) Specification Quantity Item Depends on zone device, 1.0 ~ 1.2M/M Detector Zone basically 1/zone. No more than 7 zones per 1.2 ~ 1.6M/M Zone Common Line common line.
Operating Instructions AH-02412 FAMILY Operating Instructions 1. Fire Surveillance , After installed system devices into the panel, connect with AC supply source and the "System Normal" indicators will lighten up. Fire Indicating Lamp of the combination PBL box light up and surveillance begins.
Operating Instructions AH-02412 FAMILY 4.Fault Alarm The panel is equipped with "Auto Fault Indication/ Release"function. Should there be a Circuit Break in certain areas, or detachment of the terminal resistor, the "Fault"indicator and the related Zone"Fault/ Disable"indicator will lighten up simultaneously. The internal beeper will sound.
Operating Instructions AH-02412 FAMILY B.12 buttons including 10 numeric,1 select/clear and 1 acknowledge. C.Use S/C for displayed heading selection and information clear, the " " and " " buttons scroll of the manual headings. D.Original screen: first line shows Alarm= 000 Fault= 000 (note: 0 means normal condition);...
Installation Location AH-02412 FAMILY Installation Location Please refer to your local regulation for installation details. Important Notes On Maintenance 1.Normal State of Control Panel (1)Normal Condition (Fire Surveillance Alert) Under normal conditions, the "System Normal" indicator should light up. All other indicators should be OFF for ready status and...
Trouble Shooting AH-02412 FAMILY Trouble Shooting The Control Panel is produced with an advanced technology and delicate design that is easy to assemble. It requires no special skills to trouble-shoot a malfunction, thus avoiding any teething problems that might be encountered during maintenance.
Trouble Shooting AH-02412 FAMILY 4.Combination PBL Fire Indicating Lamp & Alarm Bell Malfunction (1)Remove the external wiring of the Fire Indicating Lamp and Alarm Bell. (2)Measure the ( '+' and '-' ) outlet of Fire Indicating Lamp with a multi-meter and Check whether it is read DC24V. Then perform a fire test.
Trouble Shooting AH-02412 FAMILY 7.Standby Power Fault When there is any problem on Battery, the "Fault" indicator & "Supply Fault" indicator will on and sound. 8.PCB Connection Fault When there is any disconnection between PCBs, the "Fault" indicator will light up &...
Page 19
AH-02412 Fire Alarm Control Panel 2005-04E1...
