- Page 1 User’s Guide IP Camera Quick Installation Guide Part Number 00552-01681 Rev. B Jul. 2007 Trademarks and/or registered trademarks are the property of their respective owners...
- Page 2 The information contained herein is the property of MWR Engineering Co., Ltd., and shall not be reproduced in whole or in part without prior written approval of MWR Engineering Co., Ltd., The information herein is subject to change without notice and should not be construed as a commitment by MWR Engineering Co., Ltd..
-
Page 3: Table Of Contents
User’s Guide Table of Contents Compliance Statement..........................4 Declaration of Conformity ..............................5 Owner’s Record...................................5 Important Notice..................................6 Notes, Cautions, and Warnings............................ 7 How Can I Get Help?................................7 Package Content....................................9 1. Installation ....................................10 1-1 Connect C1002 to your Local Network ..............10 1-1-1 There is DHCP Server in your LAN .............10 1-1-2 There is not DHCP Server in your LAN ............13 1-2 Connect C1002 to your computer directly............16 1-3 Connect C1002 to Internet ..................16... -
Page 4: Compliance Statement
User’s Guide Compliance Statement CAUTION : Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 5: Declaration Of Conformity
Owner’s Record The model and serial number are located at the bottom. Record these numbers in the spaces provided below. Refer to these numbers whenever you call upon your MWR dealer regarding this product. Model No. Clairvoyant1002 Serial No. -
Page 6: Important Notice
User’s Guide Important Notice 1. The Clairvoyant1002 is for indoor use. Note that the CMOS sensor inside the product can be damaged permanently if the camera lens is exposed to direct sunlight. If your application demands prolonged exposure to sunlight, you should consider equipping it with a sun visor. -
Page 7: Notes, Cautions, And Warnings
How Can I Get Help? The following section tells you who to call if you need help. Within China MWR Engineering Co., Ltd. maintains a Customer Service Center at its BUs in Shenzhen, or Taiwan. The phone numbers are: Service Calls (86) 755-2696-6470 (24 hours a day, 7 days a week) (86) 755-2696-6471 ext.:88 FAX... - Page 8 NOTE: Please attach the serial number of the camera. Regional Distributors MWR on Demand Web Page If you have access to the Internet, you can view MWR’s web page at the following address: http://www.mwr.com.tw The web site contains sales, customer service, and technical support...
-
Page 9: Package Content
User’s Guide Package Content 1. Indoor Camera Outdoor Camera 2. Power Adapter : 5VDC, 1A 3. Utility CD :... -
Page 10: Installation
User’s Guide 1. Installation 1-1 Connect C1002 to your Local Network CAUTION: Please use the DC power adapter that is provided with camera. Connecting camera other power source will cause permanent damage camera. NOTE: Please use straight Ethernet cable (CAT. 5e) to connect camera to your home/ office network switch/ hub or a broadband router. - Page 11 User’s Guide “IP Camera Tool” ” in Utility CD will find all the Clairvoyant 1002 IP cameras in your local network. “Double Clicks” or ”Right Click” on the camera you want to connect, choose “Access IP Camera” will bring up IE browser with camera login screen.
- Page 12 User’s Guide Note: You can choose to modify the camera to fixed IP by Choosing “Network Settings” Warning: Please consult your office network administrator to get a free IP for your IP Camera, duplicated IP address will cause undesired problems. Normally you will not need to change the network settings automatically obtained from DHCP server.
-
Page 13: There Is Not Dhcp Server In Your Lan
User’s Guide 1-1-2 There is DHCP Server in your LAN The camera will not be able to get IP from DHCP Server (Factory Setting). Please use “IP Camera Tool” in Utility CD to search and link to cameras. “IP Camera Tool” ” in Utility CD will find all the Clairvoyant 1002 IP cameras in your local network. - Page 14 User’s Guide You must choose “Network Settings” to set the camera to fixed IP. Please modify the “IP Address” to the same subnet of your computer. Normally the IP should start with “192.168.xxx.xxx”...
- Page 15 User’s Guide If you are not sure of your computer IP address, please go to DOS mode by : “START” => “RUN” => Open “CMD” Type “ipconfig /all” at command prompt, You will be able to find you computer network settings. After input correct network settings, press “Set”...
-
Page 16: Connect C1002 To Your Computer Directly
User’s Guide 1-2 Connect C1002 to your computer directly Because there is no DHCP Server available, you have to setup the network settings manually. Please follow the procedures in previous sections (1-1-2) to link to your camera. 1-3 Connect C1002 to Internet Connect IP Camera to your broadband router or NAT gateway. - Page 17 User’s Guide 5. Access camera URL through Internet. Example: http://your_camera.dyndns.org:port Please reference more details of Router & DynDNS setup on Reference User’s Manual.
-
Page 18: Software Installation
User’s Guide 2. Software Installation 2.1 Utility CD. Please insert the “Utility CD” into your CD-ROM drive, auto-run program will start and below screen will guide you through installation. To install software and ActiveX plug-in Please click on the “Install 1st” tab to install software and ActiveX plug-in. - Page 19 User’s Guide Click on “Next”,...
- Page 20 User’s Guide Click on “Close”, The IP Camera search utility software icon will display on your desktop. Click on the “IP Camera Tool” tab to search Clairvoyant 1002 IP cameras in your local network.
-
Page 21: Login & Access Camera Video
User’s Guide 2.2 Login & Access Camera video “Double Clicks” or ”Right Click” on the camera you want to connect, choose “Access IP Camera” will bring up IE browser with camera login screen. There is no Password set by factory default, please leave the Password in”... - Page 22 User’s Guide Note: 1. Clairvoyant 1002 IP camera will required a Microsoft Windows based PC with Media Player 7.0 or later installed. 2. If the video don’t start, please reference the “ActiveX_Security_Setup” manual. 3. If you see only white screen and your camera is in outdoor or expose to strong light, please change the “Mode”...
- Page 23 User’s Guide...
-
Page 24: Configuration Page
User’s Guide 2.3 Configuration Page... -
Page 25: Basic Setting
User’s Guide 2.3.1 Basic Setting Camera Alias : Input the camera name for you to recognize. Password and Confirm Password: password used to login the IP Camera ( Default is blank ) CAUTION: Please always write down the password and keep password in safe place. -
Page 26: Smtp Configuration (E-Mail)
User’s Guide DDNS Setting: Clairvoyant 1002 IP camera supports protocols from two DDNS providers: 1. Oray.net 2. Dyndns.org Domain Name: the second-level name you apply for and acquire at Oray.net or Dyndns.org, please read more details in “Reference User’s manual” User and Password: the user name and password when applying for the DDNS service. -
Page 27: Appendix
User’s Guide Appendix A. Rear Panel LAN: RJ-45/10-100 Base T COM: 1, 4: GND 2: TX RS-232 5: ALM Input 6: Relay, ALM Output 2, 7: RS-232 only for test 7: RX RS-232 8: ALM GND 3: +5V（100mA）Voltage Output DC5V: 5V/1A Power supply... -
Page 28: Technical Data
User’s Guide B. Technical Data Image System - Compression: Motion JPEG hardware compression - 350,000 pixels CMOS sensor - f: 6.0mm to infinity, C/CS mount lens - Min. 2.0 to 3.0 Lux (Indoor version) - Min. 0 Lux with IR Leds (Outdoor version) - Automatic Exposure Control - Automatic Gain Control - Automatic Brightness Control... -
Page 29: Cross Ethernet Cable Making Tip
User’s Guide C. Cross Ethernet Cable Making Tip I. LAN Plug Pin: 1 ~ 8 II. LAN Cable PART-A PART-B III. Connection Method a. Connect LAN Cable Part-A and LAN plug by order as one to one . b. Connect to LAN cable Part-B & Part-A, Replace order No.1 & 3, No.2 & 6. c. -
Page 30: Clairvoyant User's Manual
Thank you for your input. NAME __________________________________________DATE_____________________ COMPANY__________________________________________________________ ADDRESS ___________________________________________________________________ PHONE ___________________________________________________________________ MANUAL TITLE: Clairvoyant1002 User’s Guide 00552-01681 Rev. A Oct. 2005 PART NUMBER: PUBLICATION DATE: COMMENTS ________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________... - Page 31 User’s Guide ========================== The End =========================...
