Fingerprint Lock User Manual
Version: 1.0
Date: Sept. 2010
About This Manual
This manual introduces the fingerprint lock interface and menu operations. For the
fingerprint lock installation, see the animated installation instructions.
Our products are subject to update from time to time, so our company
will neither make a commitment to guarantee the consistency between the
actual products and this document, nor assume any responsibility for any
dispute arising out of the discrepancy between the actual technical parameters
and this manual. This document is subject to change without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L7000 and is the answer not in the manual?

Questions and answers

Summary of Contents for ZK Technology L7000

  • Page 1 Fingerprint Lock User Manual Version: 1.0 Date: Sept. 2010 About This Manual This manual introduces the fingerprint lock interface and menu operations. For the fingerprint lock installation, see the animated installation instructions. Our products are subject to update from time to time, so our company will neither make a commitment to guarantee the consistency between the actual products and this document, nor assume any responsibility for any dispute arising out of the discrepancy between the actual technical parameters...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents 1. Instruction for Use ........1 1.1 Functions Introduction................ 1 1.2 List of Installation Accessories............3 1.3 Fingerprint Press Introduction ............5 1.4 Installation Requirements ..............6 1.4.1 Precautions .................. 6 1.4.2 Use Backup Battery..............8 1.4.3 Backup (Emergency) Mechanical Key........
  • Page 4 Fingerprint Lock User Manual V1.0 3. Lock Function and Settings.....27 3.1 Operation Settings ................27 3.1.1 Operate Alarm Setting ............... 28 3.1.2 Illegal Times ................28 3.1.3 Lock Setting ................29 3.1.4 Verify Mode Setting ..............29 3.1.5 Normal Open Setting..............30 3.2 Language Settings ................

  • Page 5: Instruction For Use

    1. Instruction for Use 1. Instruction for Use Functions marked with “★” in this manual are only supported by specific product or customized product and will be marked below. 1.1 Functions Introduction By leveraging the perfect combination of biometrics and cryptography, our fingerprint locks ensure double security through the fingerprint plus password unlocking feature.
  • Page 6 Fingerprint Lock User Manual V1.0 Single latch lock (support both 60mm and 70mm locks) of American standard supports deadbolt lock either. The max user capacity is 500 fingerprints. The max unlocking record is 30000 logs. Unlock mode: fingerprint, password, mechanical key.

  • Page 7: List Of Installation Accessories

    1. Instruction for Use 1.2 List of Installation Accessories 15 installation disk...

  • Page 8: List Of Installation Accessories

    Fingerprint Lock User Manual V1.0 List of Installation Accessories Name Quantity Unit Remarks Front panel assembly Square shaft of One need to select base on the handle door thickness Lock body Single latch lock Including the one on the front Waterproof washer panel assembly Rear hold-down plate...

  • Page 9: Fingerprint Press Introduction

    1. Instruction for Use 1.3 Fingerprint Press Introduction Enroll fingerprint by pressing index finger, middle finger or ring finger (thumb and little finger are clumsy) . Proper press: Make finger center pressed on the sensor window. Improper press: Upright Too lean Too downward Slant Please adopt the correct way to place the finger to avoid improper...

  • Page 10: Installation Requirements

    Fingerprint Lock User Manual V1.0 1.4 Installation Requirements 1.4.1 Precautions 1. The fingerprint lock is applicable to doors of 35–70 mm in thickness. Be sure to list your special requirements or remarks for fingerprint locks to be installed on doors in excess of 70 mm in thickness before placing an order. 2.
  • Page 11 1. Instruction for Use 4. Ensure the central point of the handle is about 1 meter above the floor. 5. Ensure all the accessories installed on the right position. 6. Please follow the animated instructions to install fingerprint locks. Recommended Tools: You may need the following tools while following the instructions to install fingerprint locks: ...

  • Page 12: Use Backup Battery

    Fingerprint Lock User Manual V1.0 1.4.2 Use Backup Battery The fingerprint lock supports temporary use of external DC power for fingerprint or password matching and unlocking, but when connected with an external battery, the fingerprint lock cannot provide such special functions as enrollment, deletion and setting, so as to prevent data loss as a result of power instability.

  • Page 13: Backup (Emergency) Mechanical Key

    1. Instruction for Use 1.4.3 Backup (Emergency) Mechanical Key 1. Remove the screw from the lock 2. Insert the key, turn to right or handle, and take off the handle. left 180º to unlock the door. 1.4.4 Convert of Unlock Direction Waterproof washer 1.

  • Page 14: Front And Rear Views

    Fingerprint Lock User Manual V1.0  Note: In converting of unlock direction, you just need to rotate the lock body 180º entirely. 1.5 Front and Rear Views Front view: Number key 1 OLED display (“ESC” key) Number key 4 Number key 2 (“”...
  • Page 15 1. Instruction for Use Rear view: Battery cover Battery Band switch USB Port (optional) Handle Number key 1: Press this key to exit current operation, press and hold this key to power off the fingerprint lock. The number key “1” doubles as ESC key. Number key 2: This key is used to manually increase (when held this key, the display values will rapidly increase) the setup value or navigate among menu options.
  • Page 16 Fingerprint Lock User Manual V1.0 when an operation succeeds. Band switch: If you cannot access the menu options due to the loss of administrators for some reason, proceed as follows: Press and hold the Menu key for three seconds to display the administrator verification, and then turn the Band switch at the rear of the lock to the left or right to open up the menu as a super administrator.

  • Page 17: Precautions

    1. Instruction for Use information and unlocking records through a USB pen drive. Only some models have USB port options. 1.6 Precautions 1. We strongly recommend you to enroll at least one administrator after installing the fingerprint lock. You must at least enroll one administrator before enrolling ordinary users.

  • Page 18: Time Setting

    Fingerprint Lock User Manual V1.0 1.8 Time Setting You need to set the correct date and time on first use of a fingerprint lock in the following steps: 1) Power on the fingerprint lock by pressing the 02: 30: 30 Menu key to open up the initial interface, as shown FP LOCK in the figure on the left.

  • Page 19: Operation Overtime

    1. Instruction for Use 5) Press Menu to select "Date Time". System Opt. ↓ ►Date Time Language English Dev Num YYYY-MM-DD 24H 6) To modify date or time, press 2/3 to move the 2009-01-01 9: 34: 29 cursor to the desired option, and then press 2/3 again to enter correct date or time.

  • Page 20: Enrollment And Verification

    Fingerprint Lock User Manual V1.0 2. Enrollment and Verification 2.1 Enroll an Administrator If the fingerprint lock has no administrator, you must at least enroll one administrator before enrolling ordinary users. To enroll an administrator, proceed as follows: 1) Power on the fingerprint lock by pressing the 02:30:30 Menu key to open up the initial interface.

  • Page 21: Enroll A Fingerprint

    2. Enrollment and Verification 2.1.1 Enroll a Fingerprint 4) Enter “Enroll Admin” interface according to the Enroll Admin ↓ ► Enroll FP operation in 2.1 Enroll an Administrator step 1), 2), Enroll Pwd 3). Press 3 to select “Enroll FP” and then press Menu.

  • Page 22: Enroll A Password

    Fingerprint Lock User Manual V1.0 9) The system will prompt to save the enrollment New Enroll information after enrollment successful. If the 00001-0 enrollment fails, the system will prompt if re-enroll OK(Save) fingerprint. The system returns to the “New Enroll” interface upon successful enrollment.

  • Page 23: Enroll An Ordinary User

    2. Enrollment and Verification 7) The system by default assigns unused user IDs New Enroll from 00001 and you may also manually enter an UserID 00001 unused user ID. 8) Input a password by pressing the number keys New Enroll and press Menu to confirm your input.
  • Page 24 Fingerprint Lock User Manual V1.0 operation steps as follows: 1) Power on the fingerprint lock by pressing the 02: 30: 30 Menu key to open up the initial interface. FP LOCK 2) Press and hold the Menu key to access the menu. Admin Confirm The system prompt for administrator confirmation.

  • Page 25: Backup Enrollment

    2. Enrollment and Verification User Manage ↓ ► Enroll User 5) Press 3 to select “Enroll User” and then press Enroll Admin MENU. Delete User Enroll User ↓ ►Enroll FP 6) Enter the user enrollment interface. Enroll PWD After that, the enrolled administrator can perform fingerprint and password enrollment.

  • Page 26: User Verification And Set No Status

    Fingerprint Lock User Manual V1.0  Note: (1) It is a wise choice to enroll fingerprints of at least two different fingers for long-standing users. (2) If you wish to modify the password after finishing password enrollment, you can replace the original password with the password entered in backup enrollment. 2.4 User Verification and Set NO Status 1) Press the Menu key to display the initial 02: 30: 30...

  • Page 27: Delete User Information

    2. Enrollment and Verification  Note: You can only match fingerprints when the fingerprint lock is in non-NO state. 3) Your ID number will be displayed on the screen upon successful verification and then you can hear the unlocking sound. Rotate the handle of the User ID: 00001 fingerprint lock within 4 seconds to open the door.
  • Page 28 Fingerprint Lock User Manual V1.0 1) Power on the fingerprint lock by pressing the 02:30:30 Menu key to open up the initial interface. FP LOCK 2) Enter the administrator password or match your Admin Affirm fingerprint once. Skip to step 4) if verification FP LOCK succeeds;...
  • Page 29 2. Enrollment and Verification 5) Press 3 to select “Delete User”, and then press Menu ↓ Menu. ►Enroll User Enroll Admin Delete User Delete User 6) Press 2/3 to select the desired delete ID number, Enroll ID 00002 and then press Menu to confirm. In deleting user fingerprint: Delete fingerprint 00002—0...
  • Page 30 Fingerprint Lock User Manual V1.0 Del User 10) Press Menu to finish the user deletion,. User Delete! can restart the power, then verify the fingerprint that have been deleted, to check whether it or not.  Note: The Administrator (include super administrator) can only delete ordinary user.

  • Page 31: Lock Function And Settings

    3. Lock Function and Settings 3. Lock Function and Settings 3.1 Operation Settings 1) Press Menu and the device power on, enter the 02:30:30 initial interface. Long press Menu to enter menu. FP LOCK 2) Input administrator password or press the Admin Affirm administrator fingerprint.

  • Page 32: Operate Alarm Setting

    Fingerprint Lock User Manual V1.0 Set Opt. ↓ Verify Mode Operate Alarm Yes Normal Open Illegal Times Lock 3.1.1 Operate Alarm Setting It is used to set if the operation failure trigger the alarm. Operate the step 1), 2), 3), 4) in 3.1 Operation Set Opt.

  • Page 33: Lock Setting

    3. Lock Function and Settings modification, press Menu to save and quit. If the number of cumulative failures exceeds the threshold, the fingerprint lock will automatically power off. After device restart the fingerprint lock will generate an invalid operation alarm of buzzer sound. About 30 seconds it will power off automatically.

  • Page 34: Normal Open Setting

    Fingerprint Lock User Manual V1.0 Verify Mode 0: Only the administrator can open the lock, while the unlocking function is disabled for ordinary users. Verify Mode 1: This is a default matching mode. Users can open the lock by successfully matching their fingerprints only once. Verify Mode 2: This is a dual verification mode.

  • Page 35: Language Settings

    3. Lock Function and Settings 4) After successful setting, the screen display as left figure. That indicate the setting is success, and the buzzer sound 3 times for prompt. Normal Open 5) To disable the NO function, power on the system 02: 30: 30 and press Menu in the “Normal Open”...

  • Page 36: Advanced Settings

    Fingerprint Lock User Manual V1.0 Options 4) Press 3 to select “System Opt”, and press Menu Operate Opt to enter the menu. ►System Opt Adv Option System Opt ↓ Date Time ►Language Dev Num 5) In “Language Option” menu, press 3 to select the language, and press Menu to enter modification state.
  • Page 37 3. Lock Function and Settings 02:30:30 1) Press Menu and the device power on, enter the FP LOCK initial interface. Long press Menu to enter the menu.. Admin Affirm 2) Enter the administrator password or match your fingerprint once. Enter the next step after successful FP LOCK verification.

  • Page 38: Browse System Information

    Fingerprint Lock User Manual V1.0 5) Select “Adv Options” under the System Opt Adv Options ↓ Reset Opts menu, and then press Menu to enter the advanced Del Logs option interface. Clear All Data Clear Admin Pri The advanced options include Reset Options, Delete Logs, Clear All Data and Clear Administrator Privilege.
  • Page 39 3. Lock Function and Settings 1) Press Menu and the device power on, enter the 02:30:30 initial interface. Long press Menu to enter menu. FP LOCK Admin Affirm 2) Enter the administrator password or match your FP LOCK fingerprint once. Enter the next step after successful verification..

  • Page 40: Browse Logs

    Fingerprint Lock User Manual V1.0 see the detail. Free Space Info FP Cnt 29915 S Logs 4095 Dev Info: Press 2/3 to select “Device information”, and press Menu to see the details as follows: Dev Info ↓ Serial Num FPCnt(100) Vendor Log (10k) Device Name...

  • Page 41: Usb Pen Drive Management (Optional)

    3. Lock Function and Settings 2--1 The first digit denotes the 00001 total number of records and 2009-04-05 14: 49 the last one denotes current Back record. 3.6 USB Pen Drive Management (Optional) USB port 1) Insert a USB pen drive into the USB port. 02:30:30 2) Press Menu to power on, and enter the initial FP LOCK...
  • Page 42 Fingerprint Lock User Manual V1.0 5) The device prompt “PenDrive Mng”, press Menu to enter the management interface. PenDrive Mng 6) Press Menu to enter the next interface. PenDrive Mng ►DwnLoad Log DwnLoad User Upload User Upd Firmware 1. Download Attendance Logs 1) Press 2/3 to select “Dwn AttLog”...
  • Page 43 3. Lock Function and Settings User data downloading is similar to the downloading of attendance logs. Enter the “PenDrive Mng” menu according to the procedure steps of 1), 2), 3), 4), 5), 6) of USB PenDrive Management. Press 2/3 to select “DwnLoad User”, the files user.dat (user information) and template.dat (fingerprint template) will be concurrently downloaded to the USB pen drive.

  • Page 44: Conventions On Other Functions

    4. Conventions on Other Functions 4. Conventions on Other Functions 4.1 Routine Operation Indications User operation success indication: The buzzer sounds once and the green LED indicator is solid on for 3 seconds. User operation failure indication: The buzzer sounds short tone twice and the red LED indicator is solid on for 3 seconds.

  • Page 45: Battery Low Voltage Protection

    4. Conventions on Other Functions 4.3 Battery Low Voltage Protection Low Voltage Protection: When the battery meter stays at one bar, the system prompts you to replace the battery and the battery icon starts flashing. If you press and hold the Menu key, the system prompts you that you cannot access menus. In addition, the menus are also inaccessible during use of external power so as to prevent data loss caused by power instability.

  • Page 46: Appendix: Technical Specifications

    5. Appendix: Technical Specifications 5. Appendix: Technical Specifications  Screen: OLED display;  Sensor: Optics sensor without coating;  Capacity: 500 fingerprint images; 100 passwords; 500 users;  Verification mode: Fingerprint, password, Fingerprint plus password, matching;  Record capacity: 30000; ...
  • Page 47 5. Appendix: Technical Specifications This document is subject to change without prior notice. Printed in China...
