H2O Audio Oceanic DV Series D2-1C1 User Instruction Manual

H2o audio waterproof carrying case for the iriver ifp-700 series user instruction manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER INSTRUCTION MANUAL
Before using this system, please be sure to read,
understand, and follow the instruction of this manual.
H
O Audio
TM
2
Oceanic DV Series
iRiver 300 Series MP3 Players
Manufactured by: Diver Entertainment Systems Inc.
www.desworldwide.com
Copyright Notice:
This owner's manual is copyrighted, all rights reserved. It may not, in whole or in part, be copied, photocopied, reproduced,
translated, or formed into any electronic format without prior consent in writing from Diver Entertainment Systems Inc.
iRiver is a registered trademark of iRiver Limited. Oceanic is a registered trademark of Oceanic Worldwide.
Several patents have been issued on this product; Others are also Pending.
P/N DV-0404: rev.17A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Oceanic DV Series D2-1C1 and is the answer not in the manual?

Questions and answers

Related Manuals for H2O Audio Oceanic DV Series D2-1C1

Summary of Contents for H2O Audio Oceanic DV Series D2-1C1

  • Page 1 USER INSTRUCTION MANUAL Before using this system, please be sure to read, understand, and follow the instruction of this manual. O Audio Oceanic DV Series iRiver 300 Series MP3 Players Manufactured by: Diver Entertainment Systems Inc. www.desworldwide.com Copyright Notice: This owner’s manual is copyrighted, all rights reserved. It may not, in whole or in part, be copied, photocopied, reproduced, translated, or formed into any electronic format without prior consent in writing from Diver Entertainment Systems Inc.

  • Page 2: Fcc Certification

    INTRODUCTION: The H O Audio DV system enables you to listen to digital audio while S.C.U.B.A. diving or snorkeling. The system is designed to provide high fidelity audio to a depth of 200 feet (66 m). It utilizes the latest MP3 player technology capable of playing both MP3 and WMA files.
  • Page 3 IMPORTANT WARNING: Pay special attention to these labels: WARNING: Could cause injury to the user. CAUTION: Could cause damage to the product and/or injury to the user. READ THIS MANUAL CAREFULLY. IF YOU HAVE ANY QUESTIONS PLEASE CONTACT YOUR NEAREST DEALER OR CUSTOMER SUPPORT PRIOR TO USE.
  • Page 4 LEAK TEST: Before utilizing the system for the first time, it is highly recommended to perform a 'Leak Test’. Follow the instructions below, but DO NOT INSTALL THE MP3 PLAYER inside the housing for the leak test. 1. Visually inspect the main housing seal by opening the unit. Verify the seal is seated as intended and the O-ring is clean of any artifacts, then close and lock the housing using the OPEN-CLOSE Dial.
  • Page 5 O-RING PREPARATION: 1. Gently Remove the O-ring with the Remover. Be careful not to stretch the O-ring CAUTION: Never use a sharp or metal object to remove O-rings as they damage the O-ring or the O-ring groove contact surface. Use only the O-ring Remover Tool included in the packaging. Check the O-ring for hair, sand, lint, or other debris and wipe clean as necessary.

  • Page 6: General Storage Procedures

    GENERAL STORAGE PROCEDURES: For long-term storage, remove O-ring and store out of direct sunlight. If the O-ring will not be used for a long period of time, remove from it the housing and store in a plastic bag out of direct sunlight. If the O- ring is stored in a dry environment for a long period of time, it will develop cracks and become unusable.
  • Page 7 HOUSING OPERATIONS: Button 1: MP3 ON/OFF/Play/Stop Open the Housing STEP 1: Pull out the Tab STEP 2: Rotate the Dial counterclockwise CAUTION: If the housing has been subjected to pressure and become ‘tighter’ more difficult to open than usual, in this case, rotate the dial a little more strongly than usual.
  • Page 8 Button 4: Amplifier Power ON/OFF Lever 2: Volume CAUTION: This device provides powerful amplification of the audio signal beyond the normal output of standard stereo devices. This system is specifically engineered for underwater use to enhance fidelity at depth. This power amplifier is powerful and must be used carefully.
  • Page 9 INSTALLING & REPLACING AMPLIFIER BATTERY: STEP 1: WIPE EXTERIOR AND MAKE SURE IT IS DRY STEP 2: TURN OFF THE AMPLIFIER STEP 3: OPEN HOUSING CAUTION: Completely dry the inside of any moisture STEP 4: REMOVE AND UNPLUG THE MP3 PLAYER...

  • Page 10: Installing The Mp3 Player

    INSTALLING THE MP3 PLAYER: CAUTION: Before opening be sure to rinse the sealed system in fresh water. Before installing the MP3 player, make sure the housing interior is dry. Moisture in the housing can cause damage to the electronics. STEP 1: DRY THE EXTERIOR Note: Use a soft clean cloth.

  • Page 11: Step 6: Seal Check

    STEP 5: CLOSE THE LID Begin to close the lid by bringing it down towards the housing. Make sure the Lever Controls are lined up with the Joysticks on the MP3 Player. CAUTION: Make sure the lid is free of any lint, hair, sand, or other items. DO NOT FORCE THE LID CLOSED.
  • Page 12 TO OPEN STEP 7: Insert a NEW & DRY 9-Volt Alkaline battery. CAUTION: Visually inspect the inside to make sure it is dry. STEP 8: SLIDE IN TO CLOSE STEP 9: PUSH DOWN STEP 10: SNAP CLOSE STEP 11: Insert and connect the MP3 Player STEP 12: Turn on the Amplifier using the external button.
  • Page 13 REMOVING THE MP3 PLAYER: STEP 1: TURN OFF THE AMPLIFIER STEP 2: WIPE DOWN THE EXTERIOR WITH CLEAN FRESH WATER STEP 3: WIPE THE UNIT DRY STEP 4: CAREFULLY OPEN THE HOUSING STEP 5: TURN HOUSING TO SIDE AND LET MP3 PLAYER SLIDE OUT INTO YOUR PALM STEP 6: UNPLUG THE STEREO ADAPTER STEP 7: REMOVE THE MP3 PLAYER...
  • Page 14 INSTALLING THE STEREO JACK: STEP 1: LINE UP CONNECTOR WITH MP3 PLAYER STEREO JACK NOTE: Make sure you plug the connector into the stereo jack. Some of the higher end 300 Series also includes an input jack for a recording device. Make sure you know the difference.
  • Page 15 SPEAKER MASK STRAP OPERATION: SPEAKER AMPLIFIER OPERATIONS: Care must be taken when handling the speakers. Do not let the speakers hang freely from the housing. Maintain control of the speakers at all times. CAUTION: Failure to maintain control of the speakers during handling may result in damage to the speakers and compromise the integrity of the speaker set.
  • Page 16 REMOVING/REPLACING THE SPEAKER CLIP: CAUTION: Make sure that you are holding the mask on your face when entering the water. The speakers may try to pull the mask off the face when entering the water, so pay special attention to keeping the mask on your face.

  • Page 17: Limited Warranty Coverage

    LIMITED WARRANTY COVERAGE: Diver Entertainment Systems Inc. (DES) guarantees, to the original purchaser only, that the equipment purchased (EXCLUDING THE MP3 PLAYER) is free of defects in material and/or under normal recreational SCUBA use for a period of one year (1) from date of consumer purchase from an Authorized DES Dealer; provided that proper care and maintenance have been performed as prescribed by the owner's guide included with the equipment.

  • Page 18: Returning For Service

    RETURNING FOR SERVICE: Prior to any return, a Return Authorization (RA) number must be attained. Proof of purchase from an Authorized Dealer will be required. Contact Custom Support to attain the RA number and shipping instructions. CORRESPONDENCE: WARRANTY A copy of the original sales receipt and a copy of the owner’s portion of the warranty card must accompany all correspondence regarding the equipment covered by this warranty agreement or in direct reference to this warranty.
