Video CatCam
II User Manual
Revision: 18. March 2010
Check for updates on:
www.mr-lee.com
Mr. Lee CatCam and CatCam are registered trademarks of Juergen Perthold.
Index
Index..............................................................................................................1
Change History ..............................................................................................2
1. Overview....................................................................................................3
2. Charge Camera .........................................................................................4
3. Activate Camera ........................................................................................6
4. Setting of Recording Interval......................................................................7
5. Change Time Stamp..................................................................................8
6. Collar Attachment ......................................................................................9
7. Video Storage and Download ..................................................................10
8. Support and Help.....................................................................................10
Video CatCam User Manual - Page 1 of 10
Advertisement
Table of Contents
Summary of Contents for Juergen Perthold Video CatCam II
-
Page 1: Table Of Contents
® Video CatCam II User Manual Revision: 18. March 2010 Check for updates on: www.mr-lee.com Mr. Lee CatCam and CatCam are registered trademarks of Juergen Perthold. Index Index......................1 Change History ....................2 1. Overview....................3 2. Charge Camera ..................4 3. Activate Camera ..................6 4. -
Page 2: Change History
Change History We try to keep this manual up-to-date. Therefore changes and additions are made. You may want to check from time to time for updates so that you have the most recent issue available. Revision Date Changes March 18, 2010 Initial revision Video CatCam User Manual - Page 2 of 10... -
Page 3: Overview
1. Overview ® The Video CatCam records video clips in an adjustable time interval. When nothing is recorded the camera switches off automatically and safes battery energy. The device is designed to be worn on the collar of an animal (cat) but may find use for general surveillance tasks as well. -
Page 4: Charge Camera
2. Charge Camera To connect the camera to the USB interface the enclosure must be opened and the camera core pulled out as shown in the picture After the camera core is removed the USB interface as well as the micro SD memory card is accessible. - Page 5 The camera is supplied by an integrated rechargeable Lithium-Polymer battery. Charging of the camera takes 3-4 hours. After charging or data transfer put the camera core back into the enclosure as shown in the following picture. Then close the lid. For additional protection you may want to use some tape to keep the lid closed.
-
Page 6: Activate Camera
3. Activate Camera After the battery is charged the camera can be activated. Press shortly on the button in the enclosure. The status light (marked by a circle) comes on. As long as the device is active the status light blinks shortly every few seconds. Press again on the button to switch the camera off. -
Page 7: Setting Of Recording Interval
4. Setting of Recording Interval The available recording time which means memory capacity and battery energy can be spread over a longer time. The following graphic shows this. If added together both bars have the same length. Chopping the recording time into smaller pieces extends the coverage to a longer time. -
Page 8: Change Time Stamp
5. Change Time Stamp The video picture is overlaid with the recording time. This time can be adjusted. Procedure: 1. Open notepad or any other text only editor 2. write: this is setting the date to Dec. 29, [date] 2009/12/29 16:58:00_ 2009 and the time to 4pm 58 minutes. -
Page 9: Collar Attachment
6. Collar Attachment The collar is fed through both loops and then attached around the neck of the animal. Safety note: Please consider that a collar on a neck of a cat is a potential safety risk. Because a cat wanders and crawls more or less in any place and can catch or trap itself with the collar on an object such as fence rods or tree branches. -
Page 10: Video Storage And Download
of your pet. In the USA are collars common which provide a safety release if a certain amount of force is applied. Everything mounted to the collar will be lost in such a case. Please decide what is more important: The life of your pet or the device on the collar. 7.
