Summary of Contents for Axminster EBV260BN
- Page 1 EBV260BN Blower Vac Axminster Reference No: EBV260BN Part No: 211927 w w w. a x m i n s t e r. c o . u k...
- Page 2 INTRODUCTION EBV260BN engine blower has been designed and built to deliver superior performance reliability without compromise to quality, compromise to quality, comfort, safety, or durability EBV260BN high performance engines represent the leading edge of 2-cycle engine technology, delivering exceptionally high power at remarkably low displacement and weight .
-
Page 3: Table Of Contents
CONTENTS Attention Statements………………………3 Product Description……………………… 4 Specifications………………………………4 Assembling the Machine……………………5 Mixing Fuel…………………………………8 Filling the Fuel Tank…………………………9 Starting the Machine…………………………10 Adjusting Engine Speed……………………13 Routine Maintenances………………………15 Storage………………………………………17 Troubleshooting………………………………18... -
Page 4: Attention Statements
ATTENTION STAEMENTS This manual contains special “attention statements” surrounded by boxes and preceded by the triangular Attention Symbol CAUTION! WARNING! A statement preceded by A statement preceded by WARNING contains word “CAUTION” Information that should be contains information that acted upon to prevent should be acted upon to serious bodily injury. -
Page 5: Product Description
If you have any question regarding your EBV260BN blower ￡ vacuum, or if you do not understand something in this manual, your dealer will be glad to assist you. -
Page 6: Assembling The Machine
ASSEMBLING THE MACHINE 1. Assembling the vacuum (1) Nomenclature Inhale pipe Discharging NO.1 pipe Inhale pipe NO.2 Dust bag Lower handle Fan cover (2)Assembly Open the fan cover, Insert discharging pipe into dust connect inhale pipe bag from the jaws of the slide No.1 and No.2 fastener according to the picture discharging pipe. - Page 7 discharging pipe Put the discharging pipe to the machine. Herein, use screw M5×10 to reinforce. 2. Install blower machine (1) Terms Stop switch Throttler lever handle Cleaner cover Starter handle Fuel tank Lower handle...
- Page 8 Blow pipe A Blow pipe B (2)Install Put blow pipe B to the machine Put blow A to B by by rotating rotating Use screw M5×10 to reinforce IMPORTANT! Mix only enough fuel for your immediate needs! If fuel must be stored longer than 30-days,it should first be treated with a stabilizer or equivalent product!
-
Page 9: Mixing Fuel
WARNING! Danger form rotating impeller! Stop the engine before installing or removing the machine tubes! Never perform any maintenance or assembly procedures on this machine while the engine is running. MIXING FUEL Fuel requirements □ Use only fresh, clean fuel □... -
Page 10: Filling The Fuel Tank
WARNING Danger of fire! Never transfer or store fuels in the presence Of combustible materials! Before starting the engine, always move the machine to a clear area at least 10-feet (3-meters) away form fuels and other combustible materials! IMPORTANT! Mix only enough fuel for your immediate needs! If fuel must be stored longer than 30-days, it should first be treated with a stabilizer or equivalent product! FILLING THE FUEL TANK... -
Page 11: Starting The Machine
□ Never smoke or light any fires near the blower or fuel! □Always transport and store fuels in an approved container! □ Never place flammable maternal close to the engine muffler! □ Never operate the blower without a properly functioning muffler and spark arrestor installed! □... - Page 12 WARNING! The recoil starter can be damaged by abuse! <Never pull the starter cord to its full length! <Always engage the starter before cranking the engine! <Always rewind the starter cord slowly! Never operate the machine if the tubes are missing or damaged Starting procedure 1.
- Page 13 When the engine starts IMPORTANT For maximum vacuum performance and operating life, allow the engine to warm before use. 1. Run the engine at idle speed until operating temperature is reached(2 to 3 minutes) 2. As the engine warms, open the choke gradually by slowly pushing the choke control in to the fully retracted position.
-
Page 14: Adjusting Engine Speed
4. Install the spark plug and firmly tighten it with the spark plug wrench. If a torque wrench. If a torque wrench is available, torque the spark plug to 148-165 inch-pounds. Reconnect the spark plug lead. 5. Repeat the starting procedures for “ warm engine” 6. - Page 15 2. Stop the engine by pulling the stop switch. (1) Machine noise increases at higher throttle setting! Always use the lowest throttle setting required to get the job done! (2) Never operate the blower when visibility is poor. (3) Always wear eye protection such as face shield or goggles while operating this machine.
-
Page 16: Routine Maintenances
ROUTINE MAINTEANCES Daily maintenance □ WARNING! Remove dirt Before performing any maintenance and debris on this machine, stop the engine and from the blower disconnect the spark plug wire! Exterior. □ Inspect the engine, tank ,and hose for possible fuel leaks, and repair as necessary. - Page 17 then tighten it firmly with the spark plug wrench. If a torque wrench is available, torque the spark plug to 148-165 inch pounds. EVERY 50 HOURS More frequently if you note reduced performance INSPECTION Inspect the entire machine and tubes for damage, including loose or missing components, and repair as necessary.
-
Page 18: Storage
STORAGE(30 days or longer) □ CLEANING Thoroughly clean the machine exterior. □ INSPECTION Inspect the entire machine and tubes for damage, including loose or missing components, and repair as necessary. □ FUEL Drain the fuel tank, and the clear the carburetor and lines by running the machine until it stops from lack of fuel. - Page 23 1E34FBN汽油机明细表（Ⅰ) Appendix List Engine Parts of Attached Fig (Ⅰ) ERP编号 零部件名称 ERP编号 零部件名称 序号 数量 序号 数量 Part Name Part Name Item ERP NO. Item ERP NO. 火花塞 RCJ6Y 化油器垫 3480 1154 Spark plug RCJ6Y Gasket,carburetor 螺钉组合 M5X20 化油器总成 5711 1067 Bolt M5X20 Carburetor comp...
- Page 25 EBV260BN MACHINE PARTS LIST (Ⅱ) EBV260BN 机具明细表 (Ⅱ) 序号 ERP编码 名称 数量 序号 ERP编码 名称 数量 Ser.NO. Erp NO. Part Name Ser.NO. Erp NO. Part Name 自攻丝 4.2×10 吸尘管一 2-32 5307 6622 INHALE PIPE NO.1 ST4.2×10 吸尘管二 停车线 2-33 5308 0957 INHALE PIPE NO.2...
- Page 26 Axminster Reference No: EBV260BN Part No: 211927 Axminster Devon EX13 5PH UK FREEPHONE 0800 371822 www.axminster.co.uk...
