Summary of Contents for LandingZone DOCK LZ3013A
- Page 1 © 2012 Infiniti Wing, Inc • All R For additional languages, please visit LandingZone.net/user-guides...
- Page 2 DOCK. LOCK. CONNECT.
- Page 3 Dear MacBook Pro® with Retina display Owner, Thank you for your purchase of the LandingZone DOCK. We hope it provides you with great satisfaction. The LandingZone is quite easy to use but, should you need some help with it, this manual is designed to easily walk you through how to use it.
-
Page 4: Model Numbers
MODEL NUMBERS COMPATIBILITY LZ3013A for 13-inch MacBook Pro This device works with: with Retina display 13-inch MacBook Pro with Retina display models LZ3015A for 15-inch MacBook Pro released on October 2012 (Model A1425) with Retina display 15-inch MacBook Pro with Retina display models WHAT’S IN THE BOX? - Page 5 BENEFITS FEATURES LandingZone DOCK is an Single-step docking (sold separately) to secure attractive and simple to your MacBook Pro Built-in USB Hub with use secure docking station three USB 3.0 ports Power adapter with wide for the MacBook Pro with two USB 2.0 ports...
- Page 6 BEFORE YOU BEGIN Travel Clip: Remove the Travel Clip (1) on the Release Lever (9). When transporting your LandingZone DOCK, you can use the Travel Clip to secure the Release Lever. Ethernet functionality: Go to landingzone.net/download-driver to download and install the latest Ethernet driver for full Ethernet...
- Page 7 On/Off Status LandingZone MagSafe 2 Indicator Light Gigabit Power Power Holder Ethernet MagSafe 2 Tightening Switch HDMI USB 2.0 Release Lever USB 3.0 Headphone Mini DisplayPort Kensington® Lock Slot...
- Page 8 DOCKING...
- Page 9 STEP 1: CONNECT POWER & PERIPHERALS Make sure the Tightening Switch (5) is in the UP position and insert the MacBook Pro’s MagSafe 2 power plug into the MagSafe 2 Power Plug Holder (6). Push the Tightening Switch (5) down. Connect Ethernet &...
- Page 10 DOCK until the back of your MacBook Pro with Retina display® touches the two guide posts (A). Push both ends (B) of the LandingZone DOCK gently inward to fully engage with the MacBook Pro. Do not use the Release Lever on the LandingZone...
- Page 12 UNDOCKING...
- Page 13 STEP 1: Eject devices in the OS X Finder STEP 2: Unlock if using a lock STEP 3: Open the Release Lever (9) and lift out your MacBook Pro with Retina display If you would like to release the MagSafe 2 plug, flip the Tightening Switch up (5)
-
Page 14: Troubleshooting
TROUBLESHOOTING... - Page 15 ETHERNET IS NOT WORKING Make sure that both sides of the Double-check that you have the proper Ethernet driver LandingZone DOCK are completely closed installed. Lights will flash on an active Ethernet port. and the connectors are fully inserted into WINGS DON’T CLOSE PROPERLY...
-
Page 16: Customer Support
CUSTOMER SUPPORT... -
Page 17: Online Support
ONLINE SUPPORT Go to landingzone.net/FAQs PHONE SUPPORT Call 888-872-3251 (Monday - Friday, 8:00am - 4:00 pm Pacific Time) EMAIL SUPPORT Send email to support@landingzone.net ETHERNET DRIVER DOWNLOAD Download at landingzone.net/download-driver... -
Page 18: Care And Cleaning
PROPER OPERATING ENVIRONMENT CARE & CLEANING Line voltage: 100-240V AC Clean with a soft cloth. Do not use water or cleaning solutions to clean the Frequency: 50Hz to 60Hz LandingZone. Operating temperature: 50° to 95° F (10° to 35° C) Storage temperature: -13°... -
Page 19: Copyright & Trademark Information
COPYRIGHT & TRADEMARK INFORMATION © 2013 InfiniWing, Inc. LandingZone is a registered trademark of InfiniWing, Inc. Apple, the Apple logo, MacBook Pro, Retina, Mac OS X, MagSafe, Mini DisplayPort, are trademarks of Apple, Inc., registered in the U.S. and other countries. Kensington is a registered trademark of Kensington Computer Group, a division of ACCO Brands. - Page 20 For additional languages, visit LandingZone.net/user-guides...
