Summary of Contents for Sineoji PL500EW

Page 1: User Manual
User Manual PL500EW 500Mbps HomePlug AV 2-Port Wireless Range Extender...
Page 2 Safety This equipment is in compliance with the requirements of the following regulations: CE Mark, 89/336/EEC...
Page 3 Features HomePlug Features  Power voltage range is 100 to 240 V AC 50-60Hz.  Support the HomePlug AV protocol and the IEEE1901 protocol.  PLC physical link rate is up to 500Mbpsbps.  Support the following modulation schemes: OFDM QAM 4096/1024/256/64/16/8, QPSK, BPSK, and ROBO. ...
Page 4: Homeplug Powerline
1 HomePlug Powerline HomePlug Powerline is an excellent solution that can be used to extend your network. In the home or small office building, use HomePlug Ethernet Bridges to link multiple locations without the need to run long Ethernet cables. Combined with a broadband DSL/Cable connection, every room with electrical power outlets will have easy access to high-speed Internet con- nection.
Page 5: Casing Details
1.3 Casing Details Front Casing Status Lights The following table describes the status of LED indicators on the front panel: LED Indicator Color Status Description Green System runs normally. System is resetting. Power Green Blink System is in the process of password synchronization. Device is powered off or system is down.
Page 6: Initial Setup
The following table describes pushbuttons on the front panel: Button Description It is used to set the status of the device members. Press and hold the Security pushbutton for more than 10 seconds to exit the current Security network and generate a random password of network member. Press and hold the Security pushbutton for less than 3 seconds, and then the HomePlug becomes a member of the existing AVLN.
Page 7: Individual Homeplug Av Network Setup (Optional)
Port on your Modem or Router. 5. Make sure that the Data LED light on each HomePlug AV Ethernet Bridge turns solid green. 6. Your HomePlug AV Ethernet Bridges are now connected forming a HomePlug AV network. 2 Individual HomePlug AV Network Setup (Optional) All HomePlug AV Ethernet Bridges ship with a default security key so they will automatically link to all other HomePlug AV Ethernet Bridges sharing the same electrical lines.
Page 8: Adding Bridge C To Existing Network Ab (Network Abc)
2.2 Adding Bridge C to existing Network AB (Network ABC) One unassociated Bridge C is added to an existing Network AB. The procedure is as follows: 8. Press and hold the Security button on Bridge C for no more than 10 seconds. Must release after 10 seconds. Once re- leased, the Power light will flash.
Page 9 2.3 Removing Bridge B from Bridge A & C Network and join with Bridge D & E (Network BDE) The procedure is as follows: 1. Press and hold the Security button on Bridge B for no more than 10 seconds. Must release after 10 seconds. Once re- leased, the Power light will flash.
Page 10: Changing The Wireless Password
2.5 Changing the Wireless Password Plug the HomePlug directly on the power socket. Connect an Ethernet cable to LAN 1 of the HomePlug and the other end to the Ethernet port of the Desktop PC or Note- book. Right mouse click on the “NETWORK” icon of your Windows Desktop Select “OPEN NETWORK AND SHARING CENTRE”...
Page 11: Troubleshooting And Disclaimer
12. After changing the wireless password, ensure that you change the adapter settings to “OBTAIN AN IP ADDRESS AUTOMATICALLY”. 3 Troubleshooting and Disclaimer If your HomePlug AV Ethernet Bridges have difficulty communicating with each other, check the following:...
Page 12: Specifications
 Try power cycling the unit by unplugging it from the wall for 10 seconds and plugging it in again.  Hold the security/reset button down for more than 15 seconds to reset to default setting. The HomePlug AV Ethernet Bridge’s light will flash, the units will reset and attempt to link using default factory settings.
Page 13 Warranty Product carried a warranty of 3 years from the date of purchase. Warranty registration can be done via online at http://www.sineoji.com/support/product-registration. Ensure a copy of the proof of purchase is submitted online during the registration process. The Warranty will not apply in respect: If the Product has not been installed, operated, maintained or used in accordance with the manufacturer's instructions or specifications provided with the Product;...
Page 14 Sineoji aggregate liability in respect of all claims under the Standard Warranty shall not exceed the original purchase price of the Product or, at Sineoji’s discretion, replacement of the Product with a like or similar Product.
