Summary of Contents for TE Heater 525 Series
- Page 1 Heater 525 Series User’s Manual Dallas, TX 75235 Fax.214.631.4218 Texas Electronics, Inc. 5529 Redfield Street Tel.214.631.2490 www.texaselectronics.com...
-
Page 2: Heater Specifications
After the heating sensor is mounted in its permanent location and following the local electrical codes for the particular location, connect to 120 VAC. The sensor has two heaters, one attached to the underside of the inner collector funnel and the other attached to the inside lower portion of the sensor housing. These two heaters are connected in series with a thermostat that is positioned near the tipping assembly.
