OPERATION MANUAL
NOTE:
Six Pac's
Before installing your new
power amplifier, please read this manual carefully as it
will inform you of the specifications, proper installation procedures and operation procedures. Also
Six Pac's
included in this manual are guidelines on how to properly service and care for your new
monobloc power amplifier.
Advertisement
Table of Contents
Summary of Contents for Audio Electronic Supply Six Pac’s
-
Page 1: Operation Manual
Audio Electronic Supply Six Pac’s Vacuum Tube Monobloc Power Amplifiers OPERATION MANUAL NOTE: Six Pac’s Before installing your new power amplifier, please read this manual carefully as it will inform you of the specifications, proper installation procedures and operation procedures. Also Six Pac’s... -
Page 2: Specifications
Specifications for your new SIX PAC’S power amplifier. Operating the Six Pac’s power amplifier is a simple procedure. Each unit is designed for long term stability in virtually any home operating situation. Please note, if the unit is operated outside the parameters outlined in this owner's manual, damage may result. Please read this manual carefully before putting your new Six Pac’s in operation. - Page 3 1.3 Front Panel Features POWER ON/OFF SWITCH: AC mains switch and high voltage in “ON” position Red LED: Indicates the high voltage supply is ON and the fuse is intact. FEEDBACK SWITCH: Select between 0 or 10db of feedback. 1.4 Rear Apron Features RCA INPUT: Signal input connection via shielded interconnect cable SPEAKER OUTPUT: 5-way binding posts provide the signal output to the speaker system.
- Page 4 Mishandling should be evident upon inspection of the shipping container. If chassis damage is found after a visual inspection, take care not to destroy the evidence.
-
Page 5: Warranty Card
Heavy gauge #14 wire is suitable for distances up to 15 feet, #12 wire for up to 30 feet. Your Authorized Audio Electronic Supply Dealer will have proper speaker cable in stock for this purpose. -
Page 6: Operation
3.1 Operation Your new power amplifier is ready for operation after the speaker, interconnect cables and the vacuum tubes have been installed into their proper sockets. Refer to the tube placement sheet at the end of this manual for proper tube installation. 3.2 4 or 8 OHM Speaker Selection Select the proper speaker impedance (4 or 8 ohm) for the speaker(s) in your system. -
Page 7: Tube Replacement
All mentions of in factory service are relevant for Audio Electronic Supply products purchased and used exclusively within the USA only. Non USA distributors of Audio Electronic Supply products will establish their own local warranty or after service policies. - Page 8 RESULT IN TUBES OVERHEATING AND DAMAGE TO THE AMPLIFIER. ! PLEASE OBSERVE THE SAFETY DIRECTIONS IN THIS MANUAL TO AVOID POSSIBLE ELECTRICAL SHOCK OR EQUIPMENT FAILURE DUE TO IMPROPER INSTALLATION! Audio Electronic Supply 1020 Goodworth Drive Apex, North Carolina 27539 Tel: 919-355-0014 Fax: 919-355-0013 www.audioelectronicsupply.com...
