Energy Saving
Multimedia Surge Protectors
Convenient
on/off
usB
remote
saves
Energy
PG-503
Click for
User Guide
Protect these
and more
Our new UltraPower
conscious engineering. The PG-805 and PG-503 are the first component introductions to this new line.
The
PG-805
features three always on outlets as well as five energy saving outlets, while the
two always on outlets plus three energy saving outlets. The remote controller turns the energy saving outlets
completely on or off, reducing cost and saving energy. It also reduces noise via high frequency capacitors
and a choke and completes the package with robust AC power line surge protection that saves your valuable
components. Our advanced system exploits the absorptive powers of the latest X3
Varistors) made with improved materials and technology.
Saving energy, power filtering, surge protection and remote control of its five energy saving outlets puts
UltraPower on the leading edge of
Always On outlets
provide continuous
power for connected
components
THE ULTIMATE CONNECTION
Planet Green
product line reveals our commitment to environmentally
®
™
Planet Green
power!
Energy Saving outlets
provides complete
power disconnection
ultralink Products, inc.
Markham, Ontario, Canada L3R 3L1
Tel: (905) 479-2831 Fax: (905) 479-9347
®
Email: cdnsales@ultralinkproducts.com
MOVs (Metal Oxide
™
Bonus usB Charging Ports
2 USB charging ports provide 5V and
a total of 1.5 amps of power
ultralink/XLo Products, inc.
Ontario, California, U.S.A. 91761
Tel: (909) 947-6960 Fax: (909) 947-6970
Email: usasales@ultralinkproducts.com
www.ultralinkproducts.com
Planet Green
PG-805
and
PG-503
PG-805
Click for
User Guide
PG-503
offers
Advertisement
Summary of Contents for UltraPower Planet Green PG-805
- Page 1 ® ™ conscious engineering. The PG-805 and PG-503 are the first component introductions to this new line. PG-805 features three always on outlets as well as five energy saving outlets, while the PG-503 offers two always on outlets plus three energy saving outlets.
-
Page 2: Phone Specifications
PG-805 and PG-503 Features and Specifications Models PG-805 PG-503 FEATURES Advanced PurePower Filtration Circuitry ™ Microprocessor Controlled Auto Reset Ground OK / Protection On LED Total Number of Outlets Always On Outlets Energy Saving Outlets AC Power Cord Length 8ft. / 2.5meter... - Page 3 PG-503 User Guide...
- Page 4 Introduction Thank you for purchasing the UltraPower Planet Green PG-503 ® ™ Energy Saving Surge Protector with USB Remote On/Off Controller. The Planet Green product line marks our commitment to environmentally conscious engineering. Save Energy, Save Money Most electronic devices draw power even in standby mode, an obvious waste of resources.
- Page 5 Features Energy Saver Indicator Light A blue LED indicates the 3 Energy Saving Outlets are on USB Remote On/Off Controller 3 Energy Saving Outlets On or Off with Ground Fault Indicator Light the press of a button A red LED indicates the power outlets are not properly grounded Always On Indicator Light A green LED indicates the 2 Always On Outlets are active 3 Energy Saving Outlets...
-
Page 6: Connecting Your Equipment
Setup Connecting your equipment USB Charging Ports The PG-503 has 2 “Always On” outlets that Two USB charging ports provide 5V provide continuous power for devices that are and a total of 1.5 amps of power. designed to remain on at all times. Typical Always On device are DVR, Modems, Routers, Alarm Clocks, etc. - Page 7 Using the USB Remote Operating The USB Remote can be used in two different ways. Learning Button 1. It can be used free standing or as a wall The “LEARNING” button has two functions: mounted switcher. You can simply turn 1.
-
Page 8: Troubleshooting Guide
Trouble shooting Guide Mounting Screw Removal My equipment won’t turn on The PG-503 is shipped with a mounting 1. Check if it is plugged into the “Always On” or “Energy Saving” screw that will allow you to affix the unit Outlets. - Page 9 This warranty does not cover any UltraPower unit that has been damaged or rendered defective (a.) as a result of accident, misuse, or abuse; (b.) by the WARNING – No User Serviceable Parts Inside PG-503 use of parts not manufactured or sold by or (c.) by modification of product.
- Page 10 Determination of Failure: UltraLink Products, Inc. will evaluate the (1.) Contact UltraLink within ten (10) days after you discover a product defect UltraPower product for surge damage. The unit must show signs of surge (or should have discovered it, if such product defect was obvious) damage or must be performing outside of design specifications in respect (2.) Give a detailed explanation of how the damage occurred;...
- Page 11 Planet Green™ brands are a division of ® UltraLink Products, Inc. Markham, Ontario, Canada. ® UltraPower , the UltraPower logo, Planet Green™ and the Planet Green™ logo ® ® are registered trademarks of UltraLink Products, Inc. Specifications and features ®...
- Page 12 PG-805 User Guide...
- Page 13 Save Energy, Save Money Most electronic devices draw power even in standby mode, an obvious waste of resources. The PG-805 features a USB Remote On/Off Controller making it simple and convenient to turn off your devices automatically when they are not in use.
- Page 14 Features Energy Saver Indicator Light A blue LED indicates the 5 Energy Saving Outlets are on USB Remote On/Off Controller 5 Energy Saving Outlets On or Off with Ground Fault Indicator Light the press of a button A red LED indicates the power outlets are not properly grounded Always On Indicator Light A green LED indicates the 3 Always On Outlets are active 3 Always On Outlets...
- Page 15 Setup Connecting your equipment USB Charging Ports The PG-805 has 3 “Always On” outlets that Two USB charging ports provide 5V provide continuous power for devices that are and a total of 1.5 amps of power. designed to remain on at all times.
- Page 16 USB remote continues to light up after the equipment is 3. Press the button on the USB remote or connect the USB turned off. This means the USB port will not work with the PG-805 Remote directly to the main component’s USB port within 5 –...
- Page 17 My equipment won’t turn on 1. Locate the mounting holes on the back 1. Check if it is plugged into the “Always On” or of the PG-805 for wall or baseboard “Energy Saving” Outlets. mounting. 2. Switch the “Energy Saving Outlets” on with the 2.
- Page 18 WARNING – Avoid Electrical Shocks Notification: You must notify UltraLink within ten days of any event causing Never use your PG-805 if liquid of any kind is spilled on or into it. Do not a claim. use the PG-805 near areas where rain leaks or splashes in, or where water Product Return: You must contact UltraLink customer service and obtain a is regularly used as in bathroom or kitchen.
- Page 19 Determination of Failure: UltraLink Products, Inc. will evaluate the (1.) Contact UltraLink within ten (10) days after you discover a product defect UltraPower product for surge damage. The unit must show signs of surge (or should have discovered it, if such product defect was obvious) damage or must be performing outside of design specifications in respect (2.) Give a detailed explanation of how the damage occurred;...
- Page 20 Planet Green™ brands are a division of ® UltraLink Products, Inc. Markham, Ontario, Canada. ® UltraPower , the UltraPower logo, Planet Green™ and the Planet Green™ logo ® ® are registered trademarks of UltraLink Products, Inc. Specifications and features ®...
