ED Nord magicolor 2200 User Manual

Magicolor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
magicolor 2200
®
User's Guide
1800616-001B
EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500

Advertisement

Table of Contents
loading

Summary of Contents for ED Nord magicolor 2200

  • Page 1 2200 ® User’s Guide 1800616-001B EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 2: Proprietary Statement

    MINOLTA-QMS, Inc. Manual Notice MINOLTA-QMS, Inc. reserves the right to make changes to this manual and to the equipment described herein without notice. Considerable effort has been made to ensure that this manual is free of inaccuracies and omissions.

  • Page 3: Table Of Contents

    Contents Replacing Consumables .................7 Consumable Life Expectancies 8 Replacing Consumables 8 Replacing Toner Cartridges 9 Replacing the OPC Drum, Laser Lens Cover, and Waste Toner Pack 13 Replacing the Fuser Unit and Transfer Roller Kit 20 Replacing the Fuser Oil Roller 26 Replacing the Transfer Belt 28 Using Media....................33 Introduction 34...
  • Page 4 Maintaining the Printer ..................49 Maintaining the Printer 50 Cleaning 52 Troubleshooting ..................... 53 Introduction 54 Printing a Status Page 54 Preventing Media Jams 54 Automatic Jam Recovery 55 Understanding the Media Path 56 Clearing Media Jams 57 Solving Problems with Media Jams 69 Solving Other Problems 71 Solving Problems with Printing Quality 75 Status, Error, and Service Messages 85...
  • Page 5 Color Printing ....................133 Introduction 134 Repacking the Printer ..................137 Storing the Printer 138 Relocating Your Printer 138 Repacking the Printer 139 Technical Specifications .................. 145 Requirements 146 Engine and Controller Specifications 150 Print Media 155 Document Option Commands 156 Supported DOCs 156 Contents EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 6: Ednord - Istedgade 37A - 9000 Aalborg - Telefon

    EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 7: Replacing Consumables

    Replacing Consumables EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 8: Consumable Life Expectancies

    The stated life expectancy of each consumable is based on printing under specific operating conditions, such as media type, number of color planes, page size, and page coverage (@ normal 5% coverage of letter/A4-size media). The actual life expectancy will vary depending on these and other printing variables, including continuous or intermittent printing, ambient temperature, and humidity.

  • Page 9: Replacing Toner Cartridges

    (Administration/Consumables/Start Period menu). Ordering Consumables Choosing the right consumables for your magicolor 2200 printer not only increases its reliability and performance, but also minimizes the risk of damage. For example, only MINOLTA-QMS toner cartridges are designed to meet the exact specifications of your MINOLTA-QMS printer, giving maximum performance, efficiency, and long life.

  • Page 10: Toner Cartridge Life

    Attention If you get toner in your eyes, wash it out immediately and consult a doctor. Material Safety Data Sheets (MSDS) information can be found at www.minolta-qms.com (click on the Answer Base). Toner Cartridge Life A toner cartridge contains enough toner (yellow, magenta, cyan, or black) to print a maximum of 6,000 (@ normal 5% page coverage) letter/A4-size pages.
  • Page 11 Toner Cartridge Handling Attention Do not hold a toner cartridge vertically. Do not touch the toner roller surface or the protective shutter . This could lower image quality. Keep toner cartridges: „ In their packaging until you’re ready to install them. „...
  • Page 12 Press the toner cartridge carrousel button and release the button before turning the carrousel dial counterclockwise until it stops. The carrousel rotates 90° and stops. The toner cartridge carrousel may start to turn automatically from the weight of the inserted toner cartridge. Make sure you have fully turned to the next slot before try- ing to insert another toner cartridge.

  • Page 13: Replacing The Opc Drum, Laser Lens Cover, And Waste Toner Pack

    Distribute the toner inside the cartridge. Holding a cartridge with both hands, gently shake it five or six times. 5 " Each toner cartridge has a colored end that corresponds to a colored label inside the cartridge slots. Always install the toner cartridge in the slot with a label of the same color.
  • Page 14 When the OPC drum is worn out, the message REPLACE DRUM appears. The printer will not print until the drum kit is replaced. When you replace the OPC drum cartridge after a DRUM LOW or REPLACE DRUM message displays in the message window, the printer automatically recovers. However, the replaced waste toner pack consumables monitoring system must be reset.
  • Page 15 Carefully remove the waste toner pack using the handle. Keep the waste toner pack upright so the toner does not spill. Turn the two caps labeled “A” counterclock- wise and remove them. Twist the two “A” caps onto the two “A” holes Turn the caps clockwise to secure them.
  • Page 16 Remove waste toner pack cap labeled “B” and insert it into hole “B.” Dispose of the used waste toner pack. 5 " Dispose of it properly according to your local regulations (do not dispose of it by burning). Continue with replacing the OPC drum cartridge.
  • Page 17 Support the bottom of the drum with your hand, then carefully pull the cartridge toward you and remove it. 5 " Dispose of it properly according to your local regulations. Replacing the Laser Lens Cover Press on the laser lens cover lock release lever and gently pull the laser lens cover toward you.
  • Page 18 Installing the New OPC Drum Cartridge Remove the new OPC drum cartridge from its shipping box. Attention Keep the protective sheet on the cartridge. Do not touch the protective sheet on the photosensitive (green) surface or scratch the surface. This could lower image quality.
  • Page 19 Press on the front handle of the OPC drum car- tridge with one hand and hold the front handle of the OPC protective cover with the other hand. Peel the protective cover off (straight toward you). 5 " Dispose of it properly according to your local regulations.

  • Page 20: Replacing The Fuser Unit And Transfer Roller Kit

    Insert the bottom of the waste toner pack into its installation position in the printer. Insert the top of the waste toner pack into its installation position in the printer until it is firmly seated. Close the printer’s front cover. If the waste toner pack is not correctly installed or the transfer belt right release lever is at its top position (12 o’clock), the...
  • Page 21 Replacing the Fuser Unit Turn off the printer. Open the printer’s top cover. Rotate the two fuser oil roller lock levers to release the fuser oil roller. Remove the fuser oil roller. Hold it by the green handle only. Place the fuser oil roller on a table or level surface. Attention Since the fuser oil roller removed here is to be installed in the new fuser unit, handle it with care.
  • Page 22 Turn the release levers (front, rear) to release the fuser unit. Holding the fuser unit handles, lift up the unit. 5 " Dispose of it properly according to your local regulations. Remove the new fuser from its shipping box. Replacing the Fuser Unit and Transfer Roller Kit EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 23 Carefully lower the new fuser unit so that the two pins in the fuser unit installation section go into the two installation holes in the fuser unit. Press in on the fuser unit release levers rotate them downward This secures the fuser unit. Attention If the fuser unit release levers are not set correctly, the fuser oil roller cannot be installed.
  • Page 24 Reinstall the fuser oil roller (removed in step 4). Rotate the two oil roller levers to lock the oil roller into place. Close the printer’s top cover. Check the release button to make sure the top cover is properly closed. Replacing the Transfer Roller Unit 5 "...
  • Page 25 Holding the two transfer roller unit handles, remove the transfer roller unit. 5 " Dispose of it properly according to your local regulations. Remove the new transfer roller unit from the fuser kit box. Attention Do not touch the surface of the transfer roller unit.

  • Page 26: Replacing The Fuser Oil Roller

    Lower the two transfer roller unit handles. Carefully close the right cover. Check the release button status to make sure the cover is properly closed. If necessary, reopen the multipurpose tray and put the media back in. Replacing the Fuser Oil Roller The fuser oil roller provides a lubricant for the printer via an oil-impregnated roller.
  • Page 27 Turn off the printer. Open the printer’s top cover. Rotate the two fuser oil roller lock levers to release the fuser oil roller. 5 " Dispose of it properly according to your local regulations. Remove the new fuser oil roller from its shipping box.

  • Page 28: Replacing The Transfer Belt

    Rotate the two oil roller levers to lock the oil roller into place. Attention If the two fuser oil roller release levers are not correctly set, the top cover cannot be closed. Set the release levers to the roller fixed position. Carefully close the top cover.
  • Page 29 Remove the OPC drum cartridge and set it aside. Attention The OPC drum is extremely sensitive to bright light and direct sunlight. Always put it in its protective bag until you’re ready to reinstall it. Any exposure to light should be avoided, or permanent damage could result. Also, handle the cartridge carefully by its sides so you don’t touch the surface (the green part) of the drum.
  • Page 30 Grasp the handles of the transfer belt and remove it. 5 " Dispose of it properly according to your local regulations. Remove the new transfer belt from its packag- ing and insert it into the printer. Press on the transfer belt front handle with one hand, take the handle of the transfer belt fixture with your other hand, and pull the fix- ture straight toward you.
  • Page 31 Rotate the transfer belt lock lever. Reinstall the OPC drum cartridge. Replacing the Transfer Belt EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 32 Close the transfer belt lock lever. Check to make sure the laser lens cover is firmly seated. Reinstall the waste toner pack. Close the front cover and turn on the printer. Replacing the Transfer Belt EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 33: Using Media

    Using Media EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 34: Introduction

    Maintenance Guide for media specifications. Media Handling Before purchasing a large quantity or special media, do a trial printing with the same media and check print quality. Check with our web site www.minolta-qms.com for a list of current approved media. Attention Do not use the media types listed below.

  • Page 35: Media Types

    „ Metal clasps, fasteners, transparent windows, peel-off strips for sealing „ Material that will melt, vaporize, offset discolor, or emit dangerous fumes Do not use labels that have „ Label(s) already peeled off „ Labels that peel off easily „ Glue or sealer that might come off „...

  • Page 36: Letterhead And Memo Media

    Letterhead and Memo Media Formatting Format letterhead or memo data within your application. Try printing your data on a plain sheet of paper first to check placement. Input Upper and Up to 500 sheets Optional Trays Multipurpose Up to 150 sheets Tray Orientation Upper and...
  • Page 37 Type For information about thick stock media recommended for your printer, go to www.minolta-qms.com/support, then click on Answer Base, or contact Technical Support. See the Service & Support Guide for a complete listing of support telephone numbers. Weight Simplex: 24–43 lb bond (90–163 g/m²) Autoduplex: Up to 28 lb bond (105 g/m²)
  • Page 38 Labels Formatting Format label data within your application. Try printing your data on a plain sheet of paper first to check placement. Input Multipurpose Up to 50 sheets, depending on the thickness of the labels Tray Only Orientation Face down Type Use only labels recommended for laser printers, such as „...
  • Page 39 Tray Type Use any full-color transparencies (also known as OHP film) that meet normal photocopier standards. We recommend „ Q-Media Transparency Media for the magicolor 2200 for color printing „ 3M PP2500 for monochrome printing Duplexing Not supported Media Types...

  • Page 40: Loading Media

    „ When refilling media, first remove any media remaining in the tray. Stack it with the new media, even the edges, then reload it. Although the magicolor 2200 was designed Loading Media EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 41: Upper And Optional Media Trays

    for printing on a wide range of media types, it is not intended to print exclusively on a single media type except plain paper. Continuous printing on media other than plain paper (such as envelopes, labels, thick stock, or transparencies) may adversely affect print quality or reduce engine life.
  • Page 42 Push the media pressure plate down to lock it in position. Adjust the media guides to fit the size paper you’re loading. Squeeze the retainers, move the guides to the appropriate location (media sizes are listed on the tray), and release the retainers. The media should fit easily between the guides.
  • Page 43 Load the paper face-up, short edge toward the right of the tray. Often, an arrow on the media package label indicates the printing-side of the media. Do not overfill the tray. A fill limit mark is provided on the inside of the tray.

  • Page 44: Multipurpose Tray

    Slide the tray back into the printer. 5 " If you have removed the tray from the printer, slightly tilt up the tray to insert it into the installation rails to slide it back in. Multipurpose Tray Page sizes other than letter, A4, and legal can be printed only from the multipurpose tray (also known as tray 1).
  • Page 45 Open the media support. Attention Load only one type/size of media per tray at a time. Load the media face down, short edge toward the printer. Often, an arrow on the paper package label indicates the face-up (printing) side of the paper.
  • Page 46 Adjust the media guides to fit the size media you’re loading. Attention Always adjust the media guides after inserting the media. A guide that is not properly adjusted can cause poor print quality, media jams, or printer damage. Specify the media size in the multipurpose tray by using the MP Size key on the control panel.

  • Page 47: Media Storage

    Adjust the media guides to the width of the envelopes. Make sure the guides are snug enough to keep the envelopes straight, but not so tight that they buckle the envelopes. Open the flap of each envelope immediately (before it cools) after the envelope is delivered to the output tray.
  • Page 48 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 49: Maintaining The Printer

    Maintaining the Printer EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 50 Maintaining the Printer Handle the printer with care to preserve its life. Abuse may cause damage and void your warranty. If dust and paper scraps remain on the inside or outside of the printer, printer performance and print quality will suffer, so the printer should be cleaned periodically.
  • Page 51 If you get toner on your skin, wash it off with cool water and neutral detergent. WARNING! If you get toner in your eyes, wash it out immediately with cool water and consult a doctor. Material Safety Data Sheets (MSDS) information can be found at www.minolta-qms.com (click on the Answer Base). „...

  • Page 52: Cleaning

    Cleaning You should perform a thorough cleaning every 30,000 single-sided pages or 12 months, whichever comes earlier. Always test any cleaning solution (such as a mild detergent) on a small area of your printer to check the solution’s performance. Avoid A soft dry cloth to clean the Sharp or rough implements (such as wire or plastic control panel...

  • Page 53: Troubleshooting

    Troubleshooting EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 54: Introduction

    Introduction This chapter provides information to aid you in resolving printer problems you may encounter, or at least guide you to the proper sources for help. Printing a Status Page Print a status page to verify the printer is printing correctly. Press Key (Until) Display Reads Online...

  • Page 55: Automatic Jam Recovery

    The printer is on a hard, flat, level surface Automatic Jam Recovery The magicolor 2200 provides automatic jam recovery (when enabled through the Administration/Engine/Page Recovery menu). After you remove any jammed media, printing automatically resumes from the page the printer stopped at when the jam occurred.

  • Page 56: Understanding The Media Path

    Understanding the Media Path Understanding the printer’s media path will help you locate media jams. c c c c Media exit unit d d d d Output tray e e e e Fuser f f f f Transfer belt g g g g OPC drum cartridge h h h h Duplex unit (standard on DP model) i i i i Multipurpose tray j j j j Upper media tray...

  • Page 57: Clearing Media Jams

    Media Tray (Upper Tray Standard on All Models and Optional Tray Standard on DP Model) The media tray(s) is (are) located at the bottom front of the printer. The media is picked from the tray, passed under the OPC drum cartridge and the transfer belt, passed through the fuser, and delivered via the paper exit unit to the output tray on top of the printer.
  • Page 58 WARNING! If you get toner in your eyes, wash it out immediately with cool water and consult a doctor. Material Safety Data Sheets (MSDS) information can be found at www.minolta-qms.com (click on the Answer Base). If, after clearing the media jam, the jam message in the control panel window persists, open and close the printer’s covers.
  • Page 59 Clearing Misfeed (Upper or Optional Tray) Jams Remove the media tray(s). Carefully remove the jammed media. Shuffle the media currently in the tray and even up the front edges. Reinsert the media printing face up. Make sure the media is lying flat, is under the media sepa- rating tabs, and doesn’t exceed the media limit mark.
  • Page 60 Clearing Misfeed (Multipurpose Tray) Jams Remove the media from in the multipurpose tray. Carefully remove the jammed media. Shuffle the media that was removed in step 1 and even up the front edges. Reinsert the media printing face down. Make sure the media is lying flat and doesn’t exceed the media limit mark.
  • Page 61 Media Jams near the OPC Drum If there is any media in the multipurpose tray, remove it and close the multipurpose tray. Press the right-side cover release button and carefully open the cover all the way. Remove the jammed media by pulling it slowly from the bottom of the fuser.
  • Page 62 Close the right-side cover. The media jam display is cancelled. Check the release button to make sure the cover is securely closed. If media was removed in step 1, open the multipurpose tray. Shuffle the media that was removed in step 1 and even up the front edges.
  • Page 63 Carefully remove the jammed media in the top cover media reverse area. Open the media jam removal cover with your left hand and carefully remove the jammed media in the duplex media feed area with your right hand. Close the media jam removal cover with your left hand and close the top cover.
  • Page 64 Pressing the duplex unit cover release, carefully open the cover. Remove the jammed media. Close the duplex unit’s cover. Close the multipurpose tray. If there still is a jam message, press the right-side cover release button and carefully open the cover all the way. Lift the inner paper guide.
  • Page 65 Remove the jammed media by pulling it toward you. If the media came out easily, skip ahead to step 15. If the media did not come out easily or if you cannot reach the media from this area, keep the duplex unit’s lower cover open. Open the duplex unit cover.
  • Page 66 Carefully remove the jammed media. Open the media jam removal cover and carefully remove the media that is jammed there. Close the media jam removal cover. Close the top cover. Check the release button to make sure the top cover is securely closed. Open the right-side cover.
  • Page 67 Close the right-side cover. Check the release button to make sure the duplex unit cover is securely closed. The media jam display is cancelled. Media Jams in the Optional 5-bin Mailbox Carefully remove the jammed media from the paper eject area of the mailbox. Open the mailbox door.

  • Page 68: Clearing Other Jams

    Lift up the paper jam removal guide in the mailbox with your left hand, and use your right hand to care- fully remove the jammed paper. Close the mailbox door. The media jam display is cancelled. Clearing Other Jams Remove jammed media from the output tray by gently pulling it to the left away from the media exit area.

  • Page 69: Solving Problems With Media Jams

    Solving Problems with Media Jams 5 " Frequent jams in any area indicate that area should be checked, repaired, or cleaned. Repeated jams may also happen if you’re using the wrong weight print media. Symptom Cause Solution Several The front edges of the media Remove the media and even up the front edges, then sheets go are not even.
  • Page 70 Symptom Cause Solution Media is The media is not correctly Remove the jammed media aand reposition the media jamming. positioned in the tray. properly in the tray. The number of sheets in the Remove the excess media and reload the correct num- tray exceeds the maximum ber of sheets in the tray.

  • Page 71: Solving Other Problems

    Solving Other Problems Symptom Cause Solution Data was An error message is Handle according to the message displayed. sent to the displayed in the message printer, but it window. doesn’t print. The transfer belt installa- Remove the transfer belt. Place the front end of the tion guide is not set cor- intermediate transfer unit installation guide (2 locations) rectly in the installation rail.
  • Page 72 After 100 1-sided pages of a continuous print run, the pauses. Auto-Image Density Con- magicolor 2200 automatically pauses to do an AIDC trol (AIDC) cycle. cycle. This process is provided to make sure reliable printer operation with optimum output quality.
  • Page 73 Symptom Cause Solution Not all pages The printer could have the Check your cable. print. wrong kind of cable, or your printer may not be configured for the correct cable and port. The Cancel key was Make sure no one pressed the Cancel key while your pressed.
  • Page 74 Symptom Cause Solution Printer power The power cord is not Turn the power switch off (O position), then remove the is not on. correctly plugged into the power cord from the outlet and plug it back in. outlet. The mailbox power cord is Turn the power switch and the mailbox power switch off not correctly connected.

  • Page 75: Solving Problems With Printing Quality

    Solving Problems with Printing Quality Symptom Cause Solution Nothing is The toner cartridge is Remove the toner cartridge and check for damage. If nec- printed. damaged. essary, replace it. The driver is not set cor- Select the proper setting in the driver to switch from trans- rectly.
  • Page 76 Symptom Cause Solution The print Media may be moist. Remove the moist media and replace it with new, dry contains media. whited out Humidity may be too high. Adjust the humidity in the paper storage area. areas. The fuser unit may be defec- Check the fuser unit for damage.
  • Page 77 Symptom Cause Solution Irregular The media is moist from Remove the moist media and replace it with new, dry print or mot- humidity. media. tled image appears. There is The media is moist from Remove the moist media and replace it with new, dry insufficient humidity.
  • Page 78 Symptom Cause Solution Image is One or more toner cartridges Check the toner cartridges. If necessary, replace them. blurred; may be defective. background The OPC drum may be mis- Reinstall the OPC drum cartridge. If necessary, replace the is lightly installed or defective.
  • Page 79 Symptom Cause Solution Part of image The media is moist from Remove the moist media and replace it with new, dry is missing. humidity. media. Media with specifications not Use media that is covered by the printer warranty. covered by the printer war- ranty is being used.
  • Page 80 Symptom Cause Solution There are The fuser oil roller is dirty or Remove the fuser oil roller and check the roller surface. If it dark spots on worn. is very dirty, replace it. the image. The transfer belt is defective. Remove the transfer belt and check for damage. If neces- sary, replace it.
  • Page 81 Symptom Cause Solution Abnormal Width of abnormal area: Remove the toner cartridge with the color causing the areas (white 1.25" (31.75 mm) abnormal image. Replace it with a new toner cartridge. or black) appear in a The toner cartridge is regular damaged.
  • Page 82 Symptom Cause Solution Abnormal The toner cartridge may be Remove the toner cartridge and check for damage. If nec- areas (white defective. essary, replace it. or black belt The OPC drum cartridge Remove the OPC drum cartridge and check the photosen- or spots) may be defective or sitive surface (the green surface) for scratches.
  • Page 83 Symptom Cause Solution Lateral lines Lateral lines have 1–2 mm Replace the laser lens cover. appear cycli- spacing. cally (evenly Lateral lines have 35 mm Replace the color toner cartridge. spaced) on spacing. image. Lateral lines have 75 mm Replace the image transfer roller. spacing.
  • Page 84 Symptom Cause Solution Colors are The front cover may not be Make sure that the printer’s front cover is closed. not register- properly closed. ing properly; The OPC drum cartridge is Remove the OPC drum cartridge and reinstall it. colors are not correctly seated.

  • Page 85: Status, Error, And Service Messages

    Symptom Cause Solution The color has The paper image transfer is Check the OPC drum cartridge. If necessary, replace the a poor repro- defective. entire drum kit. duction or The Auto-Image Density Open the front cover. Lift up the transfer belt release lever has poor Control (AIDC) detection to the 12 o’clock position.

  • Page 86: Status And Error Messages

    Status and Error Messages 5 " Status messages are not displayed while the printer is off line. This message... means... Do this... The printer is on line and No action needed. < X > ACTIVE JOBS actively processing jobs. (< X > identifies the number of jobs in process.) The <...
  • Page 87 CALIBRATING PRINT QUALITY After 100 1-sided pages of a Wait. No action needed. continuous print run, the magi- color 2200 automatically pauses to do an Auto-Image Density Control (AIDC) cycle. This pro- cess is provided to make sure reliable printer operation with optimum output quality.
  • Page 88 This message... means... Do this... The Cancel key has been Press Select for all jobs CANCEL ALL JOBS pressed, and one or more of the with a printing, interpret- print jobs in the print queue are ing, spooled, or termi- being canceled.
  • Page 89 This message... means... Do this... The printer is in energy saver No action needed. ENERGY SAVER mode to reduce power con- sumption during periods of inac- tivity. When a print job is received, the printer returns to normal power within 90 sec- onds.
  • Page 90 This message... means... Do this... The front, top, or duplex covers Close the specified MAIN UNIT COVER OPEN are open and must be closed. cover(s). Media has jammed in the duplex Locate and remove the MEDIA JAM DUPLEX area or duplex refeed area on jam.
  • Page 91 This message... means... Do this... Tray jams occur between the Locate and remove the MEDIA JAM OPTIONAL TRAY standard upper or optional tray jam. and the print engine. A misfeed jam may be as simple as a sheet of media not being picked, or it may be that the media was picked but not fed properly.
  • Page 92 This message... means... Do this... The media detected in the tray Change the media in the PAPER MISMATCH doesn’t match the media size tray or change the setting. media size setting . A status page is printing Wait until after the status PRINTING STATUS page prints, and the message clears.
  • Page 93 This message... means... Do this... The compiler is waiting on Wait until the job is fin- WAITING ON INPUT incoming data for the first job in ished and the printer END JOB? the queue. The job may not goes idle to access the have an end-of-job indicator and configuration menu.

  • Page 94: Service Messages

    SERVICE CALL 04 MAIN UNIT item indicated in the service mes- SERVICE CALL 05 FLASH ROM sage. Correction of these errors is performed by a MINOLTA-QMS- SERVICE CALL 08 MAIN MOTOR authorized service provider only. Con- tact your local vendor.
  • Page 95 SERVICE CALL 1F FUS LOW THERM item indicated in the service mes- SERVICE CALL 20 FUS RETRACT sage. Correction of these errors is performed by a MINOLTA-QMS- SERVICE CALL 21 TRANS DET SENS authorized service provider only. Con- tact your local vendor.
  • Page 96 HP-GL Error Codes and PCL Error Codes The following tables list error codes that could appear on the printer message window when running the HP-GL, PCL or HPXL emulation. HP-GL Error Description Error Description Code Code Not enough memory for job. Not enough memory for job.

  • Page 97: Additional Assistance

    Additional Assistance If you’ve followed all of the instructions in this guide and still have problems you can’t solve, refer to the Service & Support Guide or visit our web site at www.minolta-qms.com for current information on getting help. Additional Assistance...
  • Page 98 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 99: Installing Other Accessories

    Installing Other Accessories EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 100: Installing Other Accessories

    Introduction The optional lower feeder unit and duplex unit were discussed in the Installation Guide. This chapter provides information about the following accessories. Contact your local vendor for purchase information. 5-bin Mailbox Three models: For 100-, 120-, or 220-volt printers BuzzBox Via parallel connection for 100, 120, and 220 volts Dual In-Line...
  • Page 101 Installing an Optional 5-bin Mailbox Read this section if you purchased a 5-bin mailbox for your magicolor 2200. Kit Contents „ Mailbox unit „ 5 bins „ 2 thumbscrews „ Accessory screen cover „ Power cord Installation Remove the mailbox unit from its shipping box.
  • Page 102 Open the mailbox unit cover and remove any pack- ing material from the rear of the mailbox unit. Close the mailbox unit cover. Remove any packing material from the front of the mailbox unit. Remove the two screen covers from the top of the printer.
  • Page 103 Slowly lower the mailbox unit so that the two pins at the bottom fit into the two holes in the printer and the pin on the printer fits into the hole at the bottom of the mailbox. 5 " The mailbox bins will face the left side of the printer. Push the mailbox toward the right-hand side of the printer until it stops.
  • Page 104 Secure the mailbox tightly with the two thumbscrews supplied in the kit. Place the slot on the right side of the accessory screen cover from the kit onto the tab on the mailbox then press on the left side of the accessory screen cover so the tab on that side fits into the slot on the mailbox.
  • Page 105 Plug the mailbox power cord from the kit into the mail- box unit (lower connection). Plug the other end of the power cord into the printer. Make sure the printer is turned off. Make sure the 5-bin mailbox is turned off. Attention Always turn off the printer before turning off the mailbox.

  • Page 106: Buzzbox

    Plug the printer power cord into the mailbox unit (upper con- nection) and into the dedicated, grounded, surge-protected electrical outlet. Turn the mailbox unit on. Turn the printer on. BuzzBox BuzzBox is a printer accessory that warns you with a buzzer and/or a blinking light any time the printer goes off line.

  • Page 107: Installing Buzzbox

    Installing BuzzBox If you have a cable attached to the printer’s parallel port, unplug it from the printer. Attach one end of the parallel cable on the interface box to the printer’s parallel port. 5 " The BuzzBox’s ribbon cable is designed to be directly attached to the printer’s parallel port, not to an adapter or an additional cable.

  • Page 108: Using Buzzbox

    Choose a good location on the printer to mount the interface box. Make sure that the unit does not interfere with paper exiting the printer. cover any vents, doors, connectors, or labels. cause the BuzzBox ribbon cable to stretch or twist. Use the adhesive-backed clips provided to mount the BuzzBox where the printer operator can see and/or hear it.

  • Page 109: Antistatic Protection

    Also avoid walking around after grounding yourself. Dual In-Line Memory Modules Dual in-line memory modules (or DIMMs) are compact circuit boards with surface-mount memory chips. Your magicolor 2200 printer comes with the following printer memory: „ Model N—64 MB SDRAM „...

  • Page 110: How Much Memory Do You Need

    64 MB of RAM instead of the required 128 MB minimum, the file prints at 600x600 dpi. The magicolor 2200 will print all print jobs at the highest resolution that the installed memory will support.
  • Page 111 To print complex graphics or complex PostScript documents „ For increased collation performance „ For increased spooling performance The magicolor 2200 has 3 DIMM slots available. The maximum memory that can be installed is 384 MB (3 x 128 MB DIMMs). Model Standard Memory Supports up to...
  • Page 112 Installation Attention It’s very important to protect the printer controller board and any associated circuit boards from electrostatic damage. Before performing this procedure, review the antistatic caution on page 112. In addition, always handle circuit boards by the edges only. If you are not to the point when you are able to print an advanced status page yet, skip to step 2.
  • Page 113 If you need to remove a DIMM before installing one, remove it as follows; otherwise skip to step 6. 5 " If all the DIMM connectors are filled and you want to install more memory, you have to exchange one or more DIMMs for DIMMs with a greater memory capacity.

  • Page 114: Emulations, Fonts, And Other Software

    MINOLTA-QMS recommends that you have at least 4 MB of memory above the base configuration and that you add at least 1 MB memory to each emulation installed. This ensures that the printer can run the emulation without slowing down performance.
  • Page 115 Downloading an Emulation via an Ethernet Interface 5 " Before you begin this procedure, your printer and PC (or UNIX workstation) must be connected to an Ethernet network running TCP/IP and have valid IP addresses. Turn on the printer, and wait for IDLE to display in the message window. If your PC is running Windows, change to DOS.
  • Page 116 CCITT Emulation A CCITT emulation (Group 4, monochrome only) is available through the MINOLTA-QMS ImageServer option, which image-enables your printer, allowing it to print many images at or near the rated engine speed and eliminating the need for a computer dedicated to rasterizing images. For complete information, refer to the documentation that comes with the ImageServer option.
  • Page 117 Downloading Disk Fonts via CrownAdmin We recommend that you use CrownAdmin to download PostScript fonts. Refer to the CrownAdmin online help for instructions. Downloading Disk Fonts via a Parallel Interface Turn on the printer, and wait for IDLE to display in the message window. Insert the font disk or CD-ROM in your PC, and change to that drive (for example, if you’re using the A drive, type a: ).

  • Page 118: Kanji Font Internal Ide Hard Disk

    These fonts can be printed at a variety of point sizes and in different styles and resolutions. After the Kanji hard disk is installed in your magicolor 2200, the Kanji fonts are available for use just as if they were resident in the printer.
  • Page 119 FutoMinA101-Bold Jun101-Light MidashiGo-MB31 MidashiMin-MA 31 „ IDE hard disk with ribbon cable attached „ IDE hard disk bracket „ 4 screws Hardware Requirements „ A Macintosh, IBM PC, or compatible computer Software Requirements „ An application (such as a word processing or desktop publishing package) that sup- ports the PostScript printing.

  • Page 120: Qform

    QFORM QFORM allows you to use existing lineprinter and forms-printing applications on your magicolor 2200. This printer-resident application gives you the ability to store PostScript forms on the printer’s hard disk and fill those forms with your application’s ASCII print stream.

  • Page 121: Interfaces And Daughterboards

    „ Single- and multipart forms „ Labels „ Logos and watermarks 5 " QFORM doesn’t support color features. Refer to the documentation that comes in the QFORM kit for installation and usage instructions. PlanetPress PlanetPress is an electronic forms package that allows the creation and modification of business forms, MICR checks, bar codes, and other preprinted forms.
  • Page 122 What’s in the Kit? An optional interface kit includes the following: „ An interface card „ Interface documentation (in hardcopy and/or on CD-ROM) The kit may also include additional parts not required for network interface installation on this printer. Installation Attention It’s very important to protect the printer controller board and any associated circuit boards from electrostatic damage.
  • Page 123 Attach the interface card to the controller board. Position the interface card so that its I/O con- nector slides into its opening in the interface panel and that its 80-pin connector aligns with the 80-pin connector on the controller board. Gently press the inter- face card down until its connector is fully seated and the card is secured...

  • Page 124: Scsi Interface

    Using a Network Interface Once a network interface is installed, refer to “Connecting the Printer to the Host Computer,” in the Installation Guide and the CrownBook for information on connecting to the network, installing the software, and configuring the interface and the network. SCSI Interface The optional SCSI interface allows you to connect up to three optional SCSI devices, including a hard disk, and Jaz and Zip drives.
  • Page 125 Turn off the printer, and then disconnect the power cord and all interface cables from the printer. Loosen five screws and, using the tab on the lower side of the panel, pull the controller board from the printer. Remove the two screws holding the metal plate over the SCSI interface opening.

  • Page 126: Internal Ide Hard Disk Drive

    Using a SCSI Interface 5 " Installing a SCSI interface allows the attachment of external SCSI storage devices, such as hard drives, JAZ, and ZIP drives. Installing the SCSI interface kit will not allow you to print via SCSI. Internal IDE Hard Disk Drive WARNING! Make sure that the printer and all accessories are turned off before installing accessories involving the controller board.
  • Page 127 Ensure that the printer is turned off and the power cord and all interface cables are disconnected. Loosen five screws from the controller board and, using the tab on the lower side of the panel, pull the controller board from the printer. Position the controller board on a flat surface so the controller board lies flat and the interface panel is facing you.

  • Page 128: Media Trays

    Attention Make sure that the ribbon cable connector and the controller board connector pins are properly aligned. Damage to the controller board could result if the pins are misaligned. Press down gently but firmly on the cable connector until it is fully seated. Attention Do not push or pull with the ribbon cable.

  • Page 129: Printer Stand/Cabinet

    SC-210 Convenience Copier You can expand your magicolor 2200’s functionality by connecting an SC-210 digital color convenience copier option to the standard parallel port on the printer (interface set to “non-interactive”). The SC-210 supports up to legal-size paper. An optional 25-sheet Automatic Document Feeder (ADF) is available.
  • Page 130 AVERTISSEMENT! Dû au fait que l’horloge interne de l’imprimante est munie d’une batterie interne, il y a un risque d’explosion si celle-ci est mal installée ou remplacée. La remplacer seulement avec une horloge supportée par MINOLTA-QMS. Se départir de toute horloge interne défectueuse en respectant les lois et réglementations en vigueur.
  • Page 131 Attach the time-of-day clock to the controller board. Attention Make sure that the pins on the time-of-day clock are properly aligned with those in the receiving socket on the controller board. Damage to the time-of-day clock and/or controller board could result if the pins are misaligned. Locate the time-of-day clock socket on the controller board and the pin 1 notch or printed label.
  • Page 132 Reconnect the power cord and turn on the printer. 5 " In compliance with UL guidelines, “The appliance inlet is considered to be the main disconnect device.” Print a startup page. The time-of-day clock is not listed under “Installed Options” on the startup page, but the time will appear as System Date in the Printer Information column.

  • Page 133: Color Printing

    Color Printing EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 134: Introduction

    600x600, and 1200x1200 dpi on plain paper, envelopes, labels, thick stock, and transparencies. Color Management and Control The magicolor 2200 offers a host of color screening, matching, and calibration tools for both the beginner and professional color user. MINOLTA-QMS Q...
  • Page 135 (matches) COLOR graphics, text, and images on a singe page using printer-resident CRDs. Further Information For further information about the MINOLTA-QMS color management, refer to the CrownBook. Introduction EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 136 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 137: Repacking The Printer

    Repacking the Printer EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 138: Storing The Printer

    Unpack and set up the printer in its new location. Reinstall the accessories you removed in step 2. Refer to the Service & Support Guide or www.minolta-qms.com for additional information on where to obtain assistance if necessary. Storing the Printer...

  • Page 139: Repacking The Printer

    Spares at 1 (334) 633-4300 x2530 and request part number 2600674-901 for the repacking kit. For locations outside the United States, refer to the Service & Support Guide or www.minolta-qms.com. If you need to return the printer for service, be sure to write the RMA (Return Merchandise Authorization) number you received from your customer support representative clearly on the carton before shipping the printer.
  • Page 140 Remove the duplex unit (if attached). Remove the 5-bin mailbox (if attached). Remove the lower input feeder (if attached). Repack the printer for shipment. Attention To avoid toner contamination during shipment, the printer should be repacked without the fuser oil roller, toner cartridges, waste toner pack, OPC drum cartridge, or transfer belt installed.
  • Page 141 Remove the Waste Toner Pack With the printer’s front cover open, remove the waste toner pack from the printer. Use the three plugs on the side of the waste toner pack to seal the opening. Store the waste toner pack in its original packaging. Remove OPC Drum Cartridge Remove the OPC drum cartridge and store it in its original packaging.

  • Page 142: Remove The Lower Feeder Unit

    Lift 5-bin mailbox up and away from the printer. Replace the original screen covers on the top of the printer. Repack the 5-bin mailbox in its original shipping carton for storage or shipment. 5 " If you’re returning the printer for service, you don’t need to return the 5-bin mailbox, unless the problem is with the 5-bin mailbox.

  • Page 143: Repack The Printer

    If you need replacement packaging, in the United States, call MINOLTA-QMS Spares at 1 (334) 633-4300 x 2530 and request part number 2600674-901 for the repacking kit. Refer to the Service & Support Guide or www.minolta-qms.com for locations outside the United States.
  • Page 144 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 145: Technical Specifications

    Technical Specifications EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 146: Requirements

    Requirements Space Requirements The illustration below shows the amount of space required for operating the printer, replacing supplies, and removing media jams. Top View 4" (100 mm) 16" (400 mm ) Height 37" (950 mm) 4" (100 mm) 38" (950 mm) 18"...

  • Page 147: Power Requirements

    Power Requirements Power Japan 100 VAC 50–60 Hz 12 amps North America 120 VAC 50–60 Hz 8 amps Europe 220–240 VAC 50–60 Hz 6 amps Latin America 120 VAC 50–60 Hz 8 amps 220–240 VAC 50–60 Hz 6 amps Voltage Fluctuation Rate Japan 100 VAC ±10% North America...
  • Page 148 water pipes, refrigerators, and any strong electromagnetic field (such as that created by an air conditioner), open flames, or items that can easily burn, or items that produce excessive vibration. If the printer is located in a cold room that is rapidly heated, or if the printer is moved from a cold place to a warm, humid place, condensation may occur within the printer, degrading print quality.
  • Page 149 Date and time information that appears on the header and/or trailer page is passed to the MINOLTA-QMS printer by the host computer. Since this information is passed in real time, it is virtually impossible for there to be any confusion regarding the century date.

  • Page 150: Engine And Controller Specifications

    Engine and Controller Specifications Engine Engine Minolta NC-L4001 Duty cycle Simplex letter/A4 pages 8,000 average prints and up to 35,000 per month maximum prints per month* 5 " *The duty cycle will be affected by the media type, percent coverage, and the number of monochrome versus color pages.
  • Page 151 General Printer type Desktop, non-impact, 4-color printer Print method Scanner: Semiconductor laser with rotating mirror Recorder: Black writing electrophotographic Process: Cyan, magenta, yellow, and black dry toner image transfer to print media Fuser: Heated rollers Resolution Standard: 600x600 dpi (1200x1200 dpi standard on GN, EN, and DP models) Optional: 1200x1200 dpi (additional SDRAM may be required).
  • Page 152 PostScript fonts TrueType —Support for Type 42 (PostScript format) host-resident downloadable TrueType fonts, support for TrueType fonts in PCL Kanji fonts Hard disk —MINOLTA-QMS Kanji Internal IDE Hard Disk with 7 Morisawa fonts Standard CrownNet for Ethernet —10BaseT/100BaseTX interfaces Parallel —Centronics/IEEE 1284 bidirectional...
  • Page 153 Time-of-day clock N and GN models: Optional (socket provided for) EN and DP models: Standard Job accounting Crown job accounting; requires an optional IDE drive Warning function Optional, BuzzBox (light/buzzer printer warning device); operates convenience over a parallel connection Convenience Optional, SC-210 operates over a parallel connection copier Electrical...
  • Page 154 Environmental Noise level Printing: Less than 55 dB (A) Standby: Less than 41 dB (A) Relative Operating: 15-85% RH (noncondensing) humidity Transportation/Storage: 30–85% RH (noncondensing) Temperature Operating: 50-95° F (10-35° C) range Transportation/Storage: 32-95° F (0-35° C) Altitude Operating: 0-8202 ft (0-2500 m) Inclination Operating: 1°...

  • Page 155: Print Media

    Physical Main Body Main Body with Lower Main Body with Duplex Input Feeder Unit and Lower Input Feeder Dimensions W: 18.2 in. (463 mm) W: 18.2 in. (463 mm) W: 18.2 in. (463 mm) H: 20.6 in. (511 mm) H: 22.0 in. (560 mm) H: 22.0 in.

  • Page 156: Document Option Commands

    The maximum media weight supported for duplex printing is 28 lb bond (105 g/m Document Option Commands This lists the supported Document Option Commands (DOCs) for your magicolor 2200. The commands are grouped by feature type. Each command is preceded by either a DOC statement (%%) or an IncludeFeature statement (%%IncludeFeature).
  • Page 157 HP-GL Emulation Commands Select enhanced resolution %%IncludeFeature: enhanced Expand plot %%IncludeFeature: expand Select original paper size %%IncludeFeature: size Select pen width and color %%IncludeFeature: pen Select plotter %%IncludeFeature: plotter Scale the image %%IncludeFeature: scaling Set origin %%IncludeFeature: origin HP PCL 5e Emulation Commands Install object %%IncludeFeature: install Remove object...
  • Page 158 Set formfeed to CR+FF %%IncludeFeature: ffiscrff Wrap lines %%IncludeFeature: autowrap Set number of lines per page %%IncludeFeature: linesperpage Set margins %%IncludeFeature: lpmargins Set orientation %%IncludeFeature: lporientation PostScript Emulation Command SC 200 to set PostScript protocol %%IncludeFeature: parpsprotocol x CCITT Groups 3 and 4 Commands Start decompression %%ImageData Set encoded byte flag...
  • Page 159 Print page range %%IncludeFeature: pagerange Duplex printing %%IncludeFeature: duplex Collate print job %%IncludeFeature: collate Logical page size %%IncludeFeature: pagesize Select number of copies %%IncludeFeature: numcopies Select paper %%IncludeFeature: input Select orientation %%IncludeFeature: orientation Select emulation %%IncludeFeature: emulation Logical margins %%IncludeFeature: margins Select color separations %%IncludeFeature: colorseparation Select color or monochrome...
