8. CARE AND MAINTENANCE

Clean the exterior with a soft, lint-free, anti-static
cloth. Do not use force while wiping the surface.
To remove difficult stains use a few drops of
detergent on a moist cloth, sweep carefully and
wipe dry afterwards.
If some scratching occurs, please consult your
Sphinx dealer first. He can give you advice about
possible solutions.

9. TECHNICAL SPECIFICATIONS

Bandwidth
Phase response error
Gain
THD+N (IHF-A)
IMD
S/N ratio (IHF-A)
Channel separation
Slew Rate
Inputs
Level, nominal (for 1 V output)
Impedance
Capacity
Outputs
Level
Impedance
Rumble filter
Sphinx Control
Power supply
Supply capacitance
Power transformer
Power consumption
Housing
Dimensions (h x b x d)
Weight
Measurements done while using the following settings: (@1 kHz, MC input, Gain High, Ri 100 ohm)
This unit conforms to the EMC interference regulations issued by the EU and to the CE standards.
This unit complies with safety regulation VDE 0860 and therefore with international safety regulation IEC 65.
Technical specifications may be changed by SPHINX without prior notice if technical developments make this
necessary.
©1999 Audioscript BV
SPHINX
Do not use polishing or cleaning agents: they
may damage the sensitive acrylic finish.
Do not use aerosol cleaning agents.
Most contain solvents, which might react with and
damage the acrylic finish.
0 - 111,000 Hz (+0/-3 dB)
<1°
High: 66 dB max. (2000x)
Mid: 58 dB max. (800x)
Low: 37 dB max. (70x)
<0.02% (2
<0.6%
>80 dB (>90 dB)
>95 dB
>24 V/ s
2x cinch (gold plated)
0.13 V (-18 dBV)
51 kohm, 200 ohm, 100 ohm, 50 ohm (selectable)
MM: 47 pF or 147 pF (selectable)
2x cinch (gold plated)
1.1 V nominal
9.2 V max. (19.3 dBV) (1 – 100,000 Hz, THD <0.02%)
<10 ohm
12 dB/octave @ 10 Hz
1x optical IN, 1x optical OUT
Internally, fully stabilised
16,280 µF total
O-core
10 W (7 W standby)
1,5 mm steel, with powder coating
Chassis acoustically decoupled
70 x 120 x 340 mm
6.5 kg
Phono Equaliser
nd
harm., 10 – 20,000 Hz)
12
