PCFL-HNG
PCF-HNG
Patio Campfi re
Decorative Gas Log Set
• Important operating and
maintenance instructions
included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or
the gas supplier.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and follow
•
these instructions for safe
installation and operation.
Heat-N-Glo Lifestyles • Patio Campfi re • 4004-001 Rev D • 07/05
Owner's Manual
Leave this manual with
•
party responsible for
use and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
•
Keep children away.
•
CAREFULLY SUPERVISE children in same room as
appliance.
•
Alert children and adults to hazards of high
temperatures.
•
Keep clothing, furniture, draperies and other
combustibles away.
Installation and service of this appliance should be performed
by qualified personnel. Hearth & Home Technologies
suggests NFI certifi ed or factory-trained
professionals, or technicians supervised
by an NFI certifi ed professional.
Installation and Operation
1
Advertisement
Table of Contents
Summary of Contents for Heat & Glo LifeStyle PCFL-HNG
- Page 1 Owner’s Manual Installation and Operation Models: PCFL-HNG PCF-HNG Patio Campfi re Decorative Gas Log Set CAUTION DO NOT DISCARD THIS MANUAL Read, understand and follow Leave this manual with • • • Important operating and these instructions for safe party responsible for maintenance instructions installation and operation.
- Page 2 Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. Congratulations Congratulations on selecting a Heat-N-Glo Lifestyles The information contained in this owner’s manual, unless decorative gas log set. The Patio Campfi re you have selected noted otherwise, applies to all models and gas control is designed to provide the utmost in safety, reliability, and systems.
-
