Status info from CDSA
The CDSA sends back 10 Bytes terminated with a <CR> whenever any status changes.
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
Byte 9
CDSA User Manual
Byte 0 Byte 1
Seconds ones in ASCII
Seconds tens in ASCII
Minutes ones in ASCII
Minutes tens in ASCII
Hours ones in ASCII
Track number ones in ASCII
Track number tens in ASCII
bit 0 1 when "Reading" indicator is on (front panel)
bit 1 1 when "Repeat Track" indicator is on( front panel)
bit 2 1 when "Repeat All" indicator is on (front panel)
bit 3 1 when "CD PCM 2HC" indicator is on (front panel)
bit 4 1 when "SACD 2CH" indicator is on (front panel)
bit 5 reserved
bit 6 reserved
bit 7 1 when DVD disc is selected (DVD-V or DVD-A)
bit 0 reserved
bit 1 1 when front panel display is off
bit 2 1 when CDSA in Standby mode
bit 3 1 when "No Disc" indicator is on (front panel)
bit 4 reserved
bit 5 reserved
bit 6 1 when in pause
bit 7 1 when audio phase inverted
<CR> (x0D)
Byte 9 <CR>
