Abocom 10/100/Gigabit CardBus PC Card FG2003 Specification Sheet

10/100/Gigabit CardBus PC Card
The real 32-bit CardBus 10/100/1000M Gigabit Ethernet PC Card is here. The
Gigabit CardBus Card gears with leading 32-bit bus architecture and full-duplex
capability, which liberates an unmatched high-speed network performance. By
providing smoothly connection to 10M bps, 100M bps and Gigabit Ethernet
environments, the Gigabit CardBus Card is the ultimate solution for the
equipped laptops. In addition, its auto-negotiation feature also configures to meet any kind of network connective
modes.

Features

PCMCIA CardBus standard compliant
32-bit bus-mastering data transfer
10M bps, 100M or 1000M bps data rates
auto-negotiation
Support Full Duplex flow control (IEEE 802.3x)
Diagnostics LED indicators: Power, 10 /100
Link/Act, Gigabit Link/Act,
Support both Category 3/5 (10BaseT) and
Category 5e (100BaseTX/1000BaseT)
IEEE 802 IP Layer 2 priority encoding
Specification
Standards
Port

Power consumption

Temperature
Humidity
Supported OS
LED Indicators
Physical Specification
Safety & Emission
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseTX
IEEE 802.3ab for 1000BaseT
PCMCIA CardBus PC Card standard
1 x RJ 45 phone jack
695 mA (in operation)
600 mA (idle)
Operating: 0~70 ℃
Storing: -10~70 ℃
10%~85% (non-condensing, storage)
Windows 98SE, Windows 2000, Windows ME, Windows XP,
LED1: 10/100M link act (10 for green, 100 for blue)
LED2: 1G act for Blue
LED3: Power for Blue
Dimension : 120 (L)X 54
Weight : 45 g
FCC
CE
VCCI
CardBus
802.1Q VLAN tagging
Microsoft NDIS5 (IP, TCP, UDP) Checksum and
Segmentation Task off-loading
Support all major Network Operating Systems
(NOS)
PC Card hot swap supported
Ultra low power consumption
(W) X 5 (H)
