Summary of Contents for ESPOD VITEK MD-1102

  • Page 1 VITEK MD-1102 User Manual...

  • Page 2: Table Of Contents

    Contents Introduction ......................1 Application ..................... 1 Environment ..................1 System Requirements ................2 Safety Precautions ................2 LED Status..................... 3 1.5.1 Front Panel ................. 3 1.5.2 Rear panel .................. 3 Hardware Installation ..................4 ADSL Connection of Router ..............4 USB Installation ..................

  • Page 3: Introduction

    Introduction The Router is a highly ADSL2+ integrated access device and can support ADSL link downstream up to 24 Mbps and upstream up to 1 Mbps, which is designed to provide a simple and cost-effective ADSL Internet connection for a private Ethernet.

  • Page 4: System Requirements

    Storage temperature: -10 ºC ~55 ºC (14ºF~131ºF) Operating humidity: 10%~95%, non-condensing Storage humidity: 5%~95%, non-condensing Power adapter input: 100 V—240 V AC, 50/60 Hz Power adapter output: 12 V DC, 500 mA 1.3 System Requirements Pentium 233 MHz or above Memory: 64 MB or above 10M Base-T Ethernet or above Windows 9x, Windows 2000, Windows XP, Windows ME, Windows NT or...

  • Page 5: Led Status

    1.5 LED Status 1.5.1 Front Panel Status Description Power is off. Power Power is on and the device operates normally. No signal is detected. Link Blink DSL line training is in progress. DSL line connection is up. Data Blink Traffic is in progress. No Ethernet signal is detected.

  • Page 6: Hardware Installation

    Interface Description RJ-11 port: Connect the router to ADSL connector or splitter Line through telephone line. USB device interface for connecting to PC or other network devices. RJ-45 port, for connecting the router to a PC or other network Ethernet devices through Ethernet cable.

  • Page 7: Usb Installation

    Connect the Ethernet port of the router to the network card of the PC through an Ethernet line. Plug the power adapter to the wall outlet and then connect the other end of it to the Power port of the router. 2.2 USB Installation To connect the DSL router to the USB port of PC, perform the following: Connect the USB cable to the USB port on the DSL router.

  • Page 8: Web Configuration Management

    CD-ROM. Click Next. The system searches CD-ROM for the best USB driver. Then you can install the USB driver according to the instructions. Web Configuration Management 3.1 Logging In to the Router Step 1 Open the Internet Explorer or Netscape Web browser and enter http://192.168.1.1 (default IP address).

  • Page 9: Quick Setup - Pppoe

    3.2 Quick Setup – PPPoE After finishing logging, the Quick Setup page appears shown as the following figure, if you do not configure the PVC of WAN connection. Note: This section describes the procedure for adding PVC 0/35 (PPPoE mode). If you want to configure the WAN connection in another mode, refer to 3.4.1 WAN Configuration.
  • Page 10 Step 3 After proper configuration, click Next, and the following page appears. In this page, you can modify the PPP user name, PPP password, authentication method and so on. PPP Username: The correct user name that your ISP provides to you. PPP Password: The correct password that your ISP provides to you.
  • Page 11 Dial on demand (with idle timeout timer): If this function is enabled, you need to enter the idle timeout time. PPP IP extension: If this function is enabled, the WAN IP address obtained by the router through built-in dial-up can be directly assigned to the PC being attached to the router (at this time, the router connects to only one PC).
  • Page 12 Step 6 Click Next and ensure that the below settings match the settings provided by your ISP. See the following figure.

  • Page 13: Dsl Router Device Information

    Step 7 Click Save/Reboot to save your configurations. The setting for PPPoE is complete. Note: After the Quick Setup is completed, you can add the new WAN configuration in Advanced Setup. Select Advanced Setup > WAN, the following figure appears, you can click Add to add WAN configuration. 3.3 DSL Router Device Information Choose Device Info, the following page appears.

  • Page 14: Advanced Setup

    3.4 Advanced Setup 3.4.1 WAN Configuration Choose Advance Setup > WAN, the following page appears. To modify the parameters of an existing PVC, click Edit. To add an ATM PVC, click Add. To delete a PVC, select the Remove check box in the table and click Remove.
  • Page 15 This page the same as the Quick Setup page. The procedure for adding a PVC is described as follows. 3.4.1.1 Adding a PPPoE PVC This section describes the procedure for adding PVC 8/35 (PPPoE mode). Click Add and the following page appears. In this page, you can modify VPI/VCI, service categories, and QoS.
  • Page 16 After proper modifications, click Next and the following page appears. In this page, you can modify the Internet connection type and encapsulation type. Change the connection type of PVC 8/35 to PPP over Ethernet (PPPoE) and set the Encapsulation Mode to LLC/SNAP-BRIDGING (according to the uplink equipment).
  • Page 17 Click Next and the following page appears. In this page, you can modify the PPP user name, PPP password, authentication method and so on. PPP Username: The correct user name that your ISP provides to you. PPP Password: The correct password that your ISP provides to you. PPPoE Service Name: If your ISP provides it to you, please enter it.
  • Page 18 Dial on demand (with idle timeout timer): If this function is enabled, you need to enter the idle timeout time. Within the preset minutes, if the router does not detect the flow of the user continuously, the router automatically stops the PPPoE connection. Once it detects the flow (like access to a webpage), the router restarts the PPPoE dialup.
  • Page 19 IGMP Multicast: IGMP proxy. For example, if you wish that the PPPoE mode supports IPTV, enable this function. WAN Service: Enable it, unless you do not want to active the PVC. Click Next and the following page appears. This page shows all the configuration. You can view the default values of network address translation (NAT) enable and Firewall enable.
  • Page 20 Note: You need to reboot the router to activate this WAN interface and further configure services in this interface. 3.4.1.2 Adding a PPPoA PVC This section describes the procedure for adding PVC 8/35 (PPPoA mode). Click Add and the following page appears. In this page, you can modify VPI/VCI, service categories, and QoS.
  • Page 21 VCI: Virtual channel between two points in an ATM network. Its valid value range is from 32 to 65535 (1 to 31 are reserved for known protocols). Service Category: UBR Without PCR/UBR With PCR/CBR/Non Realtime VBR/Realtime VBR. Enable Quality Of Service: Enable or disable QoS. In this example, PVC 8/35 is to be modified and the default values of service category and QoS remain.
  • Page 22 In this page, you can modify the PPP user name, PPP password, authentication method and so on. PPP Username: The correct user name that your ISP provides to you. PPP Password: The correct password that your ISP provides to you. Authentication Method: The value can be AUTO, PAP, CHAP, or MSCHAP.
  • Page 23 PPP IP extension: If this function is enabled, the WAN IP address obtained by the router through built-in dial-up can be directly assigned to the PC being attached to the router (at this time, the router connects to only one PC). Use Static IP Address: If this function is disabled, the router obtains an IP address assigned by an uplink equipment such as BAS, through PPPoA dial-up.
  • Page 24 To save the settings, click Save. To make any modifications, click Back. Note: You need to reboot the router to activate this WAN interface and further configure services in this interface. 3.4.1.3 Adding an MER PVC This section describes the procedure for adding PVC 8/35 (MER mode). Click Add and the following page appears.
  • Page 25 VPI: The virtual path between two points in an ATM network, and its valid value is from 0 to 255. VCI: Virtual channel between two points in an ATM network. Its valid value range is from 32 to 65535 (1 to 31 are reserved for known protocols). Service Category: UBR Without PCR/UBR With PCR/CBR/Non Realtime VBR/Realtime VBR.
  • Page 26 Change the connection type of PVC 8/35 to MAC Encapsulation Routing (MER) and set the Encapsulation Mode to LLC/SNAP-BRIDGING (according to the uplink equipment). Click Next and the following page appears. In this page, you can modify the WAN IP address, default gateway, and DNS server settings.
  • Page 27 Obtain an IP address automatically: The router obtains a WAN IP address automatically and at this time it enables DHCP client functions. The WAN IP address is obtained from the uplink equipment like BAS and the uplink equipment is required to enable the DHCP server functions. Use the following IP address: If you want to manually enter the WAN IP address, select this check box and enter the information in the field.
  • Page 28 Use WAN Interface: As to BAS equipment, it is the IP address of the downlink interface. Obtain DNS server address automatically: To obtain the IP address of the DNS server assigned by the uplink equipment such as BAS. Use the following DNS server addresses: If you want to manually enter the IP address of the DNS server, select this check box and enter the information in the fields.
  • Page 29 port. Furthermore, any external host can send a packet to the internal host, by sending a packet to the mapped external address. Enable Firewall: Enable or disable IP filtering. IGMP Multicast: IGMP proxy. For example, if you wish that the MER mode supports IPTV, enable this function.
  • Page 30 3.4.1.4 Adding an IPoA PVC This section describes the procedure for adding PVC 8/35 (IPoA mode). Click Add and the following page appears. In this page, you can modify VPI/VCIs, service categories, and QoS. VPI: Virtual path between two points in an ATM network. Its valid value range is from 0 to 255.
  • Page 31 In this example, PVC 8/35 is to be modified and the default values of service category and QoS remain. In actual applications, you can modify them as required. After proper modifications, click Next and the following page appears. In this page, you can modify the Internet connection type and encapsulation type. Change the connection type of PVC 8/35 to IP over ATM (IPoA) and set the Encapsulation Mode to LLC/SNAP-ROUTING (according to the uplink equipment).
  • Page 32 Click Next and the following page appears. In this page, you can modify the WAN IP, default gateway, and DNS server settings.
  • Page 33 WAN IP Address: Enter the IP address of the WAN interface provided by your ISP. WAN Subnet Mask: Enter the subnet mask concerned to the IP address of the WAN interface provided by your ISP. Use the following Default Gateway: If you want to manually enter the IP address of the default gateway, select this check box and enter the information in the fields.
  • Page 34 Enable NAT: Select it to enable the NAT functions of the router. If you do not want to enable NAT and wish the router user to access the Internet normally, you must add a route on the uplink equipment. Otherwise, the access to the Internet fails.
  • Page 35 Note: You need to reboot to the router to activate this WAN interface and further configure services in this interface. 3.4.1.5 Adding a Bridge PVC This section describes the procedure for adding PVC 8/35 (Bridge mode). Click Add and the following page appears. In this page, you can modify VPI/VCIs, service categories, and QoS.
  • Page 36 VPI (Virtual Path Identifier): Virtual path between two points in an ATM network. Its valid value range is from 0 to 255. VCI (Virtual Channel Identifier): Virtual channel between two points in an ATM network. Its valid value range is from 32 to 65535 (1 to 31 are reserved for known protocols).
  • Page 37 WAN Service: Enable it, unless you do not want to active the PVC. Click Next and the following page appears. This page shows all the configuration. To save the settings, click Save. To make any modifications, click Back. Note: You need to reboot the router to activate this WAN interface and further configure services in this interface.

  • Page 38: Lan Configuration

    3.4.2 LAN Configuration You can use the LAN configuration to define an IP address for the DSL Router and configure the DHCP server.
  • Page 39 3.4.2.1 Defining the Private IP Address for the DSL Router In this page, you can change the IP address of the device. The preset IP address is 192.168.1.1. This is the private IP address of the DSL Router, under which the device can be reached in the local network.

  • Page 40: Enabling Igmp Snooping

    After you install UPnP in the operating system of a PC and activate it in the router, applications on this PC (for example, Microsoft Messenger) can communicate via the Internet without authorization. In this case, the router automatically implements port forwarding, thereby facilitating communication via the Internet. The task bar in the PC in which UPnP is installed contains an icon for the DSL Router.

  • Page 41: Configuring The Dhcp Server

    3.4.2.4 Configuring the DHCP Server The DSL Router has a DHCP server for which the factory setting is active. Consequently, the IP addresses of the PCs are automatically assigned by the DSL Router. Note: If the DHCP server for the DSL Router is activated, you can configure the network setting on the PC so that the option Obtain an IP address automatically is set up.
  • Page 42 3.4.2.5 Reserve IP Address If you want to reserve one specific IP address for a certain PC by MAC address, edit the reserved IP Address List. 3.4.2.6 Configuring the Second IP Address and Subnet Mask for LAN Interface...

  • Page 43: Nat

    3.4.3 Note: The NAT information is not displayed in the bridge mode. Click Advanced Setup > NAT, and the following page appears. This part contains Virtual Servers, Port Triggering, and DMZ Host. Choose the item to do relative configurations. 3.4.4 Security Security is an important function of DSL.

  • Page 44: Outgoing Ip Filtering Setup

    Note: If the router is configured to bridge mode only, IP filtering is disabled and the IP filtering interface does not appear. If no PVC of Bridge mode is configured, MAC filtering is disabled and the MAC Filtering interface does not appear. 3.4.4.1 Outgoing IP Filtering Setup When setup of outgoing IP filtering rules is enabled on the router, various security functions for the local network are enabled at the same time.
  • Page 45 Click Add and the page for defining the IP filtering rule appears. In this page, you can create a filter rule to identify outgoing IP traffic by specifying a new filter name and at least one condition. All specified conditions in the filtering rule must be complied with the rule to take effect.
  • Page 46 Request I need to block PC1 whose IP address is 192.168.1.10. All outgoing UDP/TCP packet from that PC1 (192.168.1.10) is not allowed. Allow all outgoing traffic packet from PC2 (192.168.1.11). Configuration Step 1 By default, all outgoing IP traffic from LAN is allowed. Hence, all outgoing IP packets from PC2 are allowed.

  • Page 47: Incoming Ip Filtering Setup

    Step 2 Click Save/Apply and the following page appears: 3.4.4.2 Incoming IP Filtering Setup The incoming IP filter is used to block and permit IP packet transmisstion from internet. By default incoming IP filter block all incoming packet from Internet. When incoming IP filtering rules setup being enable on the router, you can permit remote individual PC to access various local network service.
  • Page 48 Filter Name: Enter the name of incoming filter rule. Protocol: Select one from TCP/UDP, TCP, UDP, and ICMP protocols. Source IP address: Enter an IP address. After you set the IP address, the incoming packets (protocol selected packets) are allowed. Source port: UPD/TCP source port or a range of ports.
  • Page 49 Request I need to permit a PC whose IP address is 10.10.10.10. All Incoming TCP/UDP packet traffic from that PC (10.10.10.10) is allowed. Block all IP traffic from other PCS. Configuration Step 1 By default, all incoming IP traffic from Internet is blocked. Hence, all incoming IP packets from other PCS except PC (10.10.10.10) are blocked.

  • Page 50: Parental Control

    Step 3 Click Save/Apply and the following page appears: 3.4.4.3 Parental Control If you allow your children to access to the Internet in the specific time, add the schedule with the LAN MAC address of the device. Choose Security > Parental Control and the following page appears.

  • Page 51: Quality Of Service

    In this page, you can add time of day restriction to a specific LAN device connected to the Router. Enter the user name, select days of week and the blocking time, and click Save/Apply. The following page appears: 3.4.5 Quality of Service Many communication and multimedia applications require large, high speed bandwidths to transfer data between the local network and the Internet.
  • Page 52 Select Enable QoS to enable QoS and set the default DSCP mark. Click Save/Apply to active QoS. 3.4.5.2 QoS - Queue Configuration The queuing in packet QoS becomes effective only when packet is forwarded to QoS-enabled PVC. Packet forwarding is determined by IP routing or bridging, not under control of the packet QoS.
  • Page 53 Queue Configuration Status: Set to enable or disable a QoS queue. Queue: Select a specific network interface. The router automatically allocates selected network interface to the queue. Queue Precedence: Select an integer value for queue precedence. After you select an integer value, the queue entry appropriately places to ingress packets. Lower integer values for precedence imply higher priority for this queue relative to others.
  • Page 54 Click Add, and the following page appears. Traffic Class Name: Enter a name of the class. Rule Order: Select order for queue. Rule Status: Enable or disable this traffic class rule. Assign Classification Queue: Select a classification queue. Assign Differentiated Service Code Point (DSCP) Mark: Select a mark service that modifies the original packet IP header if all rules defined within the classification class are matched.

  • Page 55: Routing

    There are two sets of classification rules. Set-1 is based on different fields within TCP/UDP/IP layer plus physical LAN port; Set-2 is based on MAC layer IEEE 802.1p priority field. 802.1p priority: The 802.1p header includes a 3-bit prioritization field, which allows packets to be grouped into eight levels of priority (0-7), where level 7 is the highest one.

  • Page 56: Static Routes

    Use Default Gateway: Select the Enable automatic Assigned Default Gateway box. Custom DSL router Default Gateway Enable Automatic Assigned Default Gateway Use Default Gateway IP Address Use Interface: interface that the packets pass through on the router Click Save/Apply to apply the settings. 3.4.6.2 Static Routes Networking devices forward packets using route information that is either manually configured or dynamically learned using a routing protocol.

  • Page 57: Dns

    Adding Static Route Step 1 Enter destination network address. Step 2 Enter subnet Mask. Step 3 Enable Use Gateway IP Address and enter IP address. Step 4 Select use interface. Step 5 Click Save/Apply to apply the settings. Remove static route Select Remove box in the table, and click Remove to apply the settings.

  • Page 58: Dsl

    3.4.8 In this interface, you can view the DSL settings. Normally, you can keep the factory default settings. The router support these modulations: G.Dmt, G.lite, T1.413, ADSL2, AnnexL, ADSL2+ and AnnexM. The router negotiates the modulation mode with the DSLAM. Click Advanced Settings, and the following page appears.

  • Page 59: Diagnostics

    3.5 Diagnostics Click Diagnostics, and the following page appears. Your router is capable of testing your DSL connection. The individual tests are listed above. If a test displays a fail status, click Rerun Diagnostic Tests at the bottom of this page to make sure the fail status is consistent. If the test continues to fail, click Help and follow the troubleshooting procedures.

  • Page 60: Management

    3.6 Management 3.6.1 Setting Settings - Backup Select the “Backup” to show the following interface. In the interface, you can backup the DSL router configurations. Settings - Update Select the “Update” to show the following interface. Click the “Browsing...” button to select the correct update configure settings file.

  • Page 61: System Log

    3.6.1.1 Settings Restore Default Click Management > Settings > Restore Default to restore DSL router to the factory default configuration. 3.6.2 System Log Click Management > System Log, and the following page appears. The system log dialog allows you to view the system log and configure the system log options.
  • Page 62 Both the log level and display level have eight choices. The default log level is “Debugging” and the default display level is “Error”. The mode options are “Local”, “Remote”, and “Both”. The default option is “Local”. If you select “Remote” or “Both”, all events are transmitted to the specified UDP port of the specified log server.

  • Page 63: Internet Time

    Note: The log and display of the system events are above the set level. If you intend to record all information, you need to set the levels as “Debugging”. Click “Refresh” to refresh the system event logs or “Close” to exit from this interface.

  • Page 64: Access Control

    After enable Automatically synchronize with Internet time servers, the interface show below. Enter proper configurations and click Save/Apply. 3.6.4 Access Control Access Control – Services Select “Access Control”-->”Services” to show the following interface. In the interface, you can enable/disable the FTP, HTTP, ICMP, TELNET and TFTP services.
  • Page 65 Access Control – IP Addresses Choose Access Control > IP Addresses and the following page appears. In this page, you can add or remove the IP address in the IP access control list. If the Access Control Mode is enabled, it indicates that the router permits the access to local management services from the IP addresses contained in the access control list.

  • Page 66: Update Software

    3.6.5 Update Software Click “Update Software” to show the following interface. In this interface, you can update the router software. Click the “Browse...” button to find the right version file and press “Update Software” to do the update.

  • Page 67: Save/Reboot

    Note: Do not turn off your router during firmware updates. When the update is finished, the router reboots automatically. Do not turn off your router before the reboot is over. You must guarantee the update software is right and accurate. It is strictly forbidden to use other software for updates. After update software, it is suggested to restore the router to the factory defaults and configure it again.
  • Page 68 A: Check whether the VPI, VCI, user name, and password are correctly entered. (5) Q: Why does the web configuration page of the router fail to be accessed? A: Choose Start > Run from the desktop, and ping 192.168.1.1 (IP address of the router).
