  • Page 1 4 / 8CH H.264 STANDALONE DVR VEDVR 2304B / VEDVR2308B USER MANUAL 2011 April. V1.0...
  • Page 2 WARNING Do not expose the DVR under the sunlight, heat or wet environment while installation. As it could decrease the performance of DVR and damage the machine. Do not touch the power plug or case with wet hands as this could result electric shock. Do not forcedly bend or put heavy object on power cable as this could result in injury to personal or equipment.

  • Page 4: Table Of Contents

    CONTENTS Specification ..................... 1 Front Panel ....................2 Installation ....................3 DVR Installation ..................3 System Operation ..................4 Display Setup ................... 6 Search ...................... 8 Main Menu ....................10 8.1 Camera Setup ................11 8.2 Record Setup ................. 13 8.3 Alarm Setup ...................

  • Page 5: Specification

    1. Specification Video Format NTSC Video Input 4 / 8 CH Input / BNC Audio Input 4 CH Input / RCA Video Output 1CH Output / BNC Audio Output 1CH Output / RCA XGA Output 800x600, 1024x768, 1280x1024, 1440x900 Alarm Input 4CH Alarm In Alarm Output Buzzer，1 x Relay Out (N.O、N.C)

  • Page 6: Front Panel

    2. Front Panel Under the live viewing mode, press MENU to enter the main menu. MENU Under the menu mode, press MENU to go to the upper menu. Under the playback mode, press the STOP button to stop the operation Stop or go to the upper menu.

  • Page 7: Installation

    3. Installation USB Mouse Port 2.0 USB Mouse Video In 8CH Video Input (BNC) Video Out 1CH Video Output (BNC) Audio Out 1CH Audio Output (RCA) Audio In 4CH Audio Input Alarm Alarm I/O DC12V Power Input PC Monitor Output RJ-45 Network Connection RS-485 For Speed Dome Use...

  • Page 8: System Operation

    Alarm Installation Please refer to Installation for external alarm I/O installation. Please refer to Alarm Setup. Speed Dome Installation This device can support 3 kinds of communication protocol (Pelco D, Pelco P & MIKAMI) Power Installation Please use the provided power cable and adaptor to connect the DVR (AC100V~AC230V).
  • Page 9 Virtual Keyboard Operation The text input of the virtual keyboard is as below: Front Panel & Remote Menu Operation Mouse Operation Control Operation Select character from virtual keyboard [Up/Down/Left/Right] [Move Cursor] Keyin the select character [Enter] [Left Click] Exit the virtual keyboard [MENU] [Left Click]out of selection area Key Description of Virtual Keyboard...

  • Page 10: Display Setup

    Setup Operation Front Panel & Remote Control USB Mouse Select [Up/Down/Left/Right] [Moving Cursor] Confirm Select Setting [Enter] [Left Click] Change the Select Setting [Left/Right] [Left Click] Return to Upper Menu [MENU] Right Click 6. Display Setup There are 3 kinds of screen display mode: Live, Auto Switching and PTZ. DVR. Live Viewing Mode The DVR will go to the live viewing mode after boot up.
  • Page 11 Quick Menu Setup Operation Front Panel & Remote Control USB Mouse Select Item [Left/Right] [Moving Cursor] Enter the Select Item [Up/Down] [Moving Cursor] Confirm the Select Item [Enter] [Left Click] Exit [MENU] [Left Click] out of selection area Please set the speed dome properly before control PTZ. Please refer to PTZ Setup.

  • Page 12: Search

    Playback Operation Setup Operation Front Panel & Remote Control USB Mouse Fast Rewind [Fast Rewind] Fast Forward [Fast Forward] Step Forward [StepForward] Step/Pause [Step/Pause] Play 1x [Play] Stop [Stop] Digital Zoon Drag by Left Click 1~8Single Channel Display [1~8 Channel] Select Channel [Double left click] Under single channel [Double left 8split Display...
  • Page 13 Front Panel & Remote Setup Operation USB Mouse Controller Search [Enter] [Left Click] Select Channel [Up/Down] [Moving Cursor] Select Dates [Up/Down/Left/Right] [Moving Cursor] Playback [Enter] [Left Click] Return to Upper Menu [MENU] [Right Click No data: no color, data of alarm trigger: red color, normal record data: green color.

  • Page 14: Main Menu

    Front & Remote Setup Operation USB Mouse Controller Enter Select Item [Enter] [Left Click] Select Item [Up/Down/Left/Right] [Moving Cursor] Return to Upper Menu [MENU] [Left Click] First Page Previous Page Next Page Last Page Mark all the events in this page BackUp List all of recording data and click on one of record data to playback.

  • Page 15: Camera Setup

    8.1 Camera Setup Channel Select one channel to set. Use CopyButton to copy present settings to other channels. Camera Title Set the title of camera. Key in by using virtual keyboard. Title Position Set the title position. Set: Top Left, Top Right, Bottom Left, Bottom Right and Off.
  • Page 16 Type Speed dome model type. Set: PTC-301, PTC-203ST, FUM 626, JG_QG988, FUM 622SD, FUM 628 or off. Please select the correct communication protocol if you enable this setting. Protocol Speed dome protocol. Set: PELCO P, PELCO D, MIKAMI or off. Address Speed dome address.

  • Page 17: Record Setup

    Buzzer Duration The buzzer ON duration when video loss. Alarm Relay Duration The Relay ON duration when video loss. Time Display Display the time in LIVE mode. Values: ON/OFF. 8.2 Record Setup Channel Switch On/Off the channel. Resolution NTSC Recording Resolution : 720x480, 720x240, 360x240. PAL Recording Resolution: 720x576, 720x288, 360x288.

  • Page 18: Alarm Setup

    Front Panel & Remote Setup Operation USB Mouse Controller Enter Select Item [Enter] [Left Click] Select Channel [Up/Down] [Moving mouse wheel] Select Time&Date [Up/Down/Left/Right] [Click/Drag-draw] Return to Upper Menu [MENU] [Right Click] Copy (1) Select source (2) Select target (3) Press COPY icon to copy. 8.3 Alarm Setup Channel Select the channel to set.

  • Page 19: Network Setup

    Motion Detection Select the channel to set. COPY icon can copy the present setting to other channels. Channel Status Enable/disable motion detection for each camera. Set: On/Off Sensitivity Sensitivity level of motion detection. Set: 1~10. Higher value equal more sensitive. Motion Area Setup Setup by each small square.
  • Page 20 Mode Set the connection method. Set: Static IP, DHCP, PPPoE. Media port Port used for stream media. Default is port 9000. Webport Port used for web access. Default is port 80. Command Port Port used for settings. Default is port 8000. IP Address Assigned IP address.

  • Page 21: Log Search

    E-MAIL Forward E-mail after alarm triggered. Enable: On/Off Enable the SSL encryption. Recommend to set on if it is using gmail. SMTP port SMTP port number key in. For example, gmail port 465. SMTP Server SMTP server key in. For example, gmail : smtp.gmail.com From Sender E-mail address key in.

  • Page 22: Backup

    Setup Operation Front & Remote Controller USB Mouse Enter Select Item [Enter] [Left Click] Select Item [Up/Down/Left/Right] [Moving Cursor] Return to Upper Menu [MENU] [Right Click] First Page Previous Page Next Page Last Page Backup to USB disk ★ When Trigger Recording is marked , Click to playback. 8.7 Backup Channel Backup all channels or single channel 1-8.

  • Page 23: System

    8.8 System 8.8.1 Time Setting Date/Time Select by using virtual keyboard. Date Format Setup Set: YY/MM/DD, MM/DD/YY. Time Format Setup Set: 24Hours, 12Hours. Time Zone Setup Time Zone setting of DVR. NTP Setting（Network Time Protocol） NTP: On or Off Schedule Time: Using virtual keyboard NTP server: Using virtual keyboard...

  • Page 24: Hdd Setup

    8.8.2 HDD Setup Format Format the selected HDD Format HDD Overwrite Enable/Disable Overwrite, Values: On/Off. If Overwrite is enabled, the period can be set as 6, 12, 24, 36, 48 hours and 7, 15, 30, 60 days. Pack Time Set the required packing time frame to allow the system to pack each saving file under continue recording mode.

  • Page 25: Display Setting

    Format USB Memory Stick 8.8.3 Display Setting GUI Display GUI display mode can be VIDEO or VGA. Video Switching Time Set the switching time when switching channels in video mode. Values: 1-99 seconds. (0 sec is Off) VGA Switching Time Set the switching time when switching channels in VGA mode.

  • Page 26: System Information

    XGA Resolution XGA Resolution: 800x600, 1024x768, 1280x1024, 1440x900. 8.8.4 System Information Provide the firmware version, MAC address, HDD status…. 8.8.5 User password Password Setup Enable/Disable password checking. Values: On/Off (Default) Administrator account/password can not be blank. And at least 4 characters for the password.

  • Page 27: System Language

    8.8.6 System Language Language Values: Traditional Chinese, Simplified Chinese and English. Auto rebooting after change. Function Tip Show function tips below the menu items. Value: On/Off (Default). 8.8.7 Audio setting Audio Volume Set the volume of audio In/Out. Values: 1-10. (Default: 5) 8.8.8 System Maintenance Auto maintenance: Set time for auto rebooting.

  • Page 28: Cell Phone Monitoring Operation

    F/W update Please plug the USB memory stick into the USB port on the DVR rear panel after download the new firmware to the USB memory stick. Note: the firmware only can be upgraded by using the USB port. Please don’t operate the system, remove the USB memory stick or remove the power while it is in upgrade progressing in order to prevent any serious system error.
  • Page 29 6. Enter the correct IP address and click on “Open” 7. Click on “Connect” to connect to the DVR. 8. Connecting 9. Connected Capture Menu Channel[1~8] 10. If fail to connect, please repeat steps 7 to 9.
  • Page 30 Android mobile surveillance: The mobile phone must support Android 2.1 (Test mobile: Motorola XT701). Open Internet Explorer on the mobile phone. Enter the IP Address of DVR. Connected. Channel: Channel selection. Display Delay: Display Delay selection. SIZE: Display size selection. 3G MOBILE SUPPORT LIST Brand Model Number...

  • Page 31: H264Player Operation

    H264Player Operation Preface H264Player software allows to playback the backup saving file from the DVR. System Requirement Operating System: Windows 2000, XP, Vista, Windows 7. Program obtainment and installation While user start to backup the file from DVR, the system will automatically copy the H264Player.exe file and recorded data to the backup device for example, an USB flash memory stick.
  • Page 32 Step4: Install Confirmation Step 5: Installation Complete User Interface Open File Click Pause Click Stop Click Play 1x Click Fast Forward Click Slow Forward Click Capture the image (snap Click shot) to the host computer Volume Control Drag...

  • Page 33: Web Operation

    Rewind Click Step Forward Click Right click the mouse to open the Pop-up Menu pop-up menu including Setting, Language, About H264Player, Exit Web Operation Preface The Web Application Manager allows the user to remotely monitoring, playback, backup through the DVR. System Requirement Operating System: Windows 2000, XP, Vista, Windows 7 Web Browser: Internet Explorer...

  • Page 34: Live Mode

    Please login user name and password from the setting of DVR end. Live mode Start/Stop the Live Monitoring Click Click Start recording or Stop recording Record the Footage to Computer (saving path: Setup/Information) Click to snap shot the image (saving path: Snapshot the Image Setup/Information) Click...

  • Page 35: Dvr Setting

    Playback (1) Select Date Event Search (2)Click (3)Click Playback Click on pop up file list Fast Forward Click “Fast Forward” (Speed: 2X, 4X, 8X, 16X) Rewind Click “ Rewind” (Speed: 1/2, 1/ 4X, 1/ 8X, 1/ 16X) Step Forward Click “Previous”or “Step” Snapshot Click to capture.
  • Page 36 Record Please refer “Record Setup” for more information. Alarm Please refer “Alarm Setup” for more information. MotionDetection...
  • Page 37 Please refer “Motion Detection” for more information. Network setting E-MAIL Log search...
  • Page 38 System Setting Date/Time Setting HDD Management Display...
  • Page 39 System Information Account/password Audio Setting...
  • Page 40 System Maintenance Host setting...

  • Page 41: Default Setting

    12. Default Setting Item Default Setting Item Default Setting Channel Overwrite HDD Setup Resolution Normal Pack Time 60 Mins Record Frame Rate Real-time Date Format YY/MM/DD Setup Quality Highest Time Format 24 Hours Time Setup Audio Disable Time Zone GMT+08:00 Schedule Always Daylight Saving...

  • Page 42: Usb Flash Memory Stick Support List

    USB Flash Memory Stick Support List The following recommended flash drives have passed all testing procedures and are safe to a: backup, b: Playback by PC, and c: update firmware. Brand Model Number Capacity Jetflash V20 Jetflash V20 Transcend Jetflash V30 Jetflash V20 Adata C801...
