0810
0815
0811
0816
0812
0817
0813
0818
0814
0819
(0810-0819)
National Products Ltd.
Room 413-415, Houston Centre,
63 Mody Road, Tsim Sha Tsui East,
Kowloon, Hong Kong.
WWW.NPL2.COM
INFO@NPL2.COM
CHEVROLET
OWNER'S MANUAL
Please read entire manual before starting assembly.
Keep this manual along with your purchase receipt
Chevrolet,
all related emblems and the
distinctive vehicle model body and grille
designs are General Motors Trademarks
used under license to National Products
Limited.
CAUTION
Screws contain potentially
hazardous sharp points or
sharp edges. Adult assembly
required.
CONTAINS LEAD. MAY BE HARMFUL IF EATEN OR
CHEWED. MAY GENERATE DUST CONTAINING LEAD.
Contents, colors and decorations may vary from those shown.
for future reference.
WARNING
To reduce the risk of injury, adult supervision
is required. Never use on road ways, near
motor vehicles, on or near steep inclines or
steps, swimming pools or other bodies of
water. Always wear shoes, and never allow
more than two riders.
CHOKING HAZARD-Small parts.
Not for children under 3 yrs.
AGES 3
Advertisement
Related Manuals for National Products 810
Summary of Contents for National Products 810
- Page 1 Chevrolet, all related emblems and the distinctive vehicle model body and grille designs are General Motors Trademarks used under license to National Products Limited. WARNING CAUTION To reduce the risk of injury, adult supervision Screws contain potentially is required.
-
Page 2: Limited Warranty
IMPORTANT You must charge your battery for 18 hours before you use your vehicle for the first time. Remember to Charge the battery immediately after each use. Charge the battery at least once a month during storage, even if the vehicle has not been used. he battery will be permanently damaged nd void your warranty... - Page 3 Table of Contents ......................Limited Warranty .
-
Page 4: Safe Driving Rules
Warning To Prevent Serious Injuries Safe Driving Rules This product is intended for use by children ages ADULT SUPERVISION REQUIRED. MAKE SURE CHILDREN KNOW AND 3 and up, and is not intended for children under 3 FOLLOW THESE RULES FOR SAFE years of age due to lack of ability to operate safely. - Page 5 Battery Warning About Thermal Fuses ELECTRICAL HAZARD ® Your 12 volt battery is equipped with a built-in thermal fuse. The thermal fuse is a self-resetting safety WARNING device which automatically trips and shuts down operation of the vehicle if the vehicle is overloaded or the driving Battery can fall out and injure a child conditions too severe.
- Page 6 Battery Charging CAUTION Non-rechargeable batteries are not to be recharged. Make sure the charger connector is matching with the battery connector. Make sure the brand, voltage and frequency of the Battery Connector charger are in accordance with the wall outlet. Charger Batteries are to be inserted with the correct polarity.
- Page 7 Battery Care and Disposal Care Disposal If a battery leak develops, avoid contact with the ® Your battery is a sealed lead-acid leaking acid and place the damaged battery in a battery. It must be recycled or disposed of it in an plastic s s ealed bag.
- Page 8 Parts List Please identify all parts before assembly and save all packaging material until assembly is completed to ensure that no parts are discarded. Metal parts have been coated with lubricant for protection during shipment. Wipe all metal parts with a paper towel to remove any excess lubricant.
- Page 9 Assembly WARNING Children can be harmed by small parts, sharp edges and sharp points in the vehicles unassembled state, or by electrical items. Care should be taken in unpacking and assembling the vehicle. Children should not handle parts, including the battery, or help in the assembly of the vehicle.
- Page 10 Assembly Screw x 4(ST4 x 20) Screw x 2(ST4 x 14) Screw x4(ST4 x 14) Fit the dashboard and windshield assembly - Fit a mirror onto the vehicle. onto the posts near front end of the vehicle. Hint: Each mirror do not seem to fit, try assem bling on the other side.
- Page 11 Assembly Screw x6(ST4 x 14) Screw x2(ST4 x 14) - Place the vehicle upside down. - Fit the grill onto the front bumper. - Insert 4 screws into the front bumper with - Insert two screws into the grill and tighten. bumper support and tighten.
- Page 12 Assembly Nut x1 (M8 x T5) Apply all decals before you install the steering - Position the steering wheel so that the large wheel. opening is UP. - Fit the steering wheel onto the steering column. Use lock nut tool to tighten the nut. - Snap the steering wheel cup.
- Page 13 Radio Installation 3 X 1.5V "AA" (LR6) batteries (Not included) Take out the radio. Insert 3 X 1.5V AA" (LR6) batteries into " the compartment. SOUND BUTTONS TUNE - TUNE + POWER ON/OFF & MP3 LINE INDICATOR LIGHT VOLUME CONTROL IN JACK Tip for MP3: Turn on the power switch.
-
Page 14: Safety Devices
Operating your Vehicle Forward Forward Push the shifter in position and press the accelerator slowly. Reverse Reverse Push the shifter in position and press the accelerator slowly. High Speed High speed Forward Reverse The high speed lock-out must first be removed. Afterwards push the shifter to High speed position and press the accelerator slowly. -
Page 15: Problem Possible Cause
Trouble Shooting IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you ® still experience a problem, please contact Service Center , Toll-free at 1-877-743-3899 from 9 AM to 5 PM ( P ST P ST Monday through Friday. - Page 16 Trouble Shooting Problem Possible Cause Solution Short operating time (less Undercharged battery A new battery should have been charged for at least 18 than 1 hour per charge) hours before using the vehicle for the first time. After that, it must be recharge the battery for at least 12 hours after each use .Never charge longer than 24 hours.
- Page 17 Trouble Shooting Problem Possible Cause Solution Intermittent vehicle operation Loose wire or connector Check all wires around the motors and all connectors to make sure they are tight. ® Motor or electrical switch damage Contact your Service Center for diagnosis and repair at 1-877-743-3899.
- Page 18 Label Decoration Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: Wash your hands before applying the labels. Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. Place the labels exactly as shown in the illustrations.
- Page 19 Parts Diagram Note: Some parts shown are assembled to both sides of the vehicle. Part Quantity Part Quantity Part Quantity Vehicle Windshield Front Wheels Rear Bumper Hood Wheel Covers Rear Deck Grill Washers Seat Front Bumper Nuts Steering Wheel Cover Bumper Support Hubcaps Steering Wheel...
- Page 20 National Products Limited STOP! DO NOT RETURN TO STORE This product cannot be returned for a refund after it has been unpacked and used. Call our toll- free 1-877-743-3899 or fax us 1-909-869-5945 or email us customers erv ice@funcre ation.net or visit us www.funcre ation.net...
