Cairn 4810 Owner's Manual

2-channel integrated amplifier

Advertisement

OWNER'S
MANUAL
MULTI
SOLUTIONS
cairn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4810 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cairn 4810

  • Page 1 OWNER’S MANUAL MULTI SOLUTIONS cairn...
  • Page 2 481O. CE Declaration of conformity Cairn declare that this product is in conformance with the Low Voltage Directive 73/23/EEC. The conformity of the designated product with the provisions of directive number 73/23/EEC (LVD) is proved by full compliance with the following standards:...
  • Page 3: Table Of Contents

    1. Unpacking - advices ..................1.1 Unpacking ....................1.2 Care considerations ..................2. Rear panel ......................2.1 Description ....................2.2 Connections....................3. Front panel ......................3.1 Description ....................3.2 Using the buttons ..................3.3 Navigation help.................... 4. Remote control ....................
  • Page 4: Unpacking - Advices

    1.1 Unpacking Place your 4810 in a dry place, with no direct sun exposure. Sun rays could damage the device. List of supplied furnitures:: -Power cord (Europa or U.S.) -Remote control unit 33 keys -Cells 2x1.5V AAA size (in the remote control unit) -Hexagonal wrench 1.2 Care considerations...
  • Page 5: Description

    2.1 Description Speaker OUT (Minimal impedance of the loudspeakers: 2 Ohm) Main supply connector Fuse (5A time-lag) RS-232 Master (Communication with another Cairn device) RS-232 Slave (Communication wih a PC) Headphone connector (Jack 6.35mm) Preamplifier output Monitor output Monitor input Analog inputs (An1 to An4) A.M.
  • Page 6: Rear Panel

    We recommend the use of cables for your audio connections; this cables have been especially designed to match with all Cairn devices. Note: For the connections of the Inputs/Outputs of your options, please refer to the documentation delivered with the option.
  • Page 7: Front Panel

    3.1 Description Left Button (Short push) “Enter” validate an action (Long push) “Esc” escape from an action or a menu (Rotation) “Navigation” navigate through a menu, modify a parameter Right button (Short push) “ON” turn on the device (Long push) “OFF”...
  • Page 8: Using The Buttons

    3.2 Using the buttons Navigation / validation volume/ power -Short push : validate an action -Short push : turn on the device -Long push : escape -long push : turn off the device -Rotation : navigate through a menu,...
  • Page 9: Navigation Help

    3.3 Navigation help While you navigate you will se arrows on the upper left corner of the screen. It illustrates your position in a menu. You can go down You can go up Up and down possible In accordance with your selections, you can either activate the loudspeaker output “Speaker Out”, or the heaphone output “Heaphone”.
  • Page 10: Remote Control

    4.1 Description POWER : (short push) (long push) DISPLAY : (short push, display on) Informations scroll (short push, display off) Display turns on (long push) Display turns off 1 à 9 : Access to Track 1 to 99 Example: Track 23 press 2 then 3...
  • Page 11: Using

    Because short push and long pushs are distinguished, it is easier to turn on and off all cairn devices at the same time (It is impossible to turn on a device and turn off another one with the same push).
  • Page 12: Starting

    5.1 Starting In chapter 2 you have connected your 481O Each time you turn on 481O , the evice scans the option connectors and the RS-232 ports to detect the options and other devices linked to it. If you have connected a new option into, or a Fog3 to the connector “Master” of 481O , the menu is updated to match with your new configuration.
  • Page 13 Now you can use the sources that 481O has created. E.g.: A fog3 has been connected to “Master” Connector of 481O: By default, the source “Fog CD” has been associated with analog connector “An1” of 481O Each source created from a MULTI SOLUTION option is associated ith the default connector of this option.
  • Page 14 -Select “audio connector” and by rotation of the left button, change the connector you want to associate with your source. Navigation Enter -Select “level” to change the relative level of the source (default is 0.0dB). Navigation Enter -Go back to the beginning of the menu to set up your others sources.
  • Page 15: Description Of The Menus

    6.1 Main screen The main screen is the screen displayed when the device has just been powered It shows the current source selected, the monitoring state, and the output selected (headphone or speakers). When the selected source is the tuner, other menus are added, like the sation list, stereo/mono mode etc...
  • Page 16: Heaphone Setup

    6.3 Headphone setup The “Headphone setup” menu allows you to activate or disactivate the headphone output. While Heaphone outputs are activated, the “Speaker out” outputs are no more activated, and the Balance is equalized. You can also set up a relative volume level for the headphone output.
  • Page 17: General Setup

    6.6 General setup a) Region setup Choose your language (French or English). b) Display setup: Set up the display luminosities. The display is in high luminosity when a user command is received (by remote control or front panel button).
  • Page 18: Options Setup

    Automatic setup: You can specify the time the device can stay “on” with any user operation. Each time a user operation is detected, the program reloads the counter. You can specify the volume soft ramp parameters, that is to say the time the volume takes to go from mute to the normal volume.
  • Page 19: Info

    6.8 Info If you push the “DISPLAY” key of the remote control unit, or if you select “INFO” menu you will see informations on the display. If you make consecutives pushs, the information screens will scroll. Ex: If you have selected the RADIO source (tuner option) you will see (in order of appearence) the RADIO info screen, the time &...
  • Page 20: Special Features

    If an overload is detected (too much current output to your speakers) the level will be automatically decreased by steps of 0.5dB, and a message indicates overload. 7.4 Software update Software will be released on www.cairn-ezo.com when available. 1-Disconnect 481O from mains.
  • Page 21: Installing An Option

    8. Installing an option -Ensure 481O is totally disconnected from mains. -Remove the eight screws from the cover, then remove the cover (the tool is supplied). -Take care not to touch any component because of shock hazard even if the device is unlugged.
  • Page 22: Specifications

    9. Specifications CAIRN reserves the right to improve or modify its products without any notice. Technical datas and functions can change according to the country. Width: 432mm/17in Height: 102mm/4in Depth: 312mm/12.3in Weight: 12kg/27lbs Power supply: 530VA Nb of transformers: 2 toroïdal, 1El...
  • Page 23: Annex 1 - Volume And Decibel

    Volume graduation in dB: The human ear doesn’t reconstitute the acoustic power variations in a linear way, its perception is logarithmic. By the way, the difference of level between 10W and 100W sounds the same as between 100W and 1000W.
