SenTech STC-HD133DV User Manual

Osd remote control
Hide thumbs

Advertisement

Quick Links

STC-HD133DV
OSD Remote Control
User Guide
Operating and Programming
the OSD Remote Control Device

Advertisement

loading
Need help?

Need help?

Do you have a question about the STC-HD133DV and is the answer not in the manual?

Questions and answers

Summary of Contents for SenTech STC-HD133DV

  • Page 1 STC-HD133DV OSD Remote Control User Guide Operating and Programming the OSD Remote Control Device...

  • Page 2: Safety Precautions

    STC-HD133DV OSD Remote Control Safety Precautions For U.S.A. For U.S.A. CAUTION CAUTION Warning: Warning: For U.S.A. CAUTION RISK OF ELECTRIC SHOCK This equipment generates and uses radio frequency energy and if RISK OF ELECTRIC SHOCK This equipment generates and uses radio frequency energy and if...
  • Page 3 While every effort has been made to ensure that the details contained in Sentech America’s website and all documentation are correct and up-to-date, Sentech America assumes no liability, legal or otherwise for any errors in listings, specifications, part numbers, process, software or model applications.

  • Page 4: Table Of Contents

    STC-HD133DV OSD Remote Control Contents I. Keypad Layout and Button Functions ........................5 II. Using the OSD Menu Remote Control ........................6 III. Function Menu & Settings Chart ........................... 7 IV. Programming the Remote Control ........................8-9 A. Assigning Camera Functions to the Buttons ........................8 B.

  • Page 5: Keypad Layout And Button Functions

    STC-HD133DV OSD Remote Control I. Keypad Layout and Button Functions The following is a diagram of the STC-HD133 OSD Menu Remote Control: UP ARROW: Used for toggling through or highlighting the desired OSD display page, function menu and setting adjustments...

  • Page 6: Using The Osd Menu Remote Control

    STC-HD133DV OSD Remote Control II. Operating the OSD Menu Remote Control (Default Settings) First plug the pin jack of the remote control into the STC-HD133 camera to begin using the OSD Remote Control. Press the MENU [A] button to initiate the OSD (On Screen Display) menu.

  • Page 7: Function Menu & Settings Chart

    STC-HD133DV OSD Remote Control III. Function Menu & Settings Chart The following chart presents all of the selectable functions and the correlating selectable setting adjustments for each function. For further details on the function menu and the setting please refer to the STC-HD133 Control Manual.

  • Page 8: Programming The Remote Control

    IV. Programming the Sentech OSD Remote Control A. Assigning Camera Functions to the Buttons In conjunction with the HD133Ctrl software, the Sentech HD133 Remote Control is designed to allow users to assign and control up to 12 total camera functions with the remote.

  • Page 9: Assigning Osd Menu Navigation Functions To The Buttons

    OSD Remote Control B. Assigning OSD Menu Navigation Functions to the Buttons In conjunction with the HD133Ctrl software, the Sentech HD133 Remote Control is also designed to allow users to self-assign the keypad’s navigation functions for the OSD menu. In order to assign the keypad navigation functions the user must first open the HD133Ctrl software.
  • Page 10 STC-HD133DV OSD Remote Control Revision Rev. Date Changes Notes 12/9/2011 New Document User Guide Rev 1.0...
  • Page 11 STC-HD133DV OSD Remote Control Senor Technologies America, Inc. 1345 Valwood Parkway, Suite 320 Carrollton, Texas 75006-6891 TEL (972)481-9223 FAX(972) 481-9209 http://www.sentechamerica.com/ Sensor Technology Co., Ltd. 7F, Harada Center Building 9-17, Naka cho 4 chome Atsugi-city, Kanagawa 243-0018 Japan TEL +81-46-295-7061 FAX +81-46-295-7066 http://www.sentech.co.jp/...
